MAINTENANCE
4. Tighten the cap of the filter cover.
(1) Breather filter

8. Replacing the hydraulic oil filter

First change of the hydraulic-oil-filter is 50 service
hours.
1. Raise the cab.
(See Tilting up the cab on page 93 for detail)
2. Open the cap of the filter cover.
3. Remove the hydraulic-oil-filter with the wrench and
replace with the new one.
4. Tighten the cap of the filter cover.
(1) Hydraulic oil filter
9. Cleaning the front window roller
[Closed cab model only]
Consult your local KUBOTA dealer for cleaning the
front window roller.
114
EVERY 500 SERVICE HOURS

EVERY 1000 SERVICE HOURS

Carry out all 50, 100, 200, 250, and 500 hour servicing
at the same time.
1. Changing the hydraulic oil
including replacing the suction filter
and the return filter in the hydraulic
tank
WARNING
To avoid personal injury or death:
• Wait long enough for the hydraulic oil to cool
down. Then change the hydraulic oil.
1. Park the machine on a firm, flat, and level surface.
2. Lower the lift arms to the ground, and stop the
engine.
3. Remove the cover with drain plug in front of the
machine, and drain the hydraulic oil.
(1) Drain plug
4. Loosen the bolt, and remove the tank cover.
5. Remove the suction filter and replace with new one.
6. Loosen the set bolt first. Then remove the return
filter and replace with new one.
7. Install the hydraulic cover.
(2) Cover
SVL97-2
