- Page 1 KEDACOM Body Worn Camera DSJ-U1-LPN User Manual July, 2018...
-
Page 2: Table Of Contents
Contents Instruction ......................1 Appearance ......................1 Function Buttons ....................2 Safety Instructions ....................4 Startup ........................5 Start Device ......................5 Viewing Interface ....................5 Basic Functions ....................7 Video Recording ....................7 Audio Recording ....................9 Photograph ....................... 10 4.3.1 Continuous Shooting .................. - Page 3 5.5.15 Record Duration ..................29 5.5.16 IR Settings ....................29 5.5.17 Pre-Recording Settings ................29 5.5.18 Limited Functionality ................... 29 Location ......................30 WiFi ........................31 Bluetooth ......................32 Intelligent Recognition ..................33 5.10 Wireless Transmission ................... 33 5.11 VLine Settings ....................35 5.12 VLine Storage Space ..................
-
Page 4: Instruction
1 Instruction Based on Qualcomm platform and meeting GA/T947-2015 standard of the public security industry, DSJ-U1-LPN is a body worn camera for the policemen to record live video, take photos and record audio as evidences during law enforcement. 1.1 Appearance Dimensions of the device are 111.3mm (L) * 62.1mm (W) * 30.3mm (H), and it has irreplaceable... -
Page 5: Function Buttons
Body Worn Camera DSJ-U1-LPN User Manual 1.2 Function Buttons Picture 1-2 Back panel Note: When the light is dim and short-distance shooting is necessary, long-press on [IMP] button for 3s to enable the LED lamp. Picture 1-3 Front panel... - Page 6 Body Worn Camera DSJ-U1-LPN User Manual Picture 1-4 Side buttons 1 Picture 1-5 Side buttons 2 Note: Under the video recording mode, press audio recording button and after the notice tone sounds, the video record will be saved and the audio recording starts; the indicator turns from red to yellow.
-
Page 7: Safety Instructions
User Manual 2 Safety Instructions DSJ-U1-LPN is a custom precise electronic device. To prevent damage on device caused by improper operation during using, please follow the instructions below: Use only the attached battery or battery and adaptor authenticated by this company. Never electrify the device with power adaptor over the rated voltage;... -
Page 8: Startup
Body Worn Camera DSJ-U1-LPN User Manual 3 Startup 3.1 Start Device Start device: Long-press on the power button for 3s and it takes about 24s to enter the system. 3.2 Viewing Interface After starting the body worn camera, it is the viewing interface, from which user can see live images through the camera. - Page 9 Body Worn Camera DSJ-U1-LPN User Manual Information bar: show the date and available storage of the device. When recording video or audio, show the icons of recording duration and recording status. Viewing frame: image displaying in the pattern of 16:9.
-
Page 10: Basic Functions
Body Worn Camera DSJ-U1-LPN User Manual 4 Basic Functions 4.1 Video Recording Under the viewing mode, press [Video Recording] button on the device and it will start recording after the notice tone sounds. There will be a flashing icon on the screen which means the device is recording a video. - Page 11 Body Worn Camera DSJ-U1-LPN User Manual Note: Under video or audio recording mode, short-press [IMP] button and an alarm picture (with alarm text) will be captured at mean time, and all the video or audio files starting from the moment of pressing the button till the end of recording are marked as important files.
-
Page 12: Audio Recording
Body Worn Camera DSJ-U1-LPN User Manual Picture 4-3 Start video recording of body worn camera through CU of VMS 2.0 4.2 Audio Recording Under the viewing mode, press [Audio Recording] button on the device and it will start audio recording after the notice tone sounds. -
Page 13: Photograph
Body Worn Camera DSJ-U1-LPN User Manual Picture 4-4 Audio recording Under audio recording mode, re-press [Audio Recording] button on the device and after hearing notice tone, the audio file is completed and saved. Meanwhile, the device stops recording and the yellow indicator turns green. -
Page 14: Snapshot
Body Worn Camera DSJ-U1-LPN User Manual 4.3.2 Snapshot Under the video recording mode, press the [Photograph] button on the device to capture current image in the recording. The resolution of the snapshot is the same as that of the video. If continuous shooting is enabled, it will capture images continuously. -
Page 15: Settings
Body Worn Camera DSJ-U1-LPN User Manual 5 Settings Go to Settings to perform simple configurations to the device. Tap the Settings icon on the main interface and enter the interface. 5.1 Scan QR Code Tap “Scan QR Code” and scan the QR code generated in iMMS and save the parameters into the body worn camera. -
Page 16: Mobile
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-3 Case linkage 5.4 Mobile When the body worn camera is of mobile version and the SIM card works normally, user can enable / disable mobile data; configure APN, VPN and traffic threshold; and view SIM card status. - Page 17 Body Worn Camera DSJ-U1-LPN User Manual Picture 5-5 APN setting VPN setting: If user needs to access to the server of company intranet remotely, perform the following steps to configure VPN: Enable “Mobile data”, tap “VPN” to enter the interface of VPN setting. Tap icon enter the interface of “Edit VPN profile”.
- Page 18 Body Worn Camera DSJ-U1-LPN User Manual Picture 5-7 Connect to VPN On VPN interface, there is “Connecting” displaying under the configuration file. If connecting succecessfully, it will show “Connected”, which means this network can be used normally. behind the needed VPN and the interface of “Edit VPN profile” pops Note: Tap the icon up.
-
Page 19: Advanced
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-9 Traffic threshold SIM status: tap to view SIM card status. Picture 5-10 SIM card status 5.5 Advanced 5.5.1 Video parameters Main Stream/Secondary Stream: set main/secondary stream Resolution, Video Compression, Bitrate, Frame Rate and Max Key Frame Interval. Default values are recommended. If the network is too poor and the video blocks, adjust the main/secondary stream parameters such as reducing resolution, bitrate or frame rate. -
Page 20: Protocol Access
BWC at CU and perform other operations. Steps to add a BWC to the VMS through GB protocol are as follows: 1. Add DSJ-U1-LPN to VMS on PMC. 1) Choose Manage Device > Add/Delete Model. Picture 5-12 VMS PMC > Device 2) In the displayed Add/Delete Model dialog box, tap Add. - Page 21 The Location parameter is optional. The following is an example. Picture 5-15 Location 7) Tap OK. 8) Select DSJ-U1-LPN from the device list and tap Query to query its information. The following is an example.
- Page 22 Body Worn Camera DSJ-U1-LPN User Manual Picture 5-16 Query 2. Choose Settings > Advanced > Protocol Access > GB to configure the GB protocol. 1) Turn on Enable. 2) Set GB ID, Username, Password, Video Encoding Channel and Alarm to the GB ID, User Name, Password and Channel values respectively.
- Page 23 Body Worn Camera DSJ-U1-LPN User Manual Picture 5-18 Encoding channel setting 3) Tap “Alarm” to enter the following interface and tap the icon “+” at top right corner to add or edit Alarm Channel ID, Alarm Name and Effective. After finishing, tap “OK”.
- Page 24 6) On the GB interface of BWC, input the internet IP address of the VMS into VMS IP according to actual condition. Do not fill Local Port. 3. Tap OK. After DSJ-U1-LPN accesses the VMS, you can find the icon displayed on the main screen.
-
Page 25: Viid
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-22 VMS IP 5.5.2.2 VIID The face snapshots and video records of the BWC can be uploaded to VIID for future analysis. After configuration, tap “OK”. Picture 5-23 Access to VIID VIID: Currently support VIID 1 only. - Page 26 Body Worn Camera DSJ-U1-LPN User Manual Face: You can enable “Auto Upload” and “Back Up Locally”, and then select the upload strategy. Picture 5-24 Face Video: You can enable “Auto Upload” and “Back Up Locally”. Picture 5-25 Video ...
-
Page 27: Onvif
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-27 Picture GPS: You can enable “Auto Upload” and “Back Up Locally”. Picture 5-28 GPS 5.5.2.3 ONVIF To configure the ONVIF protocol: 1. Choose Settings > Advanced > Protocol Access > ONVIF. Tap “Enable”;... -
Page 28: Audio Compression
Body Worn Camera DSJ-U1-LPN User Manual 5.5.4 Audio Compression Tap “Audio Compression” and select audio compression format from the list. Picture 5-30 Audio Compression Note: When the device accesses to and communicates with different systems or VMS in audio, user needs to set their audio compression. For example, when the device accesses to the video conference system, if which applies G.7221c compression, user needs to set the... -
Page 29: Video Format
Body Worn Camera DSJ-U1-LPN User Manual 5.5.7 Video Format The default video format is MP4. Tap [Video Recording] button on the device and it will record video in MP4. Picture 5-32 Video format 5.5.8 Audio Format The default audio format is M4A. Tap [Audio Recording] button on the device and it will record audio in M4A. -
Page 30: Number Of Continuous Shootings
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-34 Resolution 5.5.10 Number of Continuous Shootings Tap “Continuous Shooting” and tap “Number of Continuous Shootings” and select a number. Picture 5-35 Number of continuous shootings 5.5.11 Notice Tone Tap “Notice Tone” to set notice tone for various operations or conditions, as shown below. -
Page 31: Auto Lock
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-37 Screen brightness 5.5.13 Auto Lock Tap “Auto-Lock” and select an option such as 30s, 1 min, 3 min and Disabled. After selecting one, the screen will be locked for a certain period of time or never be locked. Tap power button and the screen will be locked to save electricity;... -
Page 32: Record Duration
Body Worn Camera DSJ-U1-LPN User Manual 5.5.15 Record Duration Tap “Record Duration” and select the max duration for each video or audio file. 5.5.16 IR Settings Tap “IR Settings” and select “Auto”, “Enable” or “Disable” from the list. Alternatively, tap Quick Setting >... -
Page 33: Location
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-42 Enable USB mode High Temp. Alarm When the temperature of the body worn camera reaches the alarm temperature and the alarm notice tone is enabled, the body worn camera will make alarm sound; when it reaches the shutdown temperature, the device will shut down automatically. -
Page 34: Wifi
Body Worn Camera DSJ-U1-LPN User Manual Picture 5-44 Location 5.7 WiFi Tap WiFi to configure WLAN and Hotspot. The WiFi hotspot can only be enabled through iMMS client. When WiFi hotspot is enabled, WiFi will be disabled automatically. If enabling WiFi when the hotspot is enabled, the hotspot will be disabled automatically. -
Page 35: Bluetooth
Body Worn Camera DSJ-U1-LPN User Manual Add network: if user wants to add network manually, tap icon at the top right corner of WLAN interface and select “Add network”. Enter network name (SSID), select security type or check advanced options, and tap “Save” to finish. -
Page 36: Intelligent Recognition
Body Worn Camera DSJ-U1-LPN User Manual mode only supports interphone. If the paired devices include other devices apart from interphone, when Client mode is enabled, the device will show disconnected. Picture 5-48 Bluetooth interface 5.9 Intelligent Recognition Intelligent recognition means to recognize faces. Enable “Auto Recognition” and the BWC will capture the pictures of human face once there is anyone entering the viewing range of the BWC. - Page 37 Body Worn Camera DSJ-U1-LPN User Manual Upload Tap “Upload Through” to configure network transmission and server. Options on “Upload Through” interface include “WiFi” and “No Limitation”. On the interface of upload server configuration, you can configure “Upload server IP” and “Upload server port”.
-
Page 38: Vline Settings
Body Worn Camera DSJ-U1-LPN User Manual management interface. When there is the icon behind the list ot the file, it means this is a disconnected video. Note: During the recording of disconnected videos, you can perform any operation about video recording. -
Page 39: Vline Storage Space
Body Worn Camera DSJ-U1-LPN User Manual 5.12 VLine Storage Space It shows the storage usage of BWC VLine. Dev: [BWC] shows the used space of VLine; Other Application shows the used space of applications other than VLine; Available shows the toal available space of BWC. -
Page 40: About
Body Worn Camera DSJ-U1-LPN User Manual 5.14 About On the About interface, user can view Officer, Officer ID, Position, Department and Department ID. Login to the PC client of iMMS client as an administrator and configure these parameters. Picture 5-58 About... -
Page 41: Vline Functions
Body Worn Camera DSJ-U1-LPN User Manual 6 VLine Functions The body worn camera supports function of digital voice intercom. 6.1 Chats Tap the VLine icon on the main interface to enter the chats interface by default, which shows recent chat list. -
Page 42: Group Chat
Body Worn Camera DSJ-U1-LPN User Manual Picture 6-3 Manage chat group When “Mute Notification” is enabled, user will be able to receive messages but without ring tone or vibration notification and there will be an icon on the interface of this chat group. -
Page 43: Contacts
Body Worn Camera DSJ-U1-LPN User Manual Picture 6-5 Group management Tap and the icon appears. Tap and select a picture to send it in the chatting group. Picture 6-6 Send pictures 6.2 Contacts Tap icon to enter the interface of contacts to view organization (group), department (group), chat groups (including fixed and non-fixed) and contacts. -
Page 44: Private Call
Body Worn Camera DSJ-U1-LPN User Manual Picture 6-7 Groups 6.2.2 Private Call Select a contact from the contacts list and tap to enter the “Details” interface. Tap “Message” to enter the chat interface. Tap to call the contact in private. - Page 45 Body Worn Camera DSJ-U1-LPN User Manual Picture 6-9 Voice call Tap and the icon appears. Tap and select a picture to send it in the chatting window.
-
Page 46: File Management
Body Worn Camera DSJ-U1-LPN User Manual 7 File Management Tap the file management icon on the main interface to browse, search or upload face, picture, video and audio files. Pictures with icon at the bottom left corner are those have been uploaded or are being uploaded to VIID server;... -
Page 47: Pictures
Body Worn Camera DSJ-U1-LPN User Manual 7.2 Pictures Pictures include the photographed photos and captured snapshots in video records. The pictures display in thumbnails by time sequence and the latest one is on the top. Tap picture to browse. Double-tap to zoom in and double-tap again to recover; slide left and right on the screen to view previous or next picture. -
Page 48: Audio
Body Worn Camera DSJ-U1-LPN User Manual 7.4 Audio Audio file: tap Audio to view audio records; the voices display by time sequence and the latest one is behind the file name, it means this file is an “IMP” file. Tap the on the top. -
Page 49: Specification
Body Worn Camera DSJ-U1-LPN User Manual 8 Specification Model No. Main Performance (DSJ-U1-LPN) Operating Deeply customized Android OS System Application Hardware Customized DDSMMS Software System Memory 32GB (ROM) + 3G (RAM) Compression H.264 & H.265 Image Main stream: 1920*1080, Secondary stream: 1280*720...
