- Page 1 ® CleanTech 500EZ INSTALLATION AND OPERATION MANUAL March 31, 2020...
- Page 2 WARNING: The performance and effectiveness of CleanTech® systems have been extensively tested when using solutions provided by Meritech Systems, LLC. Satisfactory performance or effectiveness cannot be guaranteed when other solutions are used. FAILURE TO USE MERITECH SYSTEMS, LLC SUPPLIED CHEMICALS WILL VOID ANY AND ALL WARRANTIES.
-
Page 3: Table Of Contents
MERITECH Systems, LLC. CleanTech® Installation and Operation Manual Table of Contents Introduction Overview Facility Installation Instructions 6 - 7 Wall-mount New Construction Rough-In Diagram Who to Call if You Need Help The Hand Cleansing Cycle Helpful Pointers For Trouble Free Operation... -
Page 4: Introduction
Introduction Thank you for selecting the CleanTech® 500EZ Automated Hand Cleansing System as a component in your hand washing regimen. We designed the Series 500EZ to provide your facility with an automated, turnkey system that meets or exceeds your hand washing requirements for compliance, standardization and effectiveness. -
Page 5: Overview
Overview Achieving the Optimum Wash The CleanTech® 500EZ system provides a no-touch, completely automatic hand wash by sequentially delivering handwashing solution and water in a stimulating spray to the hands or gloves from finger tips to wrist. The system uses the Ultrapure hygiene solution and water to remove 99.9% and greater pathogens from the hands or gloves. -
Page 6: Facility Installation Instructions
Facility Installation Instructions (For detailed specifications, see the system specifications of this manual) Wall-Mount: Remove wall mount template from packaging. Place top of the wall mount bracket facing up on wall at desired height and location. Recommended height is 44” from finished floor to top of wall mounting bracket, however top of wall mount bracket must be a minimum of 26”... -
Page 7: New Construction Rough-In Diagram
New Construction Rough-In Diagram... -
Page 8: Who To Call If You Need Help
If these hook-ups are not readily available, you will need to consult with your commercial plumber or electrician. Because of the different building codes and licensing regulations, Meritech cannot accept responsibility for providing plumbing and electrical modifications to your facility. However, a Meritech representative will be happy to provide the necessary guidance to ensure a correct installation. -
Page 9: The Hand Cleansing Cycle
The Hand Cleansing Cycle Check all water hook-ups to ensure they are open and not leaking. Plug the power cord into an electrical outlet and verify power on (the display panel, master count, & resettable counter will be illuminated). The system is ready for hand washing. Solution will be drawn from the 2 ½... -
Page 10: Helpful Pointers For Trouble Free Operation
Helpful Pointers for Trouble Free Operation Avoid touching or resting your hands and forearms on the cylinders themselves. If you apply pressure to the cylinder walls, the cylinders have been designed to stop spinning and will restart once you have stopped impeding their rotation. -
Page 11: Top Cover Indicators
Top Cover Indicators The CleanTech 500EZ system is equipped with a solutions indicator light bar to indicate the level of the solutions in the container. The station has a display that will indicate when solutions are empty and needs to be replaced, Master & Resettable Compliance Monitor, when washing and when rinsing. -
Page 12: Detailed System Reference
CleanTech® system. CleanTech® systems are not compatible with instantaneous or tank-less water heaters. For specific application assistance, contact Meritech at 1-800-932-7707. Consult with local plumbing authorities for proper connections and installation requirements. The customer installed hot and cold-water control shut-off valves should be located near the system. -
Page 13: Solution Delivery
The cycle length is normally 12 seconds but can be programmed over a wide timing range. All system programming is done either at the factory or by an authorized Meritech technician. DO NOT ATTEMPT TO PROGRAM OR REPROGRAM YOUR SYSTEM. -
Page 14: Changing Solution Containers
Changing Solution Containers Removing an Empty Container To remove an empty container, simply loosen the cap on the 2 ½ gallon container and remove the tube assembly from the empty container. DISPOSE OF CONTAINER ACCORDING TO LOCAL, STATE, AND FEDERAL REGULATIONS AND DO NOT REFILL USED CONTAINERS. -
Page 15: Solutions Replacement Diagram
Solutions Replacement Diagram... -
Page 16: Maintenance
As Needed: ➢ Replace cylinders every 30,000 – 50,000 hand wash cycles or when mineral deposits buildup or water splash out becomes excessive. This should be done by a Meritech technician. Taring System: ➢ On occasion it may be necessary to re-tare the solutions scale in the system. -
Page 17: Warning Symbols
Maintenance - Continued Taring: Tare Button Warning Symbols The following is a description of the symbols used on the CleanTech 500EZ system. -
Page 18: Unpacking Instructions
Unpacking Instruction Preparing system for Unpacking/Installation Carefully Carefully Remove Tape Remove Tape Carefully Remove Tape Carefully Remove Tape Carefully Remove Tape... -
Page 19: Installation Guide
Installation Guide Instructions for Installation & First Time Start-up The facility will need to provide the appropriate grounded electrical outlet, hot and cold- water supply lines with shut off valves and standard 3/4” male garden hose fittings for each supply or the hoses that are supplied with the system. -
Page 20: Cut Sheet
Cut Sheet A - Solutions Housing B – System Drain C – Hot/Cold Water Inlets D – Water Filter Screens E – Power Cord F – Air Curtain CDA/N2 Inlet C, D... -
Page 21: Wall Mount Template
Wall Mount Template Use Wall Mount Bracket as the template. -
Page 22: System Specifications
40 - 100 PSI (2.8 - 6.9 Bar), 50 PSI (3.6 Bar) optimum water pressure ▪ Note: Consult Meritech if connecting more than 2 system on the same water lines • Drain Standard 1 1/2” (40 mm) drain stub, P-Trap to be supplied by facility Ideal wall drain height from floor is 18”... - Page 23 System Specifications - Continued PATENTS: CleanTech® Automated Handwashing and Boot washing Systems are protected by the following U.S. Patents: U.S. Pat. No. 5,265,628; U.S. Pat. No. 5,823,447; U.S. Pat. No. 7,607,442; U.S. Pat. No. 7,607,443; U.S. Pat. No. 7,617,830; U.S. Pat. No. 7,641,740; U.S. Pat. No. 7,659,824;...
-
Page 24: If External Backflow Prevention Is Needed
Watts® Series 7C Part Number: ¾ H 7C For ANSI/ASSE Standard 1012 applications: Zurn/Wilkens Model 760 Part Number: 12-760 For ANSI/ASSE Standard 1056 applications: Watt® Series 008PCQT-1/2” For details or further assistance on these components, please contact Meritech Customer Service 800.932.7707... -
Page 25: Contacting Meritech
THE CLEANTECH 500EZ HAS BEEN DESIGNED TO OPERATE SPECIFICALLY WITH THE HAND WASH SOLUTIONS PROVIDED OR APPROVED BY MERITECH. THEY ARE OF A SPECIFIC CONCENTRATION AND VISCOSITY. WE CANNOT GUARANTEE SATISFACTORY PERFORMANCE NOR WARRANTY THE SYSTEM IF THE CONTAINERS ARE FILLED WITH A DIFFERENT SOLUTION. IN ADDITION, THERE IS ALSO A RISK... -
Page 26: Meritech Systems, Llc Warranty
(e) any Product for which Meritech has not received payment from the Original Purchaser. If a defect exists to the Product, the Original Purchaser’s sole remedy is to make a warranty claim within the Warranty Period, and Meritech’s sole liability shall be to, at Meritech’s election: (a) repair the Component Parts at no charge, using new and refurbished parts;... -
Page 27: Terms & Conditions Of Sale
Buyer, Buyer’s representative, or common carrier. The cost of any special packing or special handling caused by Buyer’s requirements or requests shall be added to the amount of the order. If Buyer causes or requests a shipment delay, or if Meritech ships or delivers the products erroneously as a result of inaccurate, incomplete or misleading information supplied by Buyer or its agents or employees, storage and all other additional costs and risks shall be borne solely by Buyer.
Need help?
Do you have a question about the CleanTech 500EZ and is the answer not in the manual?
Questions and answers
I have a full bottle of soap. and it says it’s empty
The MERITECH CleanTech 500EZ may indicate that it is empty despite having a full bottle of soap due to a blockage or improper delivery of the solution. The system continuously monitors solution delivery and signals an issue if it detects improper flow. To resolve this, visually inspect the container and clear delivery lines to ensure there is adequate fluid and no blockage. If necessary, replace the solution container.
