Page 3: Safety Guidelines
This document explains how to connect to the NI 9231. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. The guidelines in this document are specific to Note the NI 9231. The other components in the system might not meet the same safety ratings. - Page 4 Such voltage measurements include signal levels, special equipment, limited-energy parts of equipment, circuits powered by regulated low-voltage sources, and electronics. NI 9231 Getting Started Guide | © National Instruments | 3 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
-
Page 5: Safety Guidelines For Hazardous Locations
III, or IV. Safety Guidelines for Hazardous Locations The NI 9231 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 Gc and Ex nA IIC T4 Gc hazardous locations; and nonhazardous locations only. - Page 6 II 3G and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9231 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
-
Page 7: Emc Guidelines
(EMC) stated in the product specifications. These requirements and limits provide reasonable protection against harmful interference 6 | ni.com | NI 9231 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www... - Page 8 To ensure the specified EMC performance, the Notice length of all I/O cables must be no longer than 3 m (10 ft). NI 9231 Getting Started Guide | © National Instruments | 7 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
-
Page 9: Preparing The Environment
Conducted RF interference on the NI 9231 can Notice adversely affect its I/O ports' measurement accuracy. Preparing the Environment Ensure that the environment in which you are using the NI 9231 meets the following specifications. Operating temperature -40 °C to 70 °C... - Page 10 NI 9231 Pinout AI0+ AI0– AI1+ AI1– AI2+ AI2– AI3+ AI3– AI4+ AI4– AI5+ AI5– AI6+ AI6– AI7+ AI7– NI 9231 Getting Started Guide | © National Instruments | 9 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
-
Page 11: Grounded Connections
Positive analog input signal connection Negative analog input signal connection Grounded Connections Signal Source – NI 9231 AI– Common Mode Voltage 10 | ni.com | NI 9231 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www... -
Page 12: Floating Connections
– NI 9231 AI– NI 9231 Connection Guidelines • Make sure that devices you connect to the NI 9231 are compatible with the module specifications. Integrated Electronic Piezoelectric (IEPE) Sensors The NI 9231 provides an IEPE excitation current for each channel to measure the IEPE sensors. -
Page 13: Overvoltage Protection
NI 9231 results in a floating connection even though the case of the sensor is grounded. Overvoltage Protection The NI 9231 provides overvoltage protection for each channel. Refer to the device datasheet on ni.com/manuals Note for more information about overvoltage protection. -
Page 14: Where To Go Next
RELATED INFORMATION C Series Documentation Services & Resources ni.com/services ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software NI 9231 Getting Started Guide | © National Instruments | 13 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www... -
Page 15: Worldwide Support And Services
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. NI 14 | ni.com | NI 9231 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www... - Page 16 United States, visit the Worldwide Offices section of ni.com/ niglobal to access the branch office websites, which provide up- to-date contact information. NI 9231 Getting Started Guide | © National Instruments | 15 hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
- Page 17 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, file on your media, or the National Instruments Patent Notice at patents.txt ni.com/ . You can find information about end-user license agreements (EULAs) and third-party patents legal notices in the readme file for your NI product.
