Remove the chassis from the rack

WARNING:
equipment:
Observe local occupational health and safety requirements and guidelines for manual
•
material handling.
Remove all installed components from the chassis before installing or moving the chassis.
•
• Use caution and get help to lift and stabilize the chassis during installation or removal,
especially when the chassis is not fastened to the rack.
WARNING:
adequately support the chassis during installation and removal.
WARNING:
loaded into the rack above chest level, a third person must assist with aligning the chassis with the
rails while the other two people support the weight of the chassis.
Power down the system (on page 27).
1.
Disconnect all peripheral cables from the nodes and chassis.
2.
IMPORTANT:
original locations.
Remove all nodes from the chassis
3.
If installed, remove the security bezel (on page 31).
4.
Remove all drives
5.
If installed, remove the RCM module (on page 29).
6.
Remove all power supplies
7.
Loosen the thumbscrews and extend the chassis from the rack.
8.
Remove the chassis from the rack.
9.
For more information, see the documentation that ships with the rack mounting option.
The chassis is very heavy. To reduce the risk of personal injury or damage to the
To reduce the risk of personal injury or damage to the equipment, you must
Always use at least two people to lift the chassis into the rack. If the chassis is being
Label the drives before removing them. The drives must be returned to their
("Remove the node from the
("Hot-plug drive" on page 58).
("Remove the power
chassis" on page 27).
supply" on page 28).
