TECH SHEET - DO NOT DISCARD
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or
electrical shock.
NOTE: Schematic shows door latch switch in the COOK
position with oven door open and oven off.
L1
BK
OVEN CONTROL LCC180
OVEN LIGHT (K2)
POWER SUPPLY
LATCH MOTOR (K1)
CON2-4
BK
BROIL (K6)
SURFACE BURNER IGNITION SWITCH
BK
BK
SOFTWARE COPYRIGHTED. THIS PRODUCT IS COVERED BY ONE OR MORE OF THE FOLLOWING PATENTS: U.S. PATENT NOS.
4,852,544
5,175,413
5,422,460
4,974,804
5,185,047
5,424,512
5,008,516
5,321,229
5,438,180
5,064,998
5,349,162
5,441,036
5,138,137
5,378,874
5,491,314
5,142,125
5,382,552
5,571,433
FOR SERVICE TECHNICIAN'S USE ONLY
CON3-3
Y
CON3-1
BU
CON3-5
GY
CON3-8
V
CON3-10
V
CON1-6
BK
CON1-1
W
CON1-4
BR
BAKE (K7)
CON2-7
CON2-1
R
5,571,434
5,808,278
5,910,265
5,620,623
5,810,576
5,918,589
5,694,916
5,813,320
5,924,857
5,749,388
5,841,112
5,928,543
5,756,970
5,856,654
5,961,311
5,767,488
5,881,710
5,967,634
AND OTHER PATENTS PENDING.
Caution: Label all wires prior to disconnection
when servicing controls. Wiring errors can
cause improper and dangerous operation.
Verify proper operation after servicing.
LEGEND
CONNECTION
COMPONENT
(SPLICE)
TERMINAL
DOOR SWITCH
DOOR POSITION SWITCH
DOOR LATCH SWITCH
OVEN TEMP SENSOR
R
BAKE VALVE
BROIL VALVE
OR
BU
R/W
BU/W
R/BU
5,983,888
6,087,944
6,263,782
6,403,929
6,008,478
6,097,000
6,349,717
6,437,294
6,017,211
6,111,231
6,363,971
6,509,551
6,035,848
6,163,017
6,375,150
6,545,251
6,043,461
6,201,222
6,392,204
6,570,136
6,079,756
6,232,584
6,394,081
6,614,006
CURRENT
NO
DIRECTION
CONNECTION
P1-2 = CONNECTOR P1 POSITION 2
GY
GY
OVEN LIGHT ASSY 40W
LATCH MOTOR 4W
M M
J1-1
J1-4
DSI BOARD
BURNER
J1-2
BURNER
BURNER
J1-3
BURNER
J1-6
J1-7
BROIL
J1-9
BAKE
J1-10
GND
6,663,009
6,722,356
6,904,969
6,666,676
6,734,403
6,935,330
6,693,262
6,784,404
6,698,417
6,841,761
6,698,923
6,870,138
6,700,101
PART NO. 9762973 REV. A
PAGE 1
IN LINE
CONNECTION
N
W
W
W
W
GND
