- Page 1 WM105V WM105VB WM105VS WASHING MACHINE INSTRUCTION MANUAL Please read this instruction manual carefully before you use this product...
-
Page 2: Table Of Contents
CONTENTS SECTION 1: BEFORE USE Safety warnings Recommendations SECTION 2: INSTALLATION Removal of transportation screws Foot adjustment Electrical connection Water supply connection Drain connection SECTION 3: TECHNICAL SPECIFICATIONS SECTION 4: CONTROL PANEL Start/Pause button Function indicator lights Function buttons Program knob Washing programs SECTION 5: WASHING YOUR LAUNDRY Before washing... -
Page 3: Section 1: Before Use
SECTION 1: BEFORE USE SAFETY WARNINGS Do not use a multiple socket or extension cable. Do not connect a plug with a damaged cord into a socket. If the cord is damaged it should be replaced by the manufacturer or appointed service agent in order to avoid a hazard. -
Page 4: Section 2: Installation
If you plan not to use your machine for a long time, unplug it, shut off the water supply and leave the door open in order to keep the inside of the machine dry and to prevent unpleasant odours in the drum. As a result of our quality control procedures, a certain amount of water may remain in your machine from testing. -
Page 5: Electrical Connection
You can level your machine by adjusting its feet. First, loosen the plastic adjustment nut away from the cabinet base. Change the level by adjusting the feet upwards or downwards. When the machine is level and stable, tighten the plastic adjustment nut again by rotating it upwards against the base of the cabinet. -
Page 6: Drain Connection
Cold water inlet DRAIN CONNECTION The drain hose should be mounted at a minimum height of 60 cm and a maximum height of 100 cm from the floor. The end of the drain hose can be connected directly to a drainage stand-pipe or alternatively to a special connection point designed for that purpose on the waste outlet of a sink unit Do not extend the drain hose or your guarantee will be invalidated. -
Page 7: Section 3: Technical Specifications
SECTION 3: TECHNICAL SPECIFICATIONS WM105V WM105VB WM105VS Maximum dry laundry capacity (kg) Recommended loading (kg) Height (cm) Width (cm) 59,6 Depth (cm) Maximum spin cycle ( rpm ) 1000... -
Page 8: Section 4: Control Panel
SECTION 4: CONTROL PANEL WM105V-WM105VS-WM105VB 1 - Detergent drawer 5 - Program knob 2 - Start/pause light 6 - Start/pause button 3 - Function indicator lights 7 - Function buttons 4 - Program ready light 8 - Program end light Our product has an electronic card and soft-touch buttons. -
Page 9: Start/Pause Button
START/PAUSE BUTTON Used to start a selected program or pause during running. Note: The program knob must be brought to the O(off) position before selecting the program or changing an existing program. FUNCTION INDICATOR LIGHTS When the start/pause button or any function button is pressed, the corresponding light turns on. -
Page 10: Program Knob
PROGRAM KNOB With the program knob, you can select the program with which you desire to wash your clothes. You can adjust the program selection process by turning the program knob in both directions. Ensure that the mark on the program knob is aligned with the program you want to select. - Page 11 MAX DRY PROGRAM ENERGY WATER DETERGENT LOAD TIME CONSUMPTION CONSUMPTION PROGRAM TYPE OF LAUNDRY EXPLANATIONS COMPARTMEN (kWh) CAPACITY (MINS) (litres) (kg) Dirty, boil, cotton and linen 1- COTTON 90° 1,96 textile 2 - COTTON 60° Very dirty, cotton, coloured 0,89 (PREWASH) and linen textile Underwear, sheet,...
- Page 12 MAX DRY LOAD PROGRAM ENERGY WATER DETERGENT PROGRAM TYPE OF LAUNDRY EXPLANATIONS COMPARTMENT CAPACITY TIME CONSUMPTION CONSUMPTION (kWh) (kg) (MINS) (litres) When you need an additional rinse to be done to 13 - RINSE 0,04 your clothes after the washing process, you can use this program for all kinds of clothes.
-
Page 13: Section 5: Washing Your Laundry
SECTION 5: WASHING YOUR LAUNDRY Plug in the machine. Switch on the power. Connect the hoses to the water supply and to the drain. Open the water tap. First wash cycle It is recommended that the first wash cycle should be made without any laundry to ensure that the drum is clean and any water left from the factory testing is removed. -
Page 14: Running The Machine
Putting detergent into the machine The quantity of the detergent that you will put in your machine depends on the following criteria: Your detergent consumption will change according to the dirtiness of your clothes. For your slightly dirty clothes, do not pre-wash and put a small amount of detergent in compartment 2 of the detergent drawer. - Page 15 Changing the program If you have selected a program and you do not want it to continue: Press the start/pause button. Turn the program knob to the O(off) position. Turn the program knob to the program you require. (You can select the program that you desire from Table-1).
-
Page 16: Section 6: Maintenance And Cleaning
SECTION 6: MAINTENANCE AND CLEANING Unplug your machine. Close the water tap. WATER INLET FILTERS On the tap part of your machine’s water inlet hose and at the end of the water inlet valve, there are filters to prevent entrance of dirt and foreign materials in the water to the machine. -
Page 17: Detergent Drawer
WARNING! Danger of being scalded! Since the water inside the pump maybe hot, wait for it to cool. DETERGENT DRAWER Detergents may form sediment in your detergent drawer or in the housing of the detergent drawer over time. To clean the sediment, pull out the detergent drawer from time to time. To pull out the detergent drawer: Pull the detergent drawer to the end.(DIAGRAM-1) Press the blue siphon plug in the drawer and continue to pull the drawer until it is... -
Page 18: The Cabinet
THE CABINET Clean the exterior surface of the cabinet of your machine with lukewarm water and a cleaning substance that will not damage the cabinet. After rinsing with clean water, wipe it with a soft and dry cloth. WARNING! If the machine is installed in a location where the ambient temperature can fall below 0 C, ensure the following procedure is used when it is not in use: Plug in the machine. -
Page 19: Section 7: Practical Information
SECTION 7: PRACTICAL INFORMATION Alcoholic beverages: The stain point should first be washed with cold water, than wiped with glycerine and water and then be rinsed with water mixed with vinegar. Shoe Polish: The stain should be slightly scratched without ruining the cloth, rubbed with detergent and rinsed. -
Page 20: Section 8: Avoiding Minor Faults
Mould: Mould stains should be cleaned as soon as possible. The stain should be washed with detergent and if it does not disappear, it should be wiped with oxygenated water (in proportion of 3%). Ink: Hold the stained area under cold water and wait until the inky water completely runs off. - Page 21 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION Insert the plug into the It is unplugged. socket. The fuse is blown. Change the fuse. The electric power is off. Check the electric power. Your machine does not Start/pause button has not Press the start/pause operate.
- Page 22 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION There is a small amount of It does not prevent clothes in the drum. operation of the machine. Excessive amount of Do not exceed the clothes are filled in the recommended quantity of Your machine is vibrating. machine or the clothes are clothes and spread your not placed in a well-...
- Page 23 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION Clothes exceeding the Put the clothes in your maximum capacity have machine in a manner not been filled in your to exceed its maximum machine. capacity. Use the amount of The washing result is not detergent according to the good.
-
Page 24: Section 9: Automatic Failure Detection System
METHODS OF FAILURE PROBABLE CAUSE ELIMINATION The unbalanced load control system will try to distribute your clothes in an homogenous manner. After your clothes are The spinning process is No failure. The distributed, passage to the not done or starts with unbalanced load control spinning process will be delay. - Page 25 FAILURE FAILURE PROBABLE THE PROCESS CODE INDICATOR FAILURE TO BE DONE Turn the tap fully on. Water may be cut, check it. If the problem is still The water level in continuing, your your machine is machine will The program ready below the heater.
- Page 26 FAILURE PROBABLE THE PROCESS TO FAILURE CODE INDICATOR FAILURE BE DONE Shut down your machine and The start/pause light The heater of your unplug. Turn off Err 05 and program end machine or the heat your tap and contact light blink. sensor has failed.
-
Page 27: Section 10: International Washing Symbols
SECTION 10: INTERNATIONAL WASHING SYMBOLS Washing Do not wash Lukewarm iron. Medium hot iron. temperature. (hand wash) Hot iron. Do not iron. Do not tumble dry. Hang to dry. Drip dry. Dry flat. Do not bleach. Handy to bleach. All of these are dry cleaning symbols. The letters are to instruct the cleaner what type of solvent to be used.
