Related Manuals for Toshiba BMS-IFKX0AWR-E
Summary of Contents for Toshiba BMS-IFKX0AWR-E
- Page 1 Installation Manual KN Interface Model name: BMS-IFKX0AWR-E English...
- Page 2 • Follow the instructions on the user's manual for configuring and commissioning the interface. See below how to obtain the user's manual and the ETS database. NOTE The cable used for connection of BMS-IFKX0AWR-E to A B bus can be any two-core cabtyre cable, the maximum distance for bus A B is 50 meters, consult the manual of the Hydro unit for more details.
- Page 3 KN Interface Installation Manual Dimensions External dimensions Wall mount During installation, secure the metal plate and mold case (bottom) together with screws. After wiring, attach the mold case (top), install the metal plate cover, and secure with a screw. Secure with screws Mold case (bottom) (2 locations) Mold case (top)
- Page 4 TOSHIBA CARRIER EUROPE S.A.S Route de Thil 01120 Montluel France DEB2019101-1...
