- Page 1 ORIGINAL INSTRUCTIONS RIDE-ON LAWN MOWER Model : RAC62PRRS WARNING: Please read all instructions carefully before operating the machine! BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France Made in PRC...
- Page 2 Dear Customer, Thank you for having chosen one of our products. We hope that you will get complete satisfaction from using your new machine and that it will fully meet all your expectations. This manual has been compiled in order that you may get to know your machine and to be able to use it safely and efficiently.
-
Page 3: How To Read The Manual
1.1 HOW TO READ THE MANUAL This manual describes various versions of the machine, which mainly differ in: – type of transmission: with either mechanical gear change or continuous speed converter. – the inclusion of components or accessories which may not be available in some areas; –... -
Page 4: Operation
A) TRAINING 1) Read the instructions carefully. Be familiar with the controls and how to use the equipment properly. 2) Never let children or people unfamiliar with these instructions use the machine. Local regulations can restrict the age of the user. 3) Never mow while people, especially children, or pets are nearby. -
Page 5: Maintenance And Storage
2) Mow only in daylight or good artificial light. 3) Before starting the engine, disengage the blades and shift into neutral. 4) Do not use on slopes of more than 10° (17%). 5) Remember there is no such thing as a “safe” slope. Travelling on grass slopes requires particular care. - Page 6 7) If the fuel tank has to be drained, this should be done outdoors. 8) When the machine is to be stored or left unattended, lower the cutting deck. Improper maintenance can reduce life of the tool and create accident and damages. Always bring maintenance.
-
Page 7: Safety Labels
It is suitable only for private use in a garden or plot. Lawnmowers designed for private plots or gardens are those used for the maintenance of grassy areas and private lawns and should not be used in public areas, parks, sports, agricultural or forest areas. 1.3 SAFETY LABELS Your machine must be used with care. -
Page 8: Identification Of The Machine
Danger! Do not near the operational machine WARNING! Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade(s) can amputate hands and feet. Danger ! Electrical shock ! This symbol indicates the surface is very hot and not touching Guaranteed sound power level 2.1 IDENTIFICATION OF THE MACHINE The identification label located under the seat has the essential data of each machine. -
Page 9: Fitting The Steering Wheel
For storage and transport purposes, some components of the machine are not installed in the factory and have to be assembled after unpacking. Follow the instructions below. The machine is supplied without engine oil or fuel. Before starting the engine, fill with oil and fuel following the instructions given in the engine manual. -
Page 10: Fitting The Seat
3.3 FITTING THE SEAT Fit the seat (1) onto the plate (2) using the screws (3) 3.4 FITTING THE BLADE ENGAGEMENT LEVER Fit the end of the lever (1) on the projecting part of the pin (2) and fix it all by tightening the screw (3) and nut (4) 3.5 FITTING THE GRASS-CATCHER Identify the screws to be used by following the drawing that shows them in... - Page 11 3.6 FITTING THE DEFLECTOR...
-
Page 12: Steering Wheel
4.21 4.6.1 4.12 4.1 STEERING WHEEL Turns the front wheels. 4.2 CLUTCH / BRAKE PEDAL This pedal has a double function: during the first part of its travel it acts as a clutch, engaging and disengaging drive to the wheels, and in the second part it works the brake. Do not keep the pedal half way of clutch engagement or disengagement, as this can cause overheating and damage the... -
Page 13: Parking Brake Lever
4.3 PARKING BRAKE LEVER This lever stops the machine from moving when it has been parked. There are two positions: –The brake is engaged by pressing the pedal (☛4.2) right down and moving the lever to position «B». When you take your foot off the pedal it will be blocked by the lever in the down position. -
Page 14: Accelerator Lever
4.6 LEVER ENGAGEMENT AND BRAKE OF BLADE The lever has two positions, as shown on the plate: –If the blade is engaged when safety conditions have not been complied with, the engine shuts down and cannot be restarted ( ☛5.2). –... -
Page 15: Safety Recommendations
4.21 PULL START HANDLE To start the engine, take the starter cable handle and give it a firm tug. Then put the handle back in its seat, guiding the cable as it automatically rewinds. 4.22 ACCELERATOR LEVER It regulates the rpm and stops the engine. The positions are indicated on the plate showing the following symbols: «OFF»... -
Page 16: Why The Safety Devices Cut In
consequently be liable for all and any damage or injury to himself or others. Examples of improper use may include, but are not limited to: – transport people, children or animals on the machine or on a trailer; – tow or push loads; –... -
Page 17: Preliminary Operations Before Starting Work
a) The engine must only be started in the following conditions: – the transmission is in “neutral”; – the blade is not engaged; – the operator is seated or the parking brake is engaged. b) The engine stops when: – the operator leaves his seat when the blade is engaged; –... - Page 18 5.3.3 Filling with oil and fuel Refueling should be carried out in an open or well-ventilated area with engine stopped. Always remember that petrol fumes are inflammable. DO NOT TAKE A NAKED FLAME TO THE TANK’S OPENING IN ORDERS TO SEE THE TANK’S CONTENTS AND DO NOT SMOKE WHEN REFUELLING.
-
Page 19: Using The Machine
Do not drip petrol onto the plastic parts to avoid ruining them. In the event of accidental leaks, rinse immediately with water. The warranty does not cover for damage to plastic parts of the bodywork or the engine caused by petrol. 5.3.4 Fitting the protections at the exit (grass catcher) Never use the machine without having fitted the exit protection! -
Page 20: Starting And Moving Without Mowing
To start the engine: 1. sit on the seat and press the brake pedal right down(☛4.3); 2. put the transmission into neutral («N») (☛ 4.4); 3. disengage the blade (☛ 4.6); 4. for cold starting, put the accelerator lever in the «CHOKE» position (if fitted) as shown on the label (☛... -
Page 21: Grass Cutting
Reach the desired operating speed using the accelerator and gear lever. To change gear, the clutch must always be used by pushing the pedal (☛4.2). The pedal must be released gradually as sudden engagement may cause tipping up and loss of control of the vehicle. Do not suddenly release the pedal and do not start moving with the gear shift more than 1/3 of the way towards «F»... -
Page 22: Emptying The Grass-Catcher
To start cutting: 1. remove any foreign objects that could be hit by the blade (stones, branches, bones, wire etc.) and mark off the position of hidden elements that cannot be moved (roots, sprinklers etc.); 2. check that the grass-catcher is fitted properly; 3. -
Page 23: Unblocking The Collector Channel
5.4.7 Unblocking the collector channel This job must only be performed with the engine Turned off. If the collector channel gets blocked (due to accumulated grass cuttings filling up the grass-catcher or an excessively high speed with relation to the quantity of grass cuttings), you need to: 1. - Page 24 After each use, accurately clean the cutting deck to remove any grass remains or debris. Wear eye protection and keep people or animals away from the surrounding area when cleaning the cutting deck. a) When washing the inside of the cutting deck and the collector channel, the machine must be on firm ground: 1.
-
Page 25: Using On Slopes
5.5 USING ON SLOPES When mowing lawns on a slope, observe the maximum gradients already mentioned (max 10° - 17%) and move up and down but never across them. Take great care when changing direction that the highest wheels do not hit obstacles (such as stones, branches, roots, etc.) that may cause the machine to slide sideways, tip over or otherwise cause loss of control. -
Page 26: Advice On How To Obtain A Good Cut
5.7 ADVICE ON HOW TO OBTAIN A GOOD CUT 1. To keep a lawn green and soft with a good appearance, it should be cut regularly without damaging the grass. 2. It is always better to cut the grass when dry. 3. -
Page 27: Routine Maintenance
Never use the machine with worn or damaged parts. Faulty or worn-out parts must always be replaced and not repaired. Only use original spare parts: The use or non-original and/or incorrectly fitted parts will compromise the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is under no circumstance liable or responsible. -
Page 28: Interventions On The Machine
6.3 INTERVENTIONS ON THE MACHINE 6.3.1 Cutting deck alignment The cutting deck should be properly set to obtain a good cut. If the cut is uneven, check the tire pressure. If this is not sufficient to achieve an even cut, please contact your Dealer for the adjustment of the alignment of the cutting deck. - Page 29 6.3.4 Dismantling, replacing and remounting the blade Always wear work gloves when handling the blade. Damaged or bent blades must always be replaced; never try to repair them! ALWAYS USE MANUFACTURER'S GENUINE REPLACEMENT BLADES BEARING THE SYMBOL! Environmental protection should be a priority of considerable importance when using the machine, for the benefit of both social coexistence and the environment in which we live.
- Page 30 PROBLEM LIKELY CAUSE SOLUTION 1. The Starter motor runs but –faulty fuel supply –check the level in the tank (☛5.3.3) the engine does not start –check the wiring of the fuel open command –check fuel filter –faulty ignition –check that spark plug caps are firmly fitted –check that the electrodes are clean and have the correct gap 2.
- Page 31 Do not take on complicated repair work if you don't knowledge. The warranty is have the necessary equipment or the technical automatically voided and the manufacturer is not held responsible if repairs are done badly. Change Blade 1.Make sure there is no machine oil and gasoline in the tank, side lay the machine as the picture above.
- Page 32 Maximum noise and vibration levels Operator ear noise pressure level (according to regulation ISO 5395-1:2013, Annex F) ......79.6dB(A) – Measurement uncertainty (2000/14/EC) ...........2.5dB(A) Measured acoustic output level (according to directive ISO 5395-1:2013, Annex F) ….....…94.34dB(A) – Measurement uncertainty (2000/14/EC) ...........1.08 dB(A) Guaranteed acoustic output level (according to directive ISO 5395-1:2013, Annex F) …......98 dB(A) Vibration level...
-
Page 33: Declaration Of Conformity
ZI, 32 rue Aristide Bergès – 31270 Cugnaux – France Tel : +33 (0)5.34.502.502 Fax : +33 (0)5.34.502.503 declares that the machines: RIDE-ON LAWN MOWER RAC62PRRS 20211221246-20211221281 Serial No.: the people name holding the technical file：Mr. Olivier Patriarca have been designed in compliance with the following standards: EN-ISO 5395-1:2013+A1: 2018, EN-ISO 5395-3:2013+A1:2017+A2:2018 EN-ISO 14982：2009... -
Page 34: Warranty
12. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 35: Product Failure
13. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 36: Warranty Exclusions
14. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
