DELUXE CLOSET SYSTEM
Design Solutions Closet Organizer
11:01 AM
Page 1
Fits 5' to 10' wide closets
CAUTION: IMPORTANT SAFETY
INFORMATION:
Be sure all parts and appropriate fasten-
ers are used as instructed. Avoid over-
drilling pilot holes. Always wear safety
glasses/goggles and work safely with
hand tools. Do not use any parts as a lad-
der or step stool because injury could
result. Do not allow children to climb on
closet organizer as injury could result.
Stanley Deluxe Closet Organizer is
designed for easy installation but if you
have any questions about installing this
product please call our Toll-Free Help
Line.
Stanley Toll-Free Help Line:
1-800-647-8145 option 3 Monday-Friday
8am to 5pm EST.
BEFORE proceeding with installation,
read instructions carefully and check
to see that you have all the parts and
tools required. Call the Toll-Free Help
Line to replace any missing parts.
WARNING:
Drilling
Attempt to locate studs, pipes and wires
before proceeding. Drilling too deep can
result in damage to electrical lines, water
lines, duct work or other structural
obstructions that may lie behind the wall.
Personal injury or property damage could
result if any of these obstructions are
pierced.
©
Charlotte. NC 28269
™
2004 Stanley Home Décor
Part # 98-6303 9/04
