- Page 1 Instructions for use...
- Page 3 PACHW2900CO ENGLISH Instructions for use Page 4...
- Page 4 SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED • Download the complete instruction manual on docs.whirlpool.eu or call the phone number shown on the warranty booklet. • Before using the appliance, read these safety instructions. Keep them nearby for future reference.
-
Page 5: Installation
SAFETY INSTRUCTIONS INSTALLATION • The appliance must be handled and installed by two or more persons - risk of injury. Use protective gloves to unpack and install - risk of cuts. • Installation, including electrical connections, and repairs must be carried out by a qualified technician according to national wiring rules. - Page 6 SAFETY INSTRUCTIONS ELECTRICAL WARNINGS • The power supply must be of rated voltage with special circuitry for the appliance. The diameter of the power cord must comply with requirements. • It must be possible to disconnect the appliance from the power supply by unplugging. The appliance must be earthed in conformity with national electrical safety standards.
- Page 7 SAFETY INSTRUCTIONS FOR SERVICING APPLIANCE WITH SPESIFIC REFRIGERANT • Download the complete manual for detailed installation, servicing, maintenance and reparing methods on docs.whirlpool.eu. • Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
- Page 8 SAFETY INSTRUCTIONS 4. The storage of equipment / appliances should be in accordance with the manufacturer’s instructions. 5. Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge. The maximum number of pieces of equipment permitted to be stored together will be by local regulations.
- Page 9 SAFETY INSTRUCTIONS 6-8 Checks to the refrigerating equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt consult the manufacturer’s technical department for assistance.
- Page 10 SAFETY INSTRUCTIONS 8. Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on whilelive in the presence of a flammable atmosphere.
- Page 11 SAFETY INSTRUCTIONS process may need to be repeated several times. Compressed air or oxygen shall not be used for this task. Purging shall be achieved by breaking to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system.
- Page 12 SAFETY INSTRUCTIONS the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off. k. Recovered refrigerant shall not be charged into another refrigerating system unless it has been cleaned and checked. 14.
-
Page 13: User Interface
User Interface Start to use your air conditioner IMPORTANT NOTE: * When the air conditioner is turned on for the first time 1. Press the power button to start or stop the after it’ s plugged in, it will run in the cooling mode. operation of your appliance. -
Page 14: Remote Controller
Remote controller Insert the batteries into RC 1. Insert a pin and gently press down on the battery cover and push in the direction of the arrow to remove, as shown. 2. Insert 2 AAA batteries (1.5V ) into the compartment. Ensure that “+”... - Page 15 Remote controller Note: please follow the intruction which matches to the remote controller you receive for Air Conditioner operation. Function description of buttons ON OFF BUTTON Starts and/or Stops the appliance by pressing this button. MODE BUTTON Used to select the operation mode. FAN BUTTON Used to select fan speed in sequence auto, high, medium or low.
-
Page 16: Maintenance
Maintenance Draining the Air Conditioner 1. Press ON/OFF to turn off the air conditioner. 2. Unplug air conditioner or disconnect power. 3. Move the appliance gently and stably to a draining location or outside to drain water. Do not move the unit before water is drained out completely. - Page 17 lnstall the portable Air Conditioner lnstall Exhaust Hose and Adapter 1. Roll the air conditioner to selected location. See “Location Requirements” in page 4. 2. Preparing the exhaust hose assembly: Press the coupling and the window exhaust adapter into the flexible exhaust hose, both the coupling and window exhaust adapter have integrai clips that snap onto the hose.
-
Page 18: Installation Instruction
Installation instruction Location Requirements NOTES: Vertical • The flexible exhaust hose allows placement of the air Silde Window conditioner between 23 1/2” and 67” (60 cm and 170 cm) from window or door. combustible surfaces The appliance with supplementary heater needs to keep a minimum distance of 100 cm from the combustible surfaces. -
Page 19: Troubleshooting
I8°C. Note: If the problems still have, turn off the appliance and disconnect from power supply, then contact the nearest Whirlpool Authorized Service Center. Do not attempt to move, repair, disassemble, or modify the appliance by yourself. -
Page 20: After Sales Service
• your full address; • your telephone number. Note: if you want the full manual for your appliance, please help to download it from websit throught below link: docs.whirlpool.eu using QR code Whirlpool EMEA Via Pisacane 1 20016 PERO (MI) ITALY...
