GE
TRANSPORTATION
SYSTEMS
GLOBAL SIGNALING DIVISION
J3-Pin
Signal
2
Rx Data
3
TX Data
5
Com
6.4.5.
J4 4-Pin Power Connector
J4 is used for primary and secondary input voltages for the 12RII-LC and 12RII-SR radio systems. The J4 cable plugs into J1-
J4 on the Power Supply Board. J4 typical signal interfaces are shown in the table below.
J4-Pin
Signal
A
+74VDC
B
13 VDC Com
C
-74VDC
D
+13 VDC
6.4.6.
J5 23-Pin Power & Control
J5 is used for input power, control and audio signal interfaces on the 12RII-RC radio. The J5 cable assembly plugs into J1-J4
on the Power Supply Board and J5 & J6 on the Radio Control Board.
The Following tables are the currently defined power interfaces used on 74V, 37V and 13V AAR Remote Control Radio
systems.
Standard 74 & 37 Volt Power Input.
J5-Pin
Signal
1
-
2
* +VIN
3
* -VIN
4
+13VDC
5
13V COM
* Radio must be specified as either 74V or 37V.
Alternate 37V Power Input.
J5-Pin
Signal
1
-
2
3
* -VIN
4
* +VIN
5
13V COM
* These are for an alternate 37V Battery Interface.
13V Power Input.
J5-Pin
Signal
1
13V RTN
2
+13V
3
-
4
+13VDC
5
13V COM
COE Communications Engineering Document
Author:
Keith Gilbertson
Date:
3/08/02
Title:
12RII FCC TECHNICAL MANUAL
J3 PROGRAM SIGNAL INTERFACE
RS-2323 Serial Receive Data Input
RS-2323 Serial Transmit Data Output
Signal Common (common to radio chassis).
J4 4-PIN POWER SIGNAL INTERFACE
Primary isolated input voltage
Common (radio chassis).
Primary isolated input voltage return.
Secondary (Test) radio input voltage.
J5 23-PIN POWER SIGNAL INTERFACE (STD)
Isolated input voltage
Isolated input voltage return
13V Output
13V Common (radio chassis)
J5 23-PIN POWER SIGNAL INTERFACE (37V ALT.)
Isolated input voltage return
Isolated input voltage
13V Common (radio chassis)
J5 23-PIN POWER SIGNAL INTERFACE (13V Only)
Non-Isolated input voltage return
Non-Isolated Input voltage
13V Output
13V Common (radio chassis)
Description
Description
Description
Description
Description
Rev:
A
Pag
16
33
of
e:
Mating Connector
RCB
J2-7
RCB
J2-8
RCB
J2-9
Mating Connector
PSB
J1 / J2
PSB
J4
PSB
J2 / J1
PSB
J3
Mating Connector
-
-
PSB
J1
PSB
J2
PSB
J3
PSB
J4
Mating Connector
-
-
-
-
PSB
J2
PSB
J1
PSB
J4
Mating Connector
PSB
J1
PSB
J2
-
-
PSB
J3
PSB
J4
