MicroNova Agua-IoT NAVEL 2.0 User Manual

1. CONTENT OF THE BOX

• Navel 2.0 ( );
fig. 1-1
• MODU II-MODU II serial cable (
• MODU II-DSUB 9 serial cable (
• Power supply* (
fig. 1-4
• velcro.
* The support power supply supplied in
the kit complies with the EN 60950-1
directive, and
characteristics:
• SELV (very low safety voltage);
• Protected against
overcurrents;
• Limited power source (Low power source
LPS)

2. NAVEL POWER SUPPLY

1. Depending on the type of stove, connect one of the two appropriate serial cables. (fig. 1-2, 1-3)
2. Supply the Navel (fig. 1-1) with the support power supply (fig. 1-4). The device is powered if the green
Power LED (2) is on. (For more details on the operation of the LEDs, refer to the relevant section 7:
"MEANING OF ICONS")

3. USER REGISTRATION PROCEDURE

1. Download and install the "Nina" app from Google Play or Apple Store.
2. Open the application and proceed with registration (written "Subscribe") by entering the
following:
- email address;
- dedicated password for the application (minimum 8 characters);
- password verification copy;
- consent to privacy.
3. Press the "SUBSCRIBE" button and wait for the e-mail containing the 6-digit code useful for
activating the account.
4. Enter the 6-digit code received by e-mail and press the "ACTIVATE" button to access the
application.

4. STOVE REGISTRATION PROCEDURE

1. Open the stoves management application and enter the login / authentication data to perform the
"Login".
2. From the "My Stoves" screen, press the "+" button at the bottom right to add a stove.
3. Scroll to the configuration wizard screen and press the "ENTER DATA" button.
4. Insert the required data progressively:
- Serial number of the stove (shown on the back of the stove on a silver label) using the "barcode
capture" function;
- MAC address (shown on the label supplied with the Navel user manual) using the "QRcode" capture
function;
- Registration Code (Reg. Code) (shown on the label supplied with the Navel user manual);
- Stove location data (optional data);
- Authorization to share stove operating data;
- Press the "SAVE STOVE" button.
QG_T009_ENG_REV_1.0
NAVEL 2.0 USER GUIDE
(Installation by qualified personnel)
);
fig. 1-2
);
fig. 1-3
);
has the following
short circuits and
MICRONOVA SRL Pag. 1 of 2
