PRODUKT MANUAL
PURE SINE WAVE
UNINTERRUPTIBLE POWER WAVE
CHARGER INVERTER
SINUS PROTECT
900
SINUS PROTECT-900 (600W)
UNINTERRUPTIBLE POWER SUPPLY
VOLT POLSKA Sp. z o.o.
ul. Grunwaldzka 76
81-771 Sopot
www.voltpolska.pl
sales@voltpolska.pl (58) 341-05-06 | przemek@voltpolska.pl (58) 341-38-80 | bartek@voltpolska.pl (22) 100-42-99
Advertisement
Table of Contents
Related Manuals for Volt Polska SINUS PROTECT 900
Summary of Contents for Volt Polska SINUS PROTECT 900
- Page 1 PRODUKT MANUAL PURE SINE WAVE UNINTERRUPTIBLE POWER WAVE CHARGER INVERTER SINUS PROTECT SINUS PROTECT-900 (600W) UNINTERRUPTIBLE POWER SUPPLY VOLT POLSKA Sp. z o.o. ul. Grunwaldzka 76 81-771 Sopot www.voltpolska.pl sales@voltpolska.pl (58) 341-05-06 | przemek@voltpolska.pl (58) 341-38-80 | bartek@voltpolska.pl (22) 100-42-99...
- Page 2 PLEASE READ AND KEEP THIS MANUAL Thank you for selecting this desktop pure sine wave Uninterruptible Power Supply ( UPS) / Inverter. This manual is a guide to install and use the UPS. It includes important safety instructions for operation and correct installation of the UPS. This symbol gives information regarding the points important for This symbol gives information, warnings, and other suggestions.
-
Page 3: Table Of Contents
TABLE OF CONTENTS ..........P1 1. IMPORTANT SAFETY INSTRUCTIONS ............P2 2. INTRODUCTION OF THE UPS ................P3 3.SPECIFICATIONS 4. INSTALLATION OF THE UPS ..............P4 4.1. UNPACK AND CHECK...................P4 4.2. PLACEMENT ...............P5 4.3. FAMILIAR WITH THE UPS ..............P7 4.4. CONNECT TO BATTERY .........P7 4.5. -
Page 4: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS •Before operating the UPS, make sure you carefully read all the instructions and warnings in this manual. • In order to avoid any damage to the UPS, it is advised to transport it in its own packing. -
Page 5: Introduction Of The Ups
2. INTRODUCTION OF THE UPS SINUS PROTECT 900 are specifically designed to backup all the home and office electrical appliances when the mains power is failure. It’s equipped with the latest line interactive technology, CPU-controlled PWM technology, and full-protected modular circuit. It’s a reliable backup power source for all kinds of loads. - Page 6 Battery Charging Machine Size Capacity Model No. Current Voltage (W x H x D mm ) PSU-816-300VA 300VA / 180W 12VDC 8A max 140x180x350 PSU-816-500VA 500VA / 300W 12VDC 10A max 140x180x350 PSU-816-800VA 800VA / 480W 12VDC 12A max 160x240x390 PSU-816-1000VA 900VA / 600W 12VDC...
-
Page 7: Installation Of The Ups
4.INSTALLATION OF THE UPS 4.1. UNPACK AND CHECK Open the package, you will find: UPS..........1 set User’s Manual ......1 piece Warranty Card......1 piece Battery Cable.......1 pair (optional accessories) Check the rating label/plate to make sure the UPS is in accordance with your purchase order. -
Page 8: Familiar With The Ups
4.3 FAMILIAR WITH THE UPS A. Front Side of the UPS 1: Colorful Display 2: Temporary Mute Button Inverter ON/OFF Switch Output Voltage Mains Mode Overload Battery Capacity Battery Mode Error Intput Voltage Load Rate 100% Battery Capacity Load Rate sales@voltpolska.pl (58) 341-05-06 | przemek@voltpolska.pl (58) 341-38-80 | bartek@voltpolska.pl (22) 100-42-99... - Page 9 B. Back Side of the UPS For models: 800VA / 900VA, For models: 300VA / 500VA 1500VA / 2000VA COOLING FAN CHARGING CURRENT CHARGING CURRENT COOLING FAN CIRCUIT BREAKER OUTPUT OUTPUT AC INPUT OUTPUT AC INPUT CIRCUIT BREAKER For models: 3000VA / 5000VA 1: Cooling Fan 2: Battery Terminal “-”...
-
Page 10: Connect To Battery
4.4. CONNECT TO BATTERY A. Make sure using the correct battery cable. The over current capability of the battery cable should not be less than the maximum discharging current. Please refer to the below table. Diameter Battery Cable Model No. PSU-816-300VA （12VDC, 180W) 10AWG / 5.26mm²... -
Page 11: Operation Of The Ups
For models: 3000VA/5000VA: А. Make sure use connection cables in correct diameter. Input & Output Cable Model No. PSU-816-3000VA （48VDC, 1800W) 14AWG / 2.075mm² PSU-816-5000VA （48VDC, 3000W) 12AWG / 3.332mm² B. Make connection as shown in below chart. INPUT OUTPUT BATTERY C. -
Page 12: Charging Current Selector
5.3. CHARGING CURRENT SELECTOR It’s recommended to select the charging current as below: Battery Capacity Level Charging Current 20AH to 50AH Low (3A~5A) 60AH to 100AH Medium (7A~9A) 100AH to 200AH High (10A~15A) Wrong selection of the charging current may lead to the damage of battery in charging process! 5.4. -
Page 13: Alarm And Protection
7. ALARM AND PROTECTION 7.1. BATTERY MODE ALARM The UPS will beep once (4 continous sound) every 30 seconds when working at battery mode. 7.2. BATTERY LOW VOLTAGE ALARM AND SHUT DOWN The UPS will beep once per second when battery is in low level. When the battery is near empty, it will beep rapidly for 20 seconds and then shut down automatically. -
Page 14: Maintenances Of The Ups
8.MAINTENANCES OF THE UPS This UPS is basically maintenance free! while regular maintenance can extend the life of the UPS by the following steps: 8.1. REGULAR INSPECTION • Disconnect the UPS from the mains power and battery completely. • Use cotton cloth and detergent to clean the body and ventilation holes. 8.2. -
Page 15: Trouble Shooting
9. TROUBLE SHOOTING Malfunction Cause Solution 1. UPS goes into The input voltage or battery mode, but Wait till the input voltage or input input frequency is there is mains requency is normal out of range. power Press and hold the power switch till Press time is too 2. - Page 16 WARRANTY CARD DATE OF PURCHASE SHIPPING ADDRESS SIGNATURE / STAMP DAMAGE DESCRIPTION SERVICE COMMENTS FILL IN IF NEEDEED (*) Cross incorrect I agree to pay the cost of inverter repair due to: * expiration of the warranty period / * warranty void Before proceeding with the repair, service will inform by phone about the exact costs of the repair.
