Page 7: Product Introduction
BL101 downlink support: Modbus RTU Master, Modbus TCP Master, DL/T645, etc. BL101 uplink support: Modbus TCP, MQTT, OPC UA, Huawei Cloud IoT, Ali Cloud IoT, AWS IoT, ThingsBoard, Sparkplug B, King Pigeon Cloud and other protocols.
Page 8 Industrial IoT Gateway BL101 BL103 BL103 supports remote gateway management or configuration through OpenVPN channel. BL103 supports routing function as well as cascade switch data acquisition to acquire data from more industrial equipment, with fully functional software covering most application scenarios.
Page 9: Application Diagram
Industrial IoT Gateway BL101 BL103 1.2 Application Diagram Note: BL101 downlink can not acquire data from BACnet devices, uplink do not support BACnet/IP protocol. V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 10: Packing List
Industrial IoT Gateway BL101 BL103 1.3 Packing List Before installing and using BL103 gateway, please confirm that the following materials are in the box. Please contact sales representative if any of the items missing or damaged. The following pictures are for reference only, the actual product may be different from the picture because of the updating, please refer to the actual product.
Page 11 Industrial IoT Gateway BL101 BL103 2 x Wall-Mounting Clip Kit(Optional, Please noted if you need)  1 x Din Rail Mounting Clip Kit(Optional)  1 x User Manual(PDF)  Note: Please scan the card QR code on the card to download it 1 x SIM card eject pin ...
Page 12: Features
Downlink support: Modbus RTU Master, Modbus TCP Master, DL/T645,  BACnet/IP, BACnet MS/TP, and other protocols. Uplink support: Modbus TCP, MQTT, OPC UA, BACnet/IP, HUAWEI Cloud,  Alibaba Cloud, AWS, ThingsBoard, Sparkplug B, King Pigeon Cloud, and others. 9-36V DC power supply with terminal wiring, and 2 power input interfaces ...
Page 13: Technical Parameters
Industrial IoT Gateway BL101 BL103 1.5 Technical Parameters Category Parameters Description Processor Main frequency 300Mhz System Storage 128MB(can be extended to 1G) Memory 64MB Input Voltage DC 9～36V Power Power Normal: 85mA@12V, Max: 117mA@12V Supply Consumption Wiring Support reverse wiring prevention protection Specification 2 x RJ45, 10/100Mbps, Adaptive MDI/MDIX。...
Page 14 Industrial IoT Gateway BL101 BL103 FDD-LTE:B2,B4,B12 GSM/EDGE:850,900,1800MHz WCDMA:B1,B2,B5,B8 L-AU FDD-LTE:B1,B3,B4,B5,B7,B8,B28 TDD-LTE:B40 WCDMA:B2,B4,B5 L-AF FDD-LTE:B2,B4,B5,B12,B13,B14,B66,B71 GSM:900,1800 CAT-1 FDD-LTE:B1,B3,B5,B8 TDD-LTE:B34,B38,B39,B40,B41 Always on when powered on, flickering when the system is running, and goes off when the system is not running. Flickering when communicating with Ethernet,...
Page 15: Model List
√ √ √ √ √ BL103Pro Note： Difference Between BL101 and BL103 BL103 BACnet IoT gateway add BACnet protocol compare to BL101 Modbus IoT gateway, the hardware of these two models is the same. V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 16: Hardware Description
Industrial IoT Gateway BL101 BL103 2 Hardware Description 2.1 Outline Dimension V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 17: Power Supply Interface
Industrial IoT Gateway BL101 BL103 2.2 Power Supply Interface 2 Channels 9-36V DC power input with reverse connection protection 2.3 SIM and SD Card Slot Make sure the device is powered off when inserting or removing the SIM card, then put the card eject pin into the card slot hole, and press slightly to push the card slot out.
Page 18: Antenna Connection Port
Industrial IoT Gateway BL101 BL103 2.6 4G Antenna Connection Port Connecting 4G Antenna 2.7 LED Indicator Light LED Indicator Introduction Item Status Description Flickering Running Normally Running Equipment Failure Flickering Ethernet working Ethernet Always on 4G network working No network...
Page 19: Reset Button
Industrial IoT Gateway BL101 BL103 2.8 Reset Button When the gateway is running normally, use the card eject pin to continuously press the Reset reset button for about 10 seconds until the RUN indicator goes off, the gateway reboots to restore the factory default settings.
Page 20: Wan And Lan
Industrial IoT Gateway BL101 BL103 2.10 WAN and LAN Ethernet Port Indicator Color Status Description Network Always on 100Mbps mode Green Speed 10Mbps mode Always on Network Connected Network Yellow Flickering Data is transmitting Link Network Disconnected 3 Installation Gateway can be places on flat surface, mounted on the wall, and DIN Rail Mounted 3.1 Wall-Mounting(Optional)
Page 21: Din Rail Mounting(Optional)
Industrial IoT Gateway BL101 BL103 3.2 DIN Rail Mounting(Optional) DIN Rail Mounting Installation Finished 4 Configuration Software Instructions 4.1 Login to Configuration Software Connect BL103 to the router or switch through WAN port with a standard cross or direct connection network cable. The IP of router or switch cannot be the same as gateway IP 192.168.3.1, WAN and LAN of gateway cannot in the same local area network, and make...
Page 22: Open Configuration Software
Industrial IoT Gateway BL101 BL103 4.1.1 Open Configuration Software Double click“ ”to execute BL103 configuration software，Shown as below： 4.1.2 Search for Gateway Click "Search" and all devices in the same local area network with the PC will appear. For example, WAN port is connected to the switch, PC and gateway are in the same local area network, and the gateway whose IP is 192.168.1.196 will be found.
Page 23: Connecting Gateway
Industrial IoT Gateway BL101 BL103 4.1.3 Connecting Gateway Choose the gateway device you want to configure, and double-click it(For example: double-click the gateway device whose IP is: 192.168.1.196) to enter the gateway device configuration interface. You can enter the IP and directly connect to log in if there is no display device because of the network environment.
Page 24: Configuration Instructions
Industrial IoT Gateway BL101 BL103 4.2 Configuration Instructions 4.2.1 System Features System Function Item Description Search for all BL103 gateways in the same local area network Search Clear Open a new default configuration file Import Import gateway configuration file Export...
Page 25 Industrial IoT Gateway BL101 BL103 Help Under development About Software version, Issue date, Firmware upgrade information Basic Information of BL103 Gateway Item Description Name BeiLai Gateway. Can be customized Time Local time when reading the gateway Model Gateway device model...
Page 26: Advanced Settings
Industrial IoT Gateway BL101 BL103 4.2.2 Advanced Settings The private network setting is to allow the dedicated Ethernet or dedicated 4G network to set the IP that can be used or the server that can be connected. If it is an ordinary Ethernet or 4G network, no settings are required.
Page 27: Com Port Introduction
Description Default Select from "Collection", "Pass Collection Mode Selection through", "Modbus RTU to TCP" Select from "Modbus", Modbus Device Brand "BACnet"(No BACnet option for BL101) Device Select slave device according to Modbus RTU Protocol Model selected brand Settings To set the device command...
Page 28: Add Com Port Devices
Industrial IoT Gateway BL101 BL103 Select from None, Even, Odd None Parity Bit Confirm COM configuration Cancel Cancel COM configuration 4.2.3.2 Add COM Port Devices Right click COM1 and click Add to enter device configuration box. Double click it to show added device configuration information.
Page 29: Add Com Port Device Data Point
Industrial IoT Gateway BL101 BL103 Note: Device attributes are set according to the selected protocol. For example, device brand is Modbus, set attributes as below table. Device Information Item Description Default Device Name Name the data collecting device Data Collecting Device Modbus...
Page 30 Industrial IoT Gateway BL101 BL103 Right click "Add" to add the next data point. You can also right click to delete the data, or double click the data point to edit the data. Variable Properties Item Description Variable Name Name the Added Data point Variable Key The MQTT identifier of the data point, can be filled in arbitrarily.
Page 31: Lan Port Introduction
Industrial IoT Gateway BL101 BL103 Status", "02 Input Status", "03 Holding Registers", "04 Input Registers". Address Address of the collected data point Select "Boolean" for Boolean, numeric type selected from "16-bit unsigned integer", "16-bit signed integer", "32-bit unsigned Data Type integer", "32-bit signed integer", "32-bit single-precision floating...
Page 32: Add Lan Port Device
Industrial IoT Gateway BL101 BL103 automatically assign IP addresses and routing functions are disabled by default. Note: If the LAN port is connected to the switch, the switch cannot be connected to the network cable of other network segments. Ethernet Settings...
Page 33 LAN port. It will take effect after power off and restarting. Device Port Set the port number of the device on the LAN port Device Brand Select from "Modbus", "BACnet", (BL101 has no "BACnet" V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 34: Add Lan Port Device Data Point
Set command interval time and device return timeout time, click the And Time out button next to the device model to set it. Device address Only available when the device brand is "BACnet" 16-bit Data Type Select from "AB", "BA", only available when the device brand is "Modbus".
Page 35: Wan Port Introduction
Industrial IoT Gateway BL101 BL103 4.2.5 WAN Port Introduction 4.2.5.1 WAN Port Attribute Configuration Double click WAN to enter WAN Port Attribute configuration box. Ethernet Settings Item Description Green: Auto retrieving IP Auto IP Gray: Specified IP IP Address WAN Port Current IP Address...
Page 36 WAN port Device Port Set device WAN port number Device Brand Select from "Modbus", "BACnet", (No "BACnet" for BL101). Device Model Select model according to the selected device brand Polling interval Set command interval time and device return timeout time, click Time out the button next to the device model to set it.
Page 37: Add Wan Port Device Data Point
Industrial IoT Gateway BL101 BL103 Device address Only available when the device brand is "BACnet". 16-bit Data Type Select from "AB", "BA", only available when the device brand is "Modbus". 32-bit Data Type Select from "ABCD", "DCBA", "BADC", "CDAB", only when the device brand is "Modbus".
Page 38: Openvpn Introduction
Industrial IoT Gateway BL101 BL103 4G Setting Item Description Access Point Name of SIM card User User Name of SIM card Password Password of SIM card 4.2.7 OpenVPN Introduction Only BL101Pro and BL103Pro have the OpenVPN function, and the gateway device is the client.
Page 39 Industrial IoT Gateway BL101 BL103 OpenVPN Item Description Client/Server Gateway device as client "Client" IP/domain name The address of the server with which the client establishes an OpenVPN connection Port The TCP/UDP port provided by the server for establishing a connection, the default is 1194.
Page 40: Alarm And Event Configuration
Industrial IoT Gateway BL101 BL103 Client Key File Select File Upload, the key corresponding to the client certificate. Compression Select from "LZO" and "LZ4" according to the OpenVPN server Algorithm selection. Confirm OpenVPN configuration Cancel Cancel OpenVPN configuration 4.2.8 Alarm and Event Configuration Click "Alarms", move the mouse to the right box, right click, click "Add", to enter "Alarm...
Page 41 Industrial IoT Gateway BL101 BL103 Alarms Item Description Alarm Name Name of Alarm Point Alarm Key The MQTT identifier of the alarm point, can be filled in arbitrarily Select the data point. Click "Add" to pop up the data point, click Variable Name the data point to set the alarm, and click "OK".
Page 42: Alarm Event Configuration
Industrial IoT Gateway BL101 BL103 Jitter Delay Within alarm acknowledge time, if data recovered, then no alarm will be triggered. Confirm alarms setting Cancel Cancel alarms setting 4.2.8.2 Alarm Event Configuration Put mouse in "Alarm triggered execution action", right click the prompt box, click "Add" to enter event configuration box, and set the operation to be performed when the alarm is triggered.
Page 43: Task Schedule Configuration
Industrial IoT Gateway BL101 BL103 Alarms Item Description Generate the point name according to the selected data point, click Write Name "Add" to select the data point to be operated. Click on the data point and click OK Write Value Write the value of the data point to be operated, write "1"...
Page 44 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 45: Data Services
Industrial IoT Gateway BL101 BL103 Tasks Item Description Task Name Name of Task Schedule System Action Can set to restart the gateway device regularly. If it is to schedule other actions, select "NULL" for this item. UTC Time Set the time for task scheduling, this time is UTC time.
Page 46 Industrial IoT Gateway BL101 BL103 Pass Through Item Description COM1 TCP Mode Select gateway device as "TCP Server" or "TCP Client" It can only be configured when the gateway device is used as Network Interface the server. Select from "WAN", "LAN".
Page 47: Modbus Rtu To Modbus Tcp
Industrial IoT Gateway BL101 BL103 is transparently transmitted to the server. Gateway device used as server, it is shown as monitoring port, must be filled in. Port Gateway device used as client, it is shown as server port, must be filled in.
Page 48: Modbus Tcp Server
Industrial IoT Gateway BL101 BL103 Modbus RTU to Modbus TCP Configuration Item Description COM1 TCP Mode TCP Server, Gateway can only be TCP Server Network Interface Select from "WAN" or "LAN” Port Fill in the port that monitor the device. Must be filled in.
Page 49 Industrial IoT Gateway BL101 BL103 Modbus TCP Server Configuration Item Description Port Fill in the monitoring port, the port must be filled in. Confirm Modbus TCP Server setting Cancel Cancel Modbus TCP Server setting Modbus TCP host computer is used as the client, and the function codes supported are: Boolean value supports "01", "05", and numerical value supports "03", "06".
Page 50: Bacnet/Ip
(such as lighting, security, fire protection, etc.). BL103 gateway acts as a BACnet/IP server to provide data. Because the data attributes of various protocols are different, the two object attributes of AV and BV are unified to provide data for the current value.
Page 51 Cancel Cancel BACnet/IP configuration Note: The choice of WAN or LAN not only stipulates that the network port of the BACnet/IP service port is provided for the uplink, but also downlink collection of BACnet/IP. BACnet/IP host computer data acquisition configuration, please refer to: 5.4.4 View and send...
Page 52: Opc Ua
Industrial IoT Gateway BL101 BL103 4.2.10.5 OPC UA BL110 supports OPC UA and provides data as OPC UA server. The IP address of the OPC UA server can be selected according to the requirements of WAN or LAN. Click "WAN" and "LAN" to view the IP address of WAN and LAN.
Page 53: Cloud Platform
Industrial IoT Gateway BL101 BL103 composed of the device name on the configuration software and the data point label of the device. 4.2.11 Cloud Platform BL103 gateway supports multiple platforms online at the same time 4.2.11.1 MQTT Client MQTT Client can be connected to cloud with certificate or without certificate.
Page 54 Industrial IoT Gateway BL101 BL103 MQTT Client Configuration Item Description Green indicates MQTT Client is enabled Enable Gray indicates MQTT Client is disabled IP/Domain Name Fill in the IP/domain name to connect to the MQTT server Fill in the port to connect to the server, default is 1883, the port Port must be filled in.
Page 55: Mqtt Client Ii
Industrial IoT Gateway BL101 BL103 Topic of MQTT publishing message. It’s used for MQTT to identify message channel of sending valid load data. Wildcard Publish Topic can’t be included in publishing message topic name. Click Add to add more public topics. Click Delete to delete Public Topic Uploading Cycle Cycle time of MQTT data sending.
Page 56: Alibaba Cloud
Industrial IoT Gateway BL101 BL103 4.2.11.3 Alibaba Cloud Alibaba Cloud Configuration Item Description Green indicates Ali Cloud is enabled Enable Gray indicates Ali cloud is disabled Authentication Default is key connection. Select the key or certificate according to Mode your needs, and choose from "Device Secret" and "X.509".
Page 57 Industrial IoT Gateway BL101 BL103 Selection of click the right mouse button, click "Add", the data point box will published data pop up, click the data point, and click OK. points Confirm Alibaba Cloud setting Cancel Cancel Alibaba Cloud setting Alibaba Cloud platform model is under development, so data points need to be added one by one.
Page 58: Huawei Cloud
Industrial IoT Gateway BL101 BL103 Note: Alibaba Cloud devices shadow is not supported, send command through online debugging. 4.2.11.4 HUAWEI Cloud HUAWEI Cloud can be connected with or without Certificate. It supports multiple service IDs. Click Add to set Service ID. ID can be viewed from the drop-down list.
Page 59 Industrial IoT Gateway BL101 BL103 Note: 1. Datapoint box is blank by default which means all datapoints will be uploaded. If there’ re multiple Service IDs, only one Service ID datapoint box can be blank. Datapoints for uploading must be selected for other Service IDs.
Page 60 Industrial IoT Gateway BL101 BL103 Set the same ID as the one in HUAWEI Cloud(Device-Device Device ID Set the same Device Secret Key as the one in HUAWEI Cloud when creating device in HUAWEI Cloud. It can be reset in Device Key device authentication if forgot.
Page 61: Aws(Amazon Web Service)
Industrial IoT Gateway BL101 BL103 HUAWEI CLOUD platform data point settings are as follows: If multiple service IDs are set on the configuration software, and each service ID has different data points, the HUAWEI CLOUD platform needs to add attributes to the corresponding service IDs. The attribute name is filled with the variable label of the corresponding data point on the configuration software.
Page 62 Industrial IoT Gateway BL101 BL103 AWS Configuration Item Description Default is disable. Green indicates AWS is enabled Enable Gray indicates AWS is disabled Fill in the terminal node, enter the console, and click "Things" - "Interact". IP/Domain Name Port 8883(Required)
Page 63 Industrial IoT Gateway BL101 BL103 Fill in AWS account ID Client ID CA File Select File Upload Client certificate Select File Upload file Client key file Select File Upload Topic created when creating a rule, topic name used by MQTT to publish messages, click "Add"...
Page 64: King Pigeon Cloud Via Mqtt
Industrial IoT Gateway BL101 BL103 4.2.11.6 King Pigeon Cloud via MQTT King Pigeon MQTT Data Format refer to：5.4.19 King Pigeon MQTT Data Format Configure it as below King Pigeon IoT Configuration Item Description Green indicates King Pigeon cloud via MQTT is enabled, Gray...
Page 65 Industrial IoT Gateway BL101 BL103 Selection of Default is blank, means all data is uploaded. In the box on the published data right, click the right mouse button, click "Add", the data point points box will pop up, click the data point, and click OK.
Page 66: King Pigeon Cloud Via Modbus
Industrial IoT Gateway BL101 BL103 4.2.11.7 King Pigeon Cloud via Modbus Both King Pigeon Cloud and custom Modbus cloud can be connected via Modbus RTU protocol. BL103 supports function code 01, 05 of Boolean data and function codes 03, 06 of numerical data.
Page 67 Industrial IoT Gateway BL101 BL103 Gray indicates disable IP/Domain Name modbus.dtuip.com Port Default is 6651, must be filled in Modbus Station Set Modbus communication address of this Gateway device Data package of register connect server. Contact King Pigeon Login Message sales for serial number if you need.
Page 68: Bl103 Gateway Application Example
Industrial IoT Gateway BL101 BL103 5 BL103 Gateway Application Example 5.1 Modbus Protocol Devices Data Acquisition Take the COM port to collect the DI and DO data of the remote I/O module M140T, and the LAN port to collect the data of the RTU S475 as an example. The COM port is collected through the Modbus RTU protocol, and the LAN port is collected through the Modbus TCP protocol.
Page 69: M140T And S475 Connect To Bl103
Industrial IoT Gateway BL101 BL103 5.1.1 M140T and S475 Connect to BL103 The LAN port of the BL103 gateway is connected to the switch, the S475 is connected to the switch, and the LAN port is used to collect the S475 data through the Modbus TCP protocol.
Page 70: Com Port Configuration For Data Acquisition
Industrial IoT Gateway BL101 BL103 5.1.2 COM Port Configuration for Data Acquisition 5.1.2.1 COM Port Configuration COM collects M140T data through Modbus RTU. The COM port configuration is as follows: (1) Double-click "COM1" (2) Mode selection: Collection. (3) Because the M140T device is collected through the RS485 COM port, use Modbus RTU protocol, the device brand: Modbus, and the device model: Modbus RTU.
Page 71: Add Com Port Device M140T
Industrial IoT Gateway BL101 BL103 5.1.2.2 Add COM Port Device M140T 1) Click "COM1", right-click, and click "Add" to enter the configuration box. (2) Fill in the device name, such as: M140T. (3) The slave ID is filled in according to the Modbus ID of the acquisition device.
Page 72: Add M140T Data Point
Industrial IoT Gateway BL101 BL103 5.1.2.3 Add M140T Data Point (1) Click "M140T", right click the box on the right, and click "Add" to enter data point setting box. (2) Variable name: Name the data point, such as: DO1. (3) Variable key, which can be filled in arbitrarily.
Page 73: Ethernet Port Configuration For Data Acquisition
Industrial IoT Gateway BL101 BL103 point configuration box, repeat (2)--( 12) Steps. Note: Clicking "Write Configuration" will restart the gateway automatically, and the data points added by the M140T will take effect only after the restart. 5.1.3 Ethernet Port Configuration for Data Acquisition Both the WAN port and the LAN port can collect data from devices, and the configuration principles are the same.
Page 74: Add Lan Port Device S475
Industrial IoT Gateway BL101 BL103 Note: The IP address of the LAN port is the IP address that specifies which network segment the LAN port device is. If the IP address of the LAN port device is not the network segment IP set by the LAN, the LAN port cannot collect.
Page 75: Add S475 Data Point
Industrial IoT Gateway BL101 BL103 Note: After clicking OK, the added LAN port devices S475 will be displayed, as shown in the figure above. If you want to add multiple devices, repeat steps (1)-(9). Note: Click "Write Configuration" and the gateway will restart automatically. After restarting, the S475 device added by the LAN port will be added successfully.
Page 76: Data Upload To Various Platform
Industrial IoT Gateway BL101 BL103 can be filled in at will. Mapped addresses cannot be duplicated. Range: 0-2000. For example, the data collected from the temperature of S475 is stored in the “16” register address of the BL103 gateway. The outside of the mapping address on the configuration software represents the Modbus address, and M.XXX in the brackets represents the PLC Modbus address.
Page 77: Add Com Port Electricity Meter
Industrial IoT Gateway BL101 BL103 5.2.1.2 Add COM Port Electricity Meter V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 78: Add Electricity Meter Data Point
5.4 Data Upload to Various Platform 5.3 BACnet Devices Data Acquisition BL101 does not support BACnet, only BL103 BACnet IoT gateway supports it. The BL103 gateway supports the collection of nine objects: AI, AO, AV, BI, BO, BV, MSI, MSO, and MSV. The collected value is the current value attribute of these nine objects.
Page 79: Com Configuration For Bacnet Ms/Tp Devices Data Acquisition
5.3.1.1 COM Configuration Take the BACnet MS/TP device collected by the COM port as an example, the COM port 485 ports A+ and B- correspond to the A+ and B- ports of the 485 port of the BACnet MS/TP device respectively.
Page 80: Add Com Port Bacnet Ms/Tp Device
BACnet MS/TP. (3) Local MAC: Fill in as required, default is 127. (4) Device MAC: MAC of BACnet MS/TP device, fill in according to the device. (5) Device address: fill in the instance of the BACnet MS/TP device. (6) Click "OK"...
Page 81 Industrial IoT Gateway BL101 BL103 (1) Click "BACnet MS/TP", right-click the box on the right, and click "Add" to enter data point setting box. (2) Variable name: Name the data point, such as: collecting data of "analog input 1", it can be filled in as: analog input. (3) Variable key, which can be filled in arbitrarily.
Page 82: Ethernet Configuration For Bacnet Ms/Tp Devices Data Acquisition
5.3.2 Ethernet Configuration for BACnet MS/TP Devices Data Acquisition Both the WAN port and the LAN port can collect BACnet/IP devices, which can be directly connected to BACnet/IP devices or collected through switches. It is the network port selection setting of the data service "BACnet/IP" item to specify whether it is WAN port collection or LAN port collection.
Page 83 Industrial IoT Gateway BL101 BL103 (1) Double-click "WAN" to enter WAN port configuration box. (2) Obtain IP automatically: It is enabled by default, and can be set as required. In this example, in this example, it is connected to a router, and the route is enabled to automatically assign IP, so keep it enabled.
Page 84: Add Wan Port Bacnet/Ip Devices
Name the device, such as: BACnet (3) Device IP: Fill in the BACnet/IP device IP. Note that the IP of the BACnet/IP device must be in the same network segment as the IP of the WAN port. (4) Device port: UDP port, default 47808. (5) Because it is collection of BACnet/IP equipment, device brand: select BACnet, and the device model: BACnet/IP.
Page 85 Industrial IoT Gateway BL101 BL103 (1) Click "BACnet", right-click the box on the right, and click "Add" to enter data point setting box. (2) Variable name: Name the data point, such as: collecting the data of "binaryinput 3", it can be filled in as: binaryinput. (3) Variable key can be filled in arbitrarily.
Page 86: Data Upload To Various Platform
Industrial IoT Gateway BL101 BL103 5.3.3 Data Upload to Various Platform No matter what protocol data is collected by the BL103 gateway, the configuration for transmitting the data to each platform is the same. Therefore, this chapter takes the configuration of collecting Modbus protocol data and transferring it to each platform as an example.
Page 87: View And Send Command By Kingview
Industrial IoT Gateway BL101 BL103 5.4.2 View and Send Command by KingView Modbus TCP Server is a Modbus TCP server that provides data to external. Collect BL103 gateway data through Modbus TCP host computer, such as SCADA, MES and other host computers.
Page 88 Industrial IoT Gateway BL101 BL103 S475 data point value and mapping address, Kingview uses PLC Modbus address. The value of the data point read by Kingview, the value of Boolean value on Kingview, "0" is closed, "1" is open. V1.0...
Page 89 Industrial IoT Gateway BL101 BL103 Kingview sends command, the value of Boolean on Kingview, "0" is closed, "1" is open. For example: the register 000002 is DO2, and the relay is disconnected by sending "0". V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 90: Bacnet/Ip Configuration
Industrial IoT Gateway BL101 BL103 5.4.3 BACnet/IP Configuration Note: BL101 Modbus Gateway does not support BACnet/IP. V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 91 (6) Vendor ID: can be filled in arbitrarily. (7) Device name: the name of the BACnet/IP server, which can be filled in arbitrarily. (8) Device ID: Can be filled in arbitrarily. (9) Device Description: Gateway description, which can be filled in arbitrarily. (10) Location: Gateway location, default "CN".
Page 92: View And Send Command By Kepserverex 6
Industrial IoT Gateway BL101 BL103 5.4.4 View and Send Command by KEPServerEX 6 Fill in the UDP port and local instance according to the port and device ID on the configuration software. After it is built, you can add devices by searching devices, or you can add devices yourself.
Page 93 Industrial IoT Gateway BL101 BL103 Taking the data point of M140T DO6 as an example, the collected data is "1" when viewed on the configuration software, and the address of the data point of DO6 on BACnet/IP is: BinaryValue.5.PresentValue Send Command: Take the value "0"...
Page 94: Opc Ua Configuration
Industrial IoT Gateway BL101 BL103 5.4.5 OPC UA Configuration V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 95: View And Send Command By Uaexpert
Industrial IoT Gateway BL101 BL103 Operation steps: (1) Double-click "OPC UA" to enter OPC UA configuration box. (2) Click the Enable button to enable OPC UA. Default: off. Gray: Disabled, green: enabled. (3) Port: OPC UA port, default: 4840. (4) Anonymous: Enabled, indicating that the user name is not used to connect.
Page 96 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 97: Mqtt Client Configuration
Industrial IoT Gateway BL101 BL103 Send Command Double-click the value of the data point directly to enter the value and press "Enter" to confirm. 5.4.7 MQTT Client Configuration The "KingPigeon" JSON data format of MQTT Client and MQTT Client II is the same as King Pigeon MQTT.
Page 98 Industrial IoT Gateway BL101 BL103 JSON data format in the "sparkplug b" format, click the button next to the data template item, enter configuration box to configure the group ID and edge node ID. The difference between MQTT Client and MQTT Client II is that the subscription topic of MQTT Client II does not work.
Page 99: View And Send Command By Mqtt.fx
Industrial IoT Gateway BL101 BL103 Configuration", the MQTT Client will not be enabled until the gateway device restarts. Re-open the configuration software to log in to the device, and you can see on the basic information page that the prompt light of "MQTT Client Online Status" is green, indicating that the MQTT Client is connected.
Page 100 Industrial IoT Gateway BL101 BL103 Note: The Client ID cannot be the same as the Client ID filled in the configuration software. Message received on MQTT.fx The subscription topic on MQTT.fx is the publish topic configured on the MQTT Client Publish with MQTT.fx...
Page 101 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 102 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 103: Alibaba Cloud Configuration
Industrial IoT Gateway BL101 BL103 5.4.9 Alibaba Cloud Configuration (1) Double-click "Alibaba Cloud IoT" to enter configuration box. (2) Click the Enable button to enable Alibaba Cloud. Default: off. Gray: Disabled, Green: enabled. (3) Authentication mode: Choose whether to use a key connection or a certificate connection. The default is key connection.
Page 104: View And Send Command By Alibaba Cloud
Industrial IoT Gateway BL101 BL103 certificate connection, select the root certificate file to upload. (10) Client certificate file: When enabling certificate connection, select the client certificate file to upload. (11) Client key file: When enabling certificate connection, select the client key file to upload. (12) Upload cycle: The interval for regular data release, the default is 30S.
Page 105 Industrial IoT Gateway BL101 BL103 The data received by Alibaba Cloud is as follows: V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 106 Industrial IoT Gateway BL101 BL103 Alibaba Cloud Platform Send Command Note: The shadow function of Alibaba Cloud devices is not supported, and the command must sent through online debugging. V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 107 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 108: Huawei Cloud Configuration
Industrial IoT Gateway BL101 BL103 5.4.11 HUAWEI Cloud Configuration (1) Double-click "HUAWEI CLOUD IoT" to enter configuration box. (2) Click the Enable button to enable HUAWEI CLOUD. Default: off. Gray: Disabled, Green: Enabled. (3) Authentication mode: Choose whether to use a key connection or a certificate connection.
Page 109 Industrial IoT Gateway BL101 BL103 enter the key when creating a device. (8) CA file: When enabling certificate connection, select the root certificate file to upload. (9) Client certificate file: When enabling certificate connection, select the client certificate file to upload. (10) Client key file: When enabling certificate connection, select the client key file upload.
Page 110: View And Send Command By Huawei Cloud
Industrial IoT Gateway BL101 BL103 5.4.12 View and Send Command by HUAWEI Cloud The property name is the variable label identifier on the configuration software V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 111 Industrial IoT Gateway BL101 BL103 Data received by the HUAWEI CLOUD IoT platform: Click "View All Properties" or click "Device Shadow" to view all data as follows: V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 112 Industrial IoT Gateway BL101 BL103 Send command by HUAWEI CLOUD Add command Command to send data Take the DO2 of M140T as an example V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 113: Aws(Amazon Web Service) Configuration
Industrial IoT Gateway BL101 BL103 Check whether the DO2 data has changed in the device shadow, from the original "1" to "0". 5.4.13 AWS(Amazon Web Service) Configuration Amazon Cloud supports multiple release topics, and the configuration is the same as HUAWEI CLOUD's.
Page 114: View And Send Command By Aws
Industrial IoT Gateway BL101 BL103 Thing: Fill in the ARN, and click "Details" of "Thing" to view the ARN. (6) Client ID: fill in the account ID and view it in the user information. (7) CA file: Select the root certificate file to upload.
Page 115 Industrial IoT Gateway BL101 BL103 V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 116: King Pigeon Modbus Cloud Configuration
Industrial IoT Gateway BL101 BL103 5.4.15 King Pigeon Modbus Cloud Configuration (1) Double-click "King Pigeon Modbus IoT" to enter configuration box. (2) Click the Enable button to enable King Pigeon Modbus. Default: off. Gray: disabled, Green: enabled. (3) IP/domain: modbus.dtuip.com, filled in by default, no need to fill in. (4) Port: 6651, filled in by default, no need to fill in.
Page 117: View And Send Commands By King Pigeon Cloud
Industrial IoT Gateway BL101 BL103 5.4.16 View and Send Commands by King Pigeon Cloud The data point configuration of the King Pigeon Modbus platform is as shown in the figure below. First build the data point, and then go to the read and write instructions of the link protocol item to set the configuration data point Modbus ID, function code, address, data format, byte order, and collection cycle.
Page 118 Industrial IoT Gateway BL101 BL103 The values of the collected data points are as follows: V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 119 Industrial IoT Gateway BL101 BL103 Send command by the platform V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 120: King Pigeon Mqtt Cloud Configuration
Industrial IoT Gateway BL101 BL103 5.4.17 King Pigeon MQTT Cloud Configuration (1) Double-click "King Pigeon IoT" to enter configuration box. (2) Click the Enable button to enable King Pigeon MQTT. Default: off. Gray: disabled, Green: enabled. (3) IP/domain name: 1883.dtuip.com, filled in by default, no need to fill in. (4) Port: 1883, filled in by default, no need to fill in.
Page 121: View And Send Command By King Pigeon Cloud
Industrial IoT Gateway BL101 BL103 5.4.18 View and Send Command by King Pigeon Cloud First, add data points, and then go to the setting link protocol item to configure the data point identifier. The identifier of the data point is consistent with the variable label on the configuration software.
Page 122 Industrial IoT Gateway BL101 BL103 The values of the collected data points are as follows: V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 123 Industrial IoT Gateway BL101 BL103 Send commands Take control of DO2 of M140T as an example V1.0 Shenzhen Beilai Technology Co., Ltd.
Page 124: King Pigeon Mqtt Data Format
Industrial IoT Gateway BL101 BL103 5.4.19 King Pigeon MQTT Data Format The "KingPigeon" JSON data format of MQTT Client and MQTT Client II is the same as that of King Pigeon MQTT. The details are as follows 1) The payload data format in the device publish message Release topic: serial number (corresponding to the configured release topic setting item) "sensorDatas": [...
Page 125 Industrial IoT Gateway BL101 BL103 "state":"alarm", //Alarm identifier (the configuration software "Alarm and Event" is configured with an alarm event, which is only available when an alarm is triggered, but not in the regularly reported data) "state":"recovery", //Alarm recovery identifier (this identifier is only available when the alarm is recovered, and the data reported regularly does not have this identifier) "gateway_indentify": "Beilai"...
Page 126 Industrial IoT Gateway BL101 BL103 //Gateway name identification: the character is "gateway_indentify", followed by "gateway name". //Time identification: the character is "time", followed by "specific reporting timestamp". //Time stamp: the character is "addtime", followed by "gateway time". //Retransmission identifier: the character is "retransmit", followed by "enable"...
Page 127: Firmware Upgrade
Industrial IoT Gateway BL101 BL103 means closed) 2. Numerical data: the character is "value", followed by "specific value" //Read and write flag: the character is "flag", followed by "MQTT flag representing the data point" //Platform downlink message identification: The character is "down", followed by "down", which means this is the platform downlink data.
Page 128: Warranty
Industrial IoT Gateway BL101 BL103 7 Warranty 1) This equipment will be repaired free of charge for any material or quality problems within one year from the date of purchase. 2) This one-year warranty does not cover any product failure caused by man-made damage, improper operation, etc.

This manual is also suitable for:

Bl103

BACnet BL101 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for BACnet BL101

Summary of Contents for BACnet BL101

This manual is also suitable for:

Table of Contents
