Wavelink Avalanche Enabler Configuration

Related manual: Using Wavelink Avalanche on LXE Windows Computers.
If the user is NOT using Wavelink Avalanche to manage their mobile device, the Enabler
should not be installed on the mobile device.

Briefly . . .

The Wavelink Avalanche Enabler installation file is loaded on the mobile device by LXE;
however, the device is not configured to launch the installation file automatically. The installation
application must be run manually the first time Avalanche is used. After the installation
completes, the Enabler begins normal performance. The Enabler is, by default, an auto-launch
application. This behavior can be modified by accessing the Avalanche Update Settings panel
through the Enabler Interface.
Note:
Note:

Enabler Install Process

Doubletap the Avalanche Enabler CAB file in the System folder. The filename is
LXE_MX3X_ENABLER.CAB.

Enabler Uninstall Process

To remove the LXE Avalanche Enabler from a Windows CE mobile device:
The Avalanche folder cannot be deleted while the Enabler is running. See Stop the Enabler
Service. If sharing errors occur while attempting to delete the Avalanche folder, warm boot the
mobile device, immediately delete the Avalanche folder, and then perform another warm boot.
Orphaned Packages
To prevent the enabler from restoring parameters, delete orphaned packages through the
Avalanche MC Console (refer to the Wavelink Avalanche Mobility Center User's Guide for details
and instruction).

Stop the Enabler Service

To stop the Enabler from monitoring for updates from the Avalanche MC Console:
1. Open the Enabler Settings Panels by tapping the Avalanche icon on the desktop.
2. Select File | Settings. Enter the password.
3. Select the Startup/Shutdown tab.
4. Select the "Do not monitor or launch Enabler" parameter to prevent automatic monitoring
5. Select Stop Monitoring for an immediate shutdown of all enabler update functionality
MX3Plus Reference Guide
LXE recommends serial communication with an MX3Plus be performed using the serial
port on the MX3Plus endcap rather than using a docking cradle serial port.
On LXE mobile devices with integrated scanners, the Scanner Wedge has primary
control of the serial ports and must be configured properly to allow the Enabler to access
the serial ports.
•
Delete the Avalanche folder located in the System folder.
•
Warm boot the mobile device.
upon startup.
upon exiting the user interface.
Wavelink Avalanche Enabler Configuration
