4K PTZ REMOTE CAMERA
KY-PZ510NWU/KY-PZ510NWE
KY-PZ510NBU/KY-PZ510NBE
KY-PZ510WU/KY-PZ510WE
KY-PZ510BU/KY-PZ510BE
Specifications and appearance of this unit are subject to change for further improvement without prior notice.
Details
For details on settings and operation, refer to "INSTRUCTIONS" on the website.
Please check the latest INSTRUCTIONS, tools, etc. from the URL below.
North America:
http://pro.jvc.com/prof/main.jsp
Europe:
https://eu.jvc.com/#pro
For Customer Use:
Enter below the Serial No. which is located
on the body.
Retain this information for future reference.
KY-PZ510NWU/KY-PZ510NBU
KY-PZ510WU/KY-PZ510BU
Model No.
Serial No.
IM 1.00
(Installation/IP Address Settings)
North America
Please read the following before getting started:
Thank you for purchasing this product. Before
operating this unit, please read the instructions
carefully to ensure the best possible performance. In
this manual, each model number is described
without the last letter (U/E) which means the
shipping destination.(U: for USA and Canada, E: for
Europe)Only "U" models (KY-PZ510NWU/KY-
PZ510NBU/KY-PZ510WU/KY-PZ510BU)have been
evaluated by UL.
INSTRUCTIONS
Europe
B5A-4258-00
Advertisement
Table of Contents
Related Manuals for JVC KY-PZ510NWE
Summary of Contents for JVC KY-PZ510NWE
- Page 1 4K PTZ REMOTE CAMERA KY-PZ510NWU/KY-PZ510NWE KY-PZ510NBU/KY-PZ510NBE KY-PZ510WU/KY-PZ510WE KY-PZ510BU/KY-PZ510BE INSTRUCTIONS (Installation/IP Address Settings) Specifications and appearance of this unit are subject to change for further improvement without prior notice. Details For details on settings and operation, refer to “INSTRUCTIONS” on the website.
- Page 3 FOR USA These are general Important Safety Instructions and certain items may not apply to all appliances. Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings.
- Page 4 POUR LES ÉTATS-UNIS Ces informations sont des CONSIGNES DE SÉCURITÉ IMPORTANTES et certains points peuvent ne pas s’appliquer à tous les appareils. CONSIGNES DE SÉCURITÉ IMPORTANTES Lire ces instructions. Conserver ces instructions. Tenir compte de tous les avertissements. Respecter toutes les instructions. Ne pas utiliser cet appareil à...
-
Page 5: Safety Precautions
Safety Precautions POUR CANADA FOR USA AND CANADA ATTENTION RISQUE CAUTION D’ELECTROCUTION NE PAS OUVRIR RISK OF ELECTRIC SHOCK ATTENTION: DO NOT OPEN POUR EVITER TOUT RISQUE CAUTION: D’ELECTROCUTION NE PAS OUVRIR LE BOITER. AUCUNE TO REDUCE THE RISK OF PIECE INTERIEURE N’EST A ELECTRIC SHOCK. - Page 6 Des changements ou modifications Changes or modifications not non approuvés par JVC peuvent approved by JVC could void the annuler le droit de l’utilisateur de faire user’s authority to operate the fonctionner l’appareil. Cet appareil a equipment. This equipment has been été...
- Page 7 CAUTION: Attention: The mains plug shall remain readily La prise secteur doit être opérationnelle. operable. Débranchez immédiatement la fiche Remove the mains plug immediately if secteur si le caméscope ne fonctionne the camera functions abnormally. pas normalement. WARNING: Avertissement: The battery pack, the camera with Évitez d’exposer la batterie, le battery installed, and the remote control caméscope avec la batterie insérée ou la...
- Page 8 When the equipment is installed in a Si le matériel est installé dans un coffret cabinet or on a shelf, make sure that it ou sur une étagère, s’assurer qu’il y a un has sufficient space on all sides to allow espace suffisant sur tous les côtés pour for ventilation (10 cm (3-15/16") or more permettre la ventilation (10 cm (3-15/16")
- Page 9 Lorsque vous utilisez l'adaptateur When using the AC adapter in secteur ailleurs qu’aux États-Unis areas other than the USA L'adaptateur secteur fourni dispose d'une The provided AC adapter features sélection de tension automatique dans la automatic voltage selection in the AC plage CA de 110 V à...
- Page 10 CAUTION: IMPORTANT (for owners in the U.K.) Where there are strong electromagnetic Connection to the mains supply in waves or magnetism, for example near a the United Kingdom. radio or TV transmitter, transformer, DO NOT cut off the mains plug from motor, etc., the picture and the sound this equipment.
- Page 11 FOR EUROPE Consult your dealer as special technique is required when installing this product. Ensure that WARNING the fixing screws or nuts are tightened securely, This is a Class A product. In a domestic otherwise, the unit may fall off. environment this product may cause radio interference in which case the user Mounting to a firm place...
-
Page 12: Table Of Contents
: Indicates the reference page Basic System Diagram ........20 numbers and reference items. : Feature available on KY- Installation/Connection PZ510NWU/KY-PZ510NWE/KY- Mounting the Camera to the Ceiling Mount Bracket PZ510NBU/KY-PZ510NBE only................21 Content of this manual Attaching Label to the Camera ......21 Installing the Camera on the Ceiling .... -
Page 13: Precautions
Precautions Transportation o Do not throw away the original box of the unit. Keep it and use it for transporting the unit in future. Installation Location Carrying the Camera o Be sure to install the camera horizontally. o Do not drop or hit this unit against a hard object Storage and Usage Locations when transporting. - Page 14 License Notices Others o MPEG LA AVC o This camera will perform the initial operation of THIS PRODUCT IS LICENSED UNDER THE AVC pan/tilt/zoom upon powering on. PATENT PORTFOLIO LICENSE FOR THE o The camera body may be captured in the PERSONAL USE OF A CONSUMER OR OTHER recording depending on the pan, tilt or zoom USES IN WHICH IT DOES NOT RECEIVE...
- Page 15 o An afterimage can appear if you view a moving object on the monitor output, however this is not a malfunction. o Do not put anything into the camera unit. Metal and flammable items entering from the connectors can result in fire or electric shock. o The camera may not show stable pictures for a few seconds immediately after the power is turned on, but this is not a malfunction.
-
Page 16: Names Of Parts
Names of Parts A RESTORE switch (Reset switch) Memo : Press and hold down to activate reset. B HDMI terminal C 3G-SDI terminal D LINE IN terminal E RS485 terminal Half duplex mode Baud rate: 2400/4800/9600/38400 bps Start position: 1 bit Data bit length: 8 bits Stop bit length: 1 bit Check digit: None... - Page 17 Corresponding Pins between Camera and Windows DB-9 Camera Windows DB-9 1.DTR 1.CD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI Corresponding Pins between Camera and Mini Camera Mini DIN 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD...
- Page 18 Infrared Remote Control H L/R SET button Press the button together with the NUMBER button [1] or [2] at the same time to pans the camera toward the left or right. CAMERA SELECT Pressing the left or right side of the [L / R SET] + [1] (STD) at the same time pans the camera toward the left or right accordingly.
- Page 19 O IR REMOTE CONTROL, AUTO TRACKING Shortcut settings buttons [Z] + [#] + [1]: IR REMOTE CONTROL Configures the menu language to English. For configuring the number of the camera you want to control using the infrared remote [Z] + [#] + [3]: control.
-
Page 20: Basic System Diagram
Basic System Diagram HDMI cable (Sold separately) 3G-SDI cable (Sold separately) 3.5 mm audio cable (Sold separately) RS485 Cable (Sold Separately) USB cable (Sold separately) AC adapter (Supplied) DC 12V IN Power cord (Supplied) LAN cable (Sold separately) RS232C Cable (Supplied) Computer, TV, Router or Hub, Microphone, etc. -
Page 21: Mounting The Camera To The Ceiling Mount Bracket
1 Place the ceiling mounting bracket (ceiling 2 Turn the label upside down side) against the ceiling and mark the 3 Align the center position of “V” of the JVC mounting position on the ceiling logo on the camera with that on the label,... -
Page 22: Installing The Camera On The Ceiling
Installing the Camera on 4 Use three M3 screws that come with the the Ceiling camera to attach 1 Remove the feet from the bottom surface of the camera Fasten the drop prevention wire (sold separately) together with one of the screws. 2 Use the four M3 screws that come with the camera to attach the ceiling mounting bracket (camera side) to the bottom... -
Page 23: Installing The Camera On A Desktop
Installing the Camera on a Connecting the Cables Desktop 1 Connect the cables Connecting to an HDMI/SDI monitor allows Place the camera on a flat surface. you to check the camera images. Be sure to place the base of the camera To input the audio, connect the audio cable horizontally. -
Page 24: Network Features
Network Features IP address settings There are two ways to configure the IP address of the camera. Operating Environment A Log in to the web page, and select [Network] B Operation has been verified for the following [Lan Settings] to make changes to the IP environments. -
Page 25: Confirming The Connection
The default IP address of camera is 192.168.0.10. 2 Enter the user name and password Enter the user name (jvc) and the password on the login screen to display the Live View screen. Memo : A screen for changing the password is displayed... -
Page 26: Troubleshooting
Manage the password properly to avoid forgetting it. If you forgot the password password, reset the camera to return to its default settings. (Default IP address: 192.168.0.10; default user name: jvc; default password: 0000) Unable to control using the Replace the batteries in the remote control with new ones and check remote control unit again. -
Page 27: Specifications
Specifications Item Description [3G-SDI] BNC type terminal 720p/1080i/1080p: embedded General audio 3G-SDI: SMPTE ST424- Item Description compliant Power DC 12 V (when an AC adapter is HD-SDI: SMPTE ST292- used) compliant PoE+ [HDMI] output Type A Current 0.95 A (*1) terminal consumption 0.25 A (*2) - Page 28 Remote control unit NDI|HX W Streaming: RTSP/RTP, RTMP/ Ceiling mount bracket set RTMPS, SRT, MPEG2-TS/ Screws (M3) RTP, MPEG2-TS/UDP, NDI| JVC logo label HX W Lens cap * The warranty card can be found inside INSTRUCTIONS (Installation/IP Address Settings). Specifications...
- Page 29 Dimensional Outline Drawing (Unit: mm) * The specifications and appearance of this product are subject to changes for further improvement without prior notice. Specifications...
-
Page 30: Software License Agreement
Software License Article 4 Right pertaining to the Licensed Software Agreement 1. Any and all copyrights and other rights pertaining to the Licensed Software and related documents shall belong to the Licensor or the original holder of The software embedded in the Product (hereinafter the right who granted to the Licensor the license or the “Licensed Software”) provided by sublicense for the Licensed Software (hereinafter... -
Page 31: Important Notice Concerning The Software
Article 9 Destruction of the Licensed Software The Licensed Software covers those corresponding to free software, and, as a condition of distribution of If this Agreement is terminated pursuant to the the software component in executable format which provision of Article 8, the User shall destroy the is based on the license granted under the GNU Licensed Software, any related documents and General Public License or Lesser General Public... - Page 33 Information on Disposal of Old Electrical and Electronic Informazioni sull’eliminazione dei prodotti elettrici ed Equipment and Batteries (applicable for countries that have elettronici e delle batterie (per i Paesi che adottano la adopted separate waste collection systems) raccolta differenziata dei rifiuti) Products and batteries with the symbol (crossed-out I prodotti e le batterie recanti questa icona (bidone wheeled bin) cannot be disposed as household waste.
- Page 34 מידע בדבר השלכה לאשפה של ציוד חשמלי ואלקטרוני ישן וכן סוללות Bu ürün 28300 sayılı Resmi Gazete’de yayımlanan Atik .()רלוונטי למדינות שמשתמשות במערכת איסוף אשפה מופרדת Elektrikli ve Elektronik Eşyalarin Kontrolü Yönetmeliğe uygun olarak üretilmiştir. X לא ניתן להשליך מוצרים וסוללות עם הסימון )פח אשפה עם .עליו( כאשפה...
- Page 36 KY-PZ510NWU/KY-PZ510NBU KY-PZ510WU/KY-PZ510BU KY-PZ510NWU/KY-PZ510NBU KY-PZ510WU/KY-PZ510BU B5A-4258-00 © 2022 JVCKENWOOD Corporation...
