◈ Product Specifications

Item
Printing Method Thermal printing
Printing Speed Up to 5 ips
Resolution 203 dpi
10 SLCS Resident Bitmap Fonts
One SLCS Resident Scalable Font
16 BPL-Z™ Resident Bitmap Fonts
Font One BPL-Z™ Resident Scalable Font
7 BPL-C™ Resident Bitmap Fonts
23 Code Page
Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
1D: Codabar, Code 11, Code 39, Code 93,Code 128, EAN-13,
Printing
Barcode
2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode,
Emulation SLCS, BPL-Z™, BPL-C™
Paper End Sensor, Black Mark Sensor,
Sensor
Paper Cover Open Sensor, Label Presence Sensor
Cutter Type Tear-bar
Language User language supported
Paper Form
Paper Type
Paper Diameter
Width
Thickness

◈ Printer Cleaning

If the interior of the printer is dusty, print quality can decline.
In such a case, follow the instructions below to clean the printer.
1) Open the paper cover and remove the paper, if present.
2) Clean the printhead using the cloth or cotton swab soaked in alcohol for medical.
3) Using the cloth or cotton swab soaked in alcohol for medical, remove the paper dust
from the black mark sensor. (Sensor could be located in the middle or on left or on right)
4) Do not use the printer for one to two minutes after cleaning until the alcohol for medical
has completely evaporated and dried.
5) Insert the paper and close the paper cover.
• Caution
1) Make sure the printer power is turned off before cleaning.
2) Wait for two to three minutes after power-off before head cleaning because the head
part may become very hot during printer operation.
3) Take care not to touch the heating region of the head with your hand while cleaning
the head part.
→ The printer head may be damaged by static electricity.
4) Take care to avoid scratching the head.
5) Clean the printer head periodically if linerless paper is used. Recommended cleaning
period is after consuming ten rolls of linerless paper (100 meters), or more than once
a week. Printing quality may be degraded or printer life may be shortened if the head is
not cleaned periodically.
• Warning
1) Use only the linerless paper that is provided by BIXOLON. Use of other paper voids
product warranty.
◈ WEEE
This marking shown on the product or its literature, indicates that it should not be
disposed of with other household wastes at the end of its working life. To prevent
possible harm to the environment or people from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources. Household users should
contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take this item for
environmentally safe recycling. Business users should contact their supplier and
check the terms and conditions of the purchase contract. This product should not
be mixed with other commercial wastes for disposal.
◈ Battery Safety Precautions
1. If the battery is not charged after the charging time, stop charging and contact the seller.
2. Store and use the battery where it will not come into contact with liquid (water, salt water,
etc.). There may be a risk of overheating, rupturing or igniting.
3. Avoid exposing the battery to high temperatures over 50 ℃ and do not store or use it in
a place with high temperature and humidity. There may be a risk of overheating,
rupturing or igniting. In addition, it may reduce the performance and life of the battery.
There is a risk of explosion, especially when the battery is placed by a fire or stored near
a heating device (e.g., heater, etc.).
4. Be sure to only use an adapter or charger approved by us to charge the battery. Use of
any other adapter or charger may reduce battery performance and life, or cause a risk of
overheating, rupturing or igniting.
5. Avoid causing any strong impact to the battery or throwing it. The protective device
inside the battery may be damaged, which may reduce the battery performance and life,
or there may be a risk of overheating, rupturing or igniting.
6. Do not disassemble or modify the battery. The battery contains safety and protection
devices to prevent danger. It may reduce battery performance and life due to damage, or
there may be a risk of overheating, rupturing or igniting.
Description
EAN-8, Industrial 2-of-5, Interleaved 2-of-5,
Logmars, MSI, Plessey, Postnet,
GS1 DataBar (RSS-14), Standard 2-of-5,
UPC/EAN extensions, UPC-A, UPC-E, IMB
MicroPDF417, PDF417, QR code,TLC 39
Label paper Linerless paper
Thermal Paper Thermal Paper
Max. Ø66 mm (2.60") Max. Ø66 mm (2.60")
25~80mm (0.99"~3.15") 25~80mm (0.99"~3.15")
0.07~0.19 mm 0.08 ± 0.01mm
A
B

◈ Safety Precautions

In using the present appliance, please keep the following safety regulations in order
to prevent any hazard or material damage.
WARNING
Violating following instructions can cause serious injury or death.
Do not plug several products in
one multi-outlet.
• This can provoke over-heating and a fire.
• If the plug is wet or dirty, dry or wipe it
before usage.
• If the plug does not fit perfectly with the
outlet, do not plug in.
• Be sure to use only standardized multi-
outlets.
PROHIBITED
Do not pull the cable to unplug.
• This can damage the cable, which is the
origin of a fire or a breakdown of the printer.
PROHIBITED
Do not plug in or unplug with your
hands wet.
• You can be electrocuted.
PROHIBITED
CAUTION
Violating following instructions can cause slight wound or damage
the appliance.
If you observe a strange smoke,
odor or noise from the printer,
unplug it before taking following
measures.
• Switch off the printer and unplug the set
from the mains.
• After the disappearance of the smoke, call
your dealer to repair it.
TO UNPLUG
PRINTER
Install the printer on the stable
surface.
• If the printer falls down, it can be broken
and you can hurt yourself.
PRINTER
PROHIBITED
Do not let water or other foreign
objects in the printer.
• If this happened, switch off and unplug
the printer before calling your dealer.
PROHIBITED
PRINTER
You must use only the supplied
adapter.
• It is dangerous to use other adapters.
ONLY SUPPLIED ADAPTER
PROHIBITED
Keep the plastic bag out of
children's reach.
• If not, a child may put the bag on his head.
PROHIBITED
Do not bend the cable by force or
leave it under any heavy object.
• A damaged cable can cause a fire.
PROHIBITED
Keep the desiccant out of
children's reach.
• If not, they may eat it.
PROHIBITED
Use only approved accessories and
do not try to disassemble, repair or
remodel it for yourself.
• Call your dealer when you need these
services.
• Do not touch the blade of auto cutter.
DISASSEMBLING
PROHIBITED
PRINTER
Do not use the printer when it is out
of order. This can cause a fire or an
electrocution.
• Switch off and unplug the printer before
calling your dealer.
TO UNPLUG
PRINTER
DEALER
