Wireless
by Lutron
Advanced Installation Guide
Advanced Installation Guide
Dimmer &
ELV+ Dimmer
PRO dimmer
PD-5NE
PD-6WCL/PD-10NXD
Caséta Diva
Caséta Claro
Smart Dimmer
Smart Switch
DVRF-6L
DVRF-5NS
Thank you for purchasing Caséta Wireless from Lutron. This document will guide you through several additional
installation topics beyond those covered in the quick-start guide included with your product.
Table of Contents
3-Way Installation -
With a Pico Remote Control
Dimmer with Pico Remote Control (PD-6WCL):
Switch with Pico Remote Control (PD-5WS-DV):
PRO Dimmer with Pico Remote Control (PD-10NXD):
Neutral Switch with Pico Remote Control (PD-5ANS / PD-6ANS):
ELV+ Dimmer with Pico Remote Control (PD-5NE):
Fan Control with Pico Remote Control (PD-FSQN):
Diva Smart Dimmer with Pico Remote Control (DVRF-6L):
Claro Smart Switch with Pico Remote Control (DVRF-5NS):
With a Mechanical Toggle Switch
Switch with Mechanical Toggle Switch (PD-5WS-DV):
PRO Dimmer with Mechanical Toggle Switch (PD-10NXD):
Neutral Switch with Mechanical Toggle Switch (PD-5ANS / PD-6ANS):
Diva Smart Dimmer with Mechanical Toggle Switch (DVRF-6L):
Claro Smart Switch with Mechanical Toggle Switch (DVRF-5NS):
With a Wired Accessory
Diva Smart Dimmer with a Claro Smart Accessory Switch (DVRF-6L/DVRF-AS):
Claro Smart Switch with a Claro Smart Accessory Switch (DVRF-5NS/DVRF-AS):
Multi-Location Installation
With a Pico Remote Control
Dimmer with Pico Remote Controls (PD-6WCL):
PRO Dimmer with Pico Remote Controls (PD-10NXD):
Switch with Pico Remote Controls (PD-5WS-DV):
Neutral Switch with Pico Remote Controls (PD-5ANS / PD-6ANS):
ELV+ Dimmer with Pico Remote Controls (PD-5NE):
Fan Control with Pico Remote Controls (PD-FSQN):
Diva Smart Dimmer with Pico Remote Controls (DVRF-6L)
Claro Smart Switch with Pico Remote Controls (DVRF-5NS)
With a Wired Accessory
Diva Smart Dimmer with Claro Smart Accessory Switch (DVRF-6L / DVRF-AS):
Claro Smart Switch with with Claro Smart Accessory Switch (DVRF-5NS / DVRF-AS):
Plug-in
lamp dimmer
PD-3PCL
Caséta Claro Smart
Accessory Switch
DVRF-AS
If you have two switches controlling your lights, follow this procedure to install your dimmer or switch
............................................................................................................ Page 3 - 6
.......................................................................................................... Page 7 - 10
- If you have three or more switches controlling your lights, follow this procedure to
install your dimmer or switch
.......................................................................................................... Page 58 - 62
Switch
PD-5WS-DV /
PD-5ANS / PD-6ANS
................................................................................................. Page 11 - 14
.............................................................................. Page 15 - 18
..................................................................................................... Page 19 - 22
..................................................................................................... Page 23 - 26
......................................................................................... Page 27 - 30
...................................................................................... Page 31 - 34
................................................................................................ Page 35 - 37
........................................................................................ Page 38 - 40
..................................................................... Page 41 - 43
................................................................................ Page 44 - 46
............................................................................. Page 47 - 49
............................................................................................... Page 63 - 67
........................................................................................................ Page 68 - 72
............................................................................ Page 73 - 77
................................................................................................... Page 78 - 82
................................................................................................... Page 83 - 87
......................................................................................... Page 88 - 92
...................................................................................... Page 93 - 97
1
Fan Control
PD-FSQN
.................................................... Page 50 - 53
................................................. Page 54 - 57
....................................................... Page 98 - 102
............................................ Page 103 - 107
(continued on next page)
0301710l 11/2022
Motion Sensor
PD-OSENS /
PD-VSENS
