- Page 1 T22023 SAFETY AND INSTRUCTION MANUAL PLEASE READ CAREFULLY YEAR *Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk. GUARANTEE...
- Page 2 Temperature control dial Easy carry lock Cord guard Temperature indicator light Removable water tank with handle Continuous steam lock Cord storage Steam control button Technical Data: Model: T22023 Rated Voltage: 220-240v Frequency: 50-60Hz Power Consumption: 2700W Steam output: 80g/min Water Tank Capacity:...
- Page 3 Wiring Safety for UK Use Only Earth Fuse (Green/Yellow) Neutral Live (Blue) (Brown) IMPORTANT As the colours in the mains lead of this The plug must be fitted with a fuse of the same appliance may not correspond with the rating already fitted and conforming to BS 1362 coloured markings identifying the terminals in and be ASTA approved.
-
Page 4: Important Safety Information
Important Safety Information: Please read these notes carefully BEFORE using your Tower appliance • Check that the voltage • Cleaning and user of the main circuit maintenance shall not corresponds with the be made by children rating of the appliance without supervision. - Page 5 • DO NOT use extension • Never pull the cord to cords with the disconnect from the appliance. mains: instead, hold the plug and pull to • DO NOT operate the disconnect. appliance by means of external time or • Always disconnect the separate remote control iron from the electrical...
- Page 6 Before First Use: NOTE: Every effort has been made to ensure this item reaches you in perfect condition. However, due to our rigorous testing and quality processes before the iron leaves our production facility, there may be a small amount of water residue left in the water tank. This is nothing to worry about and the product can be used as normal.
- Page 7 Temperature Selection: To increase the temperature of the steam iron, rotate the temperature control dial in a clockwise direction until the required temperature is aligned with the indicator marker. The temperature indicator light will illuminate to indicate that the on appliance is heating up. The temperature indicator light will go off when the temperature selected is reached and the iron is ready to use.
- Page 8 NOTE: The appliance will need to be set to the 3-dot setting to produce steam. The higher the temperature the more powerful the steam. Hold the iron approximately 20 cm away from the fabric. Press and hold the steam button, then release, working in short bursts to remove any creases. NOTE: If a continuous stream of steam is required push the steam lock to remove the requirement to manually de-press the steam button.
-
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Possible Solution The iron will not heat The iron is not connected Plug in and switch on the iron at the to the mains power supply. mains power supply. The temperature is set too Increase the temperature using the low. - Page 10 Cleaning the Anti-Calc Filter: Due to the high amount of steam this appliance produces, limescale can form inside the water tank with repeated uses. Since high amounts of limescale can affect the high-precision components inside the iron, it is important that limescale build-up be kept to a minimum. This unit is equipped with an anti-calc filter inside the water tank, which automatically cleans the tank and prevents limescale build-up from affecting the pump and other components inside the iron.
- Page 11 Notes:...
- Page 12 thank you! We hope you enjoy your appliance for many years This product is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Need help?
Do you have a question about the T22023 and is the answer not in the manual?
Questions and answers
No calc filter supplied new purchase
The Tower Hobbies T22023 comes with an anti-calc filter already installed inside the water tank. Since the unit is equipped with this filter from the start, a separate calc filter is not supplied with a new purchase. However, replacement filters (T22023GLD02) are available as spare parts if needed.
