Parts of your Oven

External Air Vents
Oven Window
Pull Door Handle
Pull to open the door. Opening the door during cooking will
stop the cooking process without cancelling the program.
Cooking resumes after the door is closed and Start is pressed.
It is quite safe to open the door at any time during a cooking
program and there is no risk of microwave exposure.
Caution label is attached on the outside surface.
Note:
The illustration is for reference only.
1. Always refer to instructions for correct
accessories to use on all programs.
2. The roller ring and oven should be cleaned
frequently to prevent excessive noise.
3. Always operate the oven with the roller ring and
glass tray in place. They are the only
accessories used for MICROWAVE cooking.
4. Only use the glass tray specifically designed for
this oven. Do not substitute with any other
glass tray.
5. Do not cook directly on glass tray.
Always place food in a microwave safe dish.
6. If glass tray is hot, allow to cool before cleaning
or placing in water.
7. If food or utensils on the glass tray touch the
oven walls, this will cause the tray to stop
moving. It will then automatically rotate in the
opposite direction. This is normal. Open oven
door, reposition the food and restart.
8. The glass tray can rotate in either direction.
The maximum weight that can be placed on the
tray is 3 kg (6 lb. 10 oz.) (this includes total
weight of food and dish).
NN-CT655_YTEYUE.indb 10
Grill Element
Glass Tray
Roller Ring
9. While cooking by MICROWAVE or
COMBINATION the glass tray may vibrate. This
will not affect cooking performance.
10. The metal wire rack must ONLY be used as
directed for GRILLING, COMBINATION and
CONVECTION cooking. Never use this on
MICROWAVE only. Do not use if operating the
oven with less than 200 g (7 oz.) of food on a
manual COMBINATION program. FAILURE TO
USE ACCESSORIES CORRECTLY COULD
DAMAGE YOUR OVEN.
11. The wire rack is used to facilitate browning of
small dishes and help with the good circulation
of the heat.
12. When using the COMBINATION mode, never
place any aluminium or metal container directly
on wire rack. Always insert a glass plate or dish
between wire rack and the aluminium container.
This will prevent sparking that may damage the
oven.
En-10
Power Supply Cord
Power Supply Plug
Control Panel
Microwave Feed Guide
(Do not remove.)
High Wire Rack
Low Wire Rack
