Ken A Vision VisionScope T-2400 Instruction Manual

screwdriver (1.5mm) into hole on right side near the top of the base.
c. Turn the stage plate lock screw one to two turns counter clockwise.
Carefully remove the stage plate, the lamp holder for the bottom light
source should now be in view and accessible.
d. Gently pull up on the lamp to unclip the fuse type bulb from the
holder. Press the new lamp into place.
e. Replace the stage plate. Tighten the Stage Plate lock screw until
snug. Do not over tighten.
Replacement of Upper Light Source
a. Unplug the microscope from the wall outlet.
b. With microscope facing you look on the right side of the upper light
cover housing. Locate the upper light housing lock screw and turn it
counter clockwise. Completely remove the screw.
c. Pull down on the upper light cover to remove it from the bracket.
Gently remove the lamp from the lamp holder. Push new lamp into the
holder.
e. Replace the cover and the cover lock screw. Take care that the
lamp is positioned in the center of the lamp holder to avoid contact with
the lock screw.
Replacement bulbs may be purchased on Ken-A-Vision web site
under accessories at www.ken-a-vision.com
CARE AND MAINTENANCE
Your microscope is a fine precision instrument and should be treated
with care. When not in use it should be protected from dust by the plas-
tic cover provided. Lenses and mirror should be cleaned periodically
with optical lens tissue which is soft and lint free. Painted surfaces can
be cleaned with a moistened cloth.
Ken-A-Vision has quality technicians on staff to repair or service your
microscopes. Contact us at 1.816.353.4787 for more details.
WARRANTY: TEN YEAR WARRANTY AGAINST DEFECTIVE PARTS AND WORK-
MANSHIP.
K -A-V
EN ISION
5615 Raytown Road, Kansas City, MO 64133 U.S.A Tel. 816-353-4787
Fax. 816-358-5072 Email: info@ken-a-vision.com www.ken-a-vision.com
part # INS-SC5
M C ., I .
ANUFACTURING O NC
kav.instman.visscope.pc.v1
Vis i o nS c op
Vis i o nS c op
Instruction Manual
