- Page 1 Owner’s Manual SKv2-1500.1D SKv2-2500.1D SKv2-3500.1D SKv2-4500.1D SKv2-1300.2AB SKv2-100.4AB SKv2-200.4D SOUND QUALITY AMPLIFIER...
-
Page 2: Design Features
1. INTRODUCTION Congratulations and thank you for purchasing Skar audio amplifiers, the logical choice in mobile audio amplification. Your amplifiers have been designed and engineered with the highest quality components and top of the line workmanship to help you reach the superior sound you are after. -
Page 3: Controls And Connections
3-2. Multi-channels specification FEATURES SKv2-1300.2AB SKv2-100.4AB SKv2-200.4D Power @ 4ohm 330W x 2 110W x 4 200W x 4 Power @ 2ohm 530W x 2 165W x 4 320W x 4 Power @ 1ohm 700W x 2 Power @ 4ohm mono 1060W x 1 340W x 2 640W x 2... - Page 4 4-2. 2channel control RCA JACK INPUT X-OVER SLECTOR SWITCH ( ON / OFF ) Low Level Rca Input will accept the signal from the output of Selected x-over is in effective. head units. Plug in Rca jack cables from the head unit. LOW PASS FILTER ( 50Hz ~ 5KHz @ 12dB / Oct slope ) RCA JACK OUTPUT The crossover features a steep 12dB oct slope...
-
Page 5: Power Connection
12 gauge. Connect carefully the subwoofer speakers by checking the impedance 1ohm or 2ohm for link connection to SKv2-1500.1D, SKv2-2500.1D, SKv2-3500.1D & SKv2-4500.1D. Skv2-1300.2AB as 1ohm stereo or 2ohm mono stable. SKv2-100.4AB and SKv2-200.4D as 2ohm stereo or 4ohm mono stable. - Page 6 4-5. Seaker connection Digital monoblock speaker connection 1. 4~ 1 ohms Caution !! Skv2-1500.1D, Skv2-2500.1D, SKv2-3500.1D and SKv2-4500.1D Minimum working impedance is 1ohm as single unit. Impedance lower than 1ohm can damage the amplifiers Digital monoblock speaker connection 2 4~ 2 ohms...
- Page 7 SKv2-1300AB speaker connection 1. 4~ 1 ohms 4~ 1 ohms 4~ 1 ohms 4~ 1 ohms Caution !! SKv2-1300.2 Minimum working impedance is 1ohm stereo or 2ohm mono. SKv2-1300AB speaker connection 2. 4~ 2 ohms...
- Page 8 4channel speaker connection 1. Caution !! SKv2-100.4AB & SKv2-200.4D Minimum working impedance is 2ohm STEREO or 4ohm mono. 4channel speaker connection 12. 8 ~ 4 ohms...
- Page 9 5. Strappable connection Strappable connection makes two of same amplifiers linked to 2ohm. Strappable connection makes the power double than their’s each 1ohm power. Please read the following connection and diagram carefully to make correct connection. INPUT CONNECTION ; Step 1. Connect the Master amplifier to the head-unit and set its output master / input slave switch to output master.
- Page 10 +12V SOURCE Remote turn on MASTER AMPLIFIER Ground BATTERY 8 ~ 2 ohms SLAVE AMPLIFIER Ground BATTERY...
- Page 11 PROTECTION @ Please check overload, overheat ( thermal ), short and voltage, DC offset. @ Minimum working impedance is 1 ohm for SKv2-1500.1D, SKv2-2500.1D, SKv2-3500.1D & SKv2-4500.1D as single unit and 2 ohm stable for strappable connection. Skv2-1300.2AB is 1ohm stereo or 2ohm mono.
