ROG STRIX
B650E-F GAMING
WIFI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROG STRIX B650E-F GAMING WIFI and is the answer not in the manual?

Questions and answers

jeremy
March 7, 2025

some more detail on +- for front panel pinout would be helpful

0

Related Manuals for Asus ROG STRIX B650E-F GAMING WIFI

Summary of Contents for Asus ROG STRIX B650E-F GAMING WIFI

  • Page 1 ROG STRIX B650E-F GAMING WIFI...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... iv About this guide ......................v ROG STRIX B650E-F GAMING WIFI specifications summary ........ vi Connectors with shared bandwidth ................x Package contents ....................... xi Installation tools and components ................xii Chapter 1: Product Introduction Before you proceed ................... 1-1 Motherboard layout..................

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Rog Strix B650E-F Gaming Wifi Specifications Summary

    ROG STRIX B650E-F GAMING WIFI specifications summary AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors* * Refer to www.asus.com for CPU support list. Chipset AMD B650 Chipset 4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800 ECC/Non-ECC,...
  • Page 7 ROG STRIX B650E-F GAMING WIFI specifications summary Rear USB (Total 12 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C ® 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C ®...
  • Page 8 ROG STRIX B650E-F GAMING WIFI specifications summary 1 x USB 3.2 Gen 2 connector (supports USB Type-C ® 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports...
  • Page 9 Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm) • Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications. • MyASUS offers a variety of support features such as helping to troubleshoot issues, optimizing product performance, integrating ASUS software, and recovery drive creation.

  • Page 10: Connectors With Shared Bandwidth

    Connectors with shared bandwidth CPU_OPT RGB_HEADER AIO_PUMP ATX_12V_2 ATX_12V_1 HDMI_DP DRAM DIGI PLUG_8PIN_PWR +VRM BOOT CPU_FAN U32G1_E1234 U32G2_2 BIOS_FLBK FLBK_LED1 USB_5_15_16_17 U32G2_C3 SOCKET AM5 LAN_U32G2_11 M.2(WIFI) AUDIO U32G2X2_C1 M.2_1(SOCKET3) PCIE SATA 5.0 X4 2280 2260 2242 Ethernet 256Mb BIOS PCIEX16_1 M.2_2(SOCKET3) Super PCIE...

  • Page 11: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard 1 x ROG STRIX B650E-F GAMING WIFI motherboard Cables 2 x SATA 6Gb/s cables Addtional Cooling Kit 1 x Thermal Pad for M.2 1 x ASUS Wi-Fi moving antennas 1 x Cable ties pack 2 x Rubber Packages for M.2...

  • Page 12: Installation Tools And Components

    Installation tools and components Phillips (cross) screwdriver PC chassis Power supply unit AMD AM5 CPU AMD AM5 compatible CPU Fan DDR5 DIMM SATA hard disk drive SATA optical disc drive (optional) Graphics card (optional) M.2 SSD module (optional) Screws The tools and components in the table above are not included in the motherboard package.

  • Page 13: Chapter 1: Product Introduction

    • The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. • For more information on installing your motherboard, please scan the QR code below: ROG STRIX B650E-F GAMING WIFI...

  • Page 14: Motherboard Layout

    Motherboard layout 24.4cm(9.6in) CPU_OPT ATX_12V_2 ATX_12V_1 HDMI_DP AIO_PUMP DRAM DIGI PLUG_8PIN_PWR +VRM BOOT CPU_FAN U32G1_E1234 U32G2_2 BIOS_FLBK FLBK_LED1 USB_5_15_16_17 U32G2_C3 SOCKET AM5 LAN_U32G2_11 M.2(WIFI) AUDIO U32G2X2_C1 M.2_1(SOCKET3) PCIE SATA 5.0 X4 2280 2260 2242 256Mb BIOS Ethernet PCIEX16_1 M.2_2(SOCKET3) Super PCIE SATA 4.0 X4...
  • Page 15 15. Front Panel Audio header 1-17 16. S/PDIF Out header 1-18 17. System Panel header 1-19 18. Thermal Sensor header 1-20 19. Thunderbolt™ header 1-21 20. BIOS FlashBack™ LED 1-22 21. Q-LEDs 1-22 22. 8-pin Power Plug LED 1-23 ROG STRIX B650E-F GAMING WIFI...
  • Page 16 Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related.
  • Page 17 A DDR5 memory module is notched differently from a DDR, DDR2, DDR3 or DDR4 module. DO NOT install a DDR, DDR2, DDR3 or DDR4 memory module to the DDR5 slot. Recommended memory configurations DIMM_A1 DIMM_A2 DIMM_A2 DIMM_A2 DIMM_B1 DIMM_B2 DIMM_B2 ROG STRIX B650E-F GAMING WIFI...
  • Page 18 (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • Visit the ASUS website for the latest QVL, and memory frequency support depends on the CPU types. Chapter 1: Product Introduction...
  • Page 19 Hyper M.2 x16 series card is installed. • For full details on the PCIe bifurcation, you may visit the support site at https://www.asus.com/support/FAQ/1037507/. • The Hyper M.2 x16 series card is sold separately. • Adjust the PCIe bifurcation under BIOS settings. ROG STRIX B650E-F GAMING WIFI...
  • Page 20 Fan and Pump headers The Fan and Pump headers allow you to connect fans or pumps to cool the system. AIO_PUMP CPU_OPT CPU_FAN CHA_FAN4 FAN PWM FAN IN CHA_FAN3 FAN PWR CHA_FAN1 CHA_FAN2 • DO NOT forget to connect the fan cables to the fan headers. Insufficient air flow inside the system may damage the motherboard components.
  • Page 21 We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. ROG STRIX B650E-F GAMING WIFI...
  • Page 22 M.2 slots The M.2 slots allow you to install M.2 devices such as M.2 SSD modules. M.2_1(SOCKET3) M.2_2(SOCKET3) M.2_3(SOCKET3) • AMD Ryzen™ 7000 Series Desktop Processors: - M.2_1 slot supports PCIe 5.0 x4 mode M Key design and type 2242/2260/2280 storage devices.
  • Page 23 If you installed SATA storage devices, you can create a RAID 0/1/10 configuration with AMD RAIDXpert2 Technology through the onboard AMD B650 chipset. Before creating a RAID set, refer to the RAID Configuration Guide. You can download the RAID Configuration Guide from the ASUS website. ROG STRIX B650E-F GAMING WIFI 1-11...
  • Page 24 USB 3.2 Gen 2 Type-C Front Panel connector ® The USB 3.2 Gen 2 Type-C connector allows you to connect a USB 3.2 Gen 2 ® Type-C module for an additional USB 3.2 Gen 2 Type-C port on the front panel. The ®...
  • Page 25 The USB 2.0 headers provide data transfer speeds of up to 480 Mb/s. USB_E12 USB_E34 PIN 1 PIN 1 DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. ROG STRIX B650E-F GAMING WIFI 1-13...
  • Page 26 Addressable Gen 2 headers The Addressable Gen 2 headers allow you to connect individually addressable RGB WS2812B LED strips or WS2812B based LED strips. ADD_GEN 2_1 ADD_GEN 2_3 ADD_GEN 2_2 PIN 1 The Addressable Gen 2 header supports WS2812B addressable RGB LED strips (5V/ Data/Ground), with a maximum power rating of 3A (5V) and the addressable headers on this board can handle a combined maximum of 500 LEDs.
  • Page 27 RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is powered on. • The LED strip is purchased separately. ROG STRIX B650E-F GAMING WIFI 1-15...
  • Page 28 Clear CMOS header The Clear CMOS header allows you to clear the Real Time Clock (RTC) RAM in the CMOS, which contains the date, time, system passwords, and system setup parameters. CLRTC PIN 1 To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Short-circuit pin 1-2 with a metal object or jumper cap for about 5-10 seconds.
  • Page 29 HD Audio. Connect one end of the front panel audio I/O module cable to this header. AAFP PIN 1 HD-audio-compliant pin definition We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. ROG STRIX B650E-F GAMING WIFI 1-17...
  • Page 30 S/PDIF Out header This header is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this header, then install the module to a slot opening at the back of the system chassis. SPDIF_OUT PIN 1 The S/PDIF module is purchased separately.
  • Page 31 The chassis intrusion sensor or switch sends a high-level signal to the header when a chassis component is removed or replaced, the signal is then generated as a chassis intrusion event. ROG STRIX B650E-F GAMING WIFI 1-19...
  • Page 32 Thermal Sensor header The Thermal Sensor header allows you to connect a sensor to monitor the temperature of the devices and the critical components inside the motherboard. Connect the thermal sensor and place it on the device or the motherboard’s component to detect its temperature.
  • Page 33 The add-on Thunderbolt™ I/O card and Thunderbolt™ cables are purchased separately. • Please visit the official website of your purchased Thunderbolt™ card for more details on compatibility. Ensure to install the Thunderbolt™ series card to a PCIe slot from PCH. ROG STRIX B650E-F GAMING WIFI 1-21...
  • Page 34 BIOS FlashBack™ LED The BIOS FlashBack™ LED lights up or blinks to indicate the status of the BIOS FlashBack™. FLBK_LED BIOS FlashBack™ Refer to the BIOS update utility section for more information on the feature. Q-LEDs The Q-LEDs check key components (CPU, DRAM, VGA, and booting devices) during the motherboard booting process.
  • Page 35 8-pin Power Plug LED The 8-pin Power Plug LED lights up to indicate that the 8-pin power plug is not connected. PLUG_8PIN_PWR ROG STRIX B650E-F GAMING WIFI 1-23...
  • Page 36 Chapter 1: Product Introduction 1-24...

  • Page 37: Chapter 2: Basic Installation

    DO NOT force the CPU into the socket to prevent bending the pins and damaging the CPU. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.
  • Page 38 Chapter 2: Basic Installation...

  • Page 39: Cooling System Installation

    CPU before you install the cooling system, if necessary. We recommend using AM5 compatible coolers with stock AM5 backplate to prevent potential damages to the pins in the socket. CPU heatsink and fan assembly Type 1 ROG STRIX B650E-F GAMING WIFI...
  • Page 40 CPU heatsink and fan assembly Type 2 When using this type of CPU fan, remove the screws and the retention module only. Do not remove the plate on the bottom. Chapter 2: Basic Installation...
  • Page 41 To install an AIO cooler If you wish to install an AIO cooler, we recommend installing the AIO cooler after installing the motherboard into the chassis. AIO_PUMP CPU_FAN CPU_OPT ROG STRIX B650E-F GAMING WIFI...

  • Page 42: Dimm Installation

    2.1.3 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 43: Installation

    Use a Phillips screwdriver when removing or installing the screws or screw stands mentioned in this section. • The M.2 is purchased separately. Remove the screws from the M.2 heatsink. Lift and remove the heatsink. ROG STRIX B650E-F GAMING WIFI...
  • Page 44 Install your M.2 to your M.2 slot. The steps may differ between installing M.2 of different lengths, please refer to the different types and their installation steps below: • To install an M.2 to M.2_3 slot For 2242, 2260, 2280, 22110 length Rotate and adjust the M.2 Q-latch so that the handle points away from the M.2 slot.
  • Page 45 Rotate and adjust the M.2 Q-latch so that the handle points away from the M.2 slot. Install your M.2 to the M.2 slot. Rotate the M.2 Q-Latch clockwise to secure the M.2 in place. OPTIONAL OPTIONAL ROG STRIX B650E-F GAMING WIFI...
  • Page 46 Remove the plastic film from the thermal pad on the bottom of the heatsink. If the thermal pad on the M.2 heatsink becomes damaged, we recommend replacing it with the bundled thermal pad or a thermal pad with a thickness of 1.25mm. Replace the heatsink.

  • Page 47: Motherboard Installation

    I/O panel. Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT over tighten the screws! Doing so can damage the motherboard. ROG STRIX B650E-F GAMING WIFI 2-11...

  • Page 48: Atx Power Connection

    2.1.6 ATX power connection • DO NOT connect the 4-pin power plug only, the motherboard may overheat under heavy usage. • Ensure to connect the 8-pin power plug, or both the 8-pin and 4-pin power plugs. Chapter 2: Basic Installation 2-12...

  • Page 49: Sata Device Connection

    2.1.7 SATA device connection ROG STRIX B650E-F GAMING WIFI 2-13...

  • Page 50: Front I/O Connector

    2.1.8 Front I/O connector To install front panel connector To install USB 3.2 Gen 2 Type-C ® connector USB 3.2 Gen 2 Type-C ® This connector will only fit in one orientation. Push the connector until it clicks into place. To install USB 2.0 connector To install USB 3.2 Gen 1 connector USB 2.0...

  • Page 51: Expansion Card Installation

    2.1.9 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards ROG STRIX B650E-F GAMING WIFI 2-15...
  • Page 52 To install Thunderbolt™ series card 6-pin PCIe power connector USB Type-C ® port connects to Thunderbolt devices MiniDP in port connects to DP out port on the motherboard or a VGA card USB 2.0 header Thunderbolt™ header Ensure to install the Thunderbolt™ series card to a PCIe slot from PCH. •...
  • Page 53 To release an expansion card using the PCIe Slot Q-Release: Slightly lift the expansion card with one hand and press the PCIe Slot Q-Release button with the other hand. This should release the expansion card so that you can remove it with ease. ROG STRIX B650E-F GAMING WIFI 2-17...

  • Page 54: Wi-Fi Moving Antenna Installation

    2.1.10 Wi-Fi moving antenna installation Installing the ASUS Wi-Fi moving antenna Connect the bundled Wi-Fi moving antenna connectors to the Wi-Fi ports at the back of the chassis. • Ensure that the Wi-Fi moving antenna is securely installed to the Wi-Fi ports.

  • Page 55: Bios Update Utility

    • Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. ROG STRIX B650E-F GAMING WIFI...

  • Page 56: Motherboard Rear And Audio Connections

    For more information on using the BIOS FlashBack™ feature, please refer to https://www.asus.com/support/, or by scanning the QR code below. Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors DisplayPort USB 3.2 Gen 1 Type-A ports E1, E2, E3, and E4 USB 3.2 Gen 2 Type-A ports 2 and 11...

  • Page 57: Audio I/O Connections

    (Rear panel) Pink – – – – (Rear panel) Black – Rear Speaker Rear Speaker Rear Speaker (Rear panel) Orange – – Center/ Center/ (Rear panel) Subwoofer Subwoofer 2.3.2 Audio I/O connections Audio I/O ports ROG STRIX B650E-F GAMING WIFI 2-21...
  • Page 58 Connect to Headphone and Mic Connect to 2-channel Speakers Connect to 4-channel Speakers Chapter 2: Basic Installation 2-22...
  • Page 59 Connect to 5.1-channel Speakers Connect to 7.1-channel Speakers ROG STRIX B650E-F GAMING WIFI 2-23...

  • Page 60: Starting Up For The First Time

    Starting up for the first time After making all the connections, replace the system case cover. Ensure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector. Turn on the devices in the following order: Monitor External storage devices (starting with the last device on the chain)

  • Page 61: Chapter 3: Bios And Raid Support

    Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 62: Bios Setup Program

    BIOS Setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST).

  • Page 63: Asus Ez Flash 3

    ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.

  • Page 64: Asus Crashfree Bios 3

    ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.

  • Page 65: Raid Configurations

    For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code. RAID definitions Volume provides the ability to link-together storage from one or several disks, regardless of the size of the space on those disks.
  • Page 66 Chapter 3: BIOS and RAID Support...

  • Page 67: Appendix

    RF exposure compliance. HDMI Trademark Notice The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. ROG STRIX B650E-F GAMING WIFI...
  • Page 68 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 69 Tenez cet appareil à distance du ventre des femmes enceintes et du bas-ventre des adolescents. ROG STRIX B650E-F GAMING WIFI...
  • Page 70 ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
