Built-in Vehicle
FROST-FREE REFRIGERATOR-FREEZER
INSTRUCTION MANUAL
Model No.: SRD-360WTG-E
Dear users, this manual contains the product's basic knowledge, how to use it,
fault diagnosis and basic troubleshooting methods. In order to better
understand and use this product, please take good care of this manual, and read
it carefully.
Advertisement
Related Manuals for Everchill SRD-360WTG-E
Summary of Contents for Everchill SRD-360WTG-E
- Page 1 Built-in Vehicle FROST-FREE REFRIGERATOR-FREEZER INSTRUCTION MANUAL Model No.: SRD-360WTG-E Dear users, this manual contains the product's basic knowledge, how to use it, fault diagnosis and basic troubleshooting methods. In order to better understand and use this product, please take good care of this manual, and read...
-
Page 3: Table Of Contents
ONTENTS ........................2 MPORTANT SAFETY INSTRUCTIONS ............................4 EATURES AND PARTS III. P ............................ 4 REPARATIONS FOR USE IV. F ................................6 UNCTIONS ........................8 NSTRUCTIONS FOR FOOD STORAGE VI. T ..........................9 IPS FOR SPECIAL NEEDS VII. M ........................10 AINTENANCE AND CLEANING VIII. -
Page 4: Important Safety Instructions
I. I MPORTANT SAFETY INSTRUCTIONS ARNINGS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use your refrigerator near water. Clean only with a damp cloth. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 5 7. WARNING-Do not use electrical appliances inside the food storage compartments of the appliance unless they are of the type recommended by the manufacturer. 8.Power source disconnected your refrigerator before carrying out user maintenance on it. 9.If a component part is damaged, it must be replaced by the manufacturer, its service agent, or similar qualified persons in order to avoid a hazard.
-
Page 6: Features And Parts
II. Features and parts Due to technological innovations, the product descriptions in this manual may not be completely consistent with your refrigerator. Detailed information is in accordance with the final product. III. Preparations for use Installation location: Ventilation condition The position you select for the refrigerator installation should be well-ventilated and has less hot air. Do not locate the unit near a heat source such as cooker, and avoid it from direct sunlight, thus guaranteeing the refrigerator effect while saving energy consumption. - Page 7 Level ground Place the refrigerator on the solid and flat ground (floor) to keep it stable, or else, it will give rise to vibration and noise. When the refrigerator is placed on such flooring materials as carpet, straw mat, polyvinyl chloride, the solid backing plates should be applied underneath the unit, so as to prevent color change due to heat dissipation.
-
Page 8: Functions
IV. Functions When the refrigerator system is connected to the power supply for the first time, all icons on the display panel gets illuminated for 3s. 1. Functions 1.1 Temp. setting “SET” is the key to set temperature mode. Every time when this key is pressed, the current indicator light will be off, with the next indicator light illuminated;... - Page 9 1.3 Battery Monitor 1) The “Battery Monitor” function can display the current input voltage value of the refrigerator, helping the user understand the current battery level. 2) Enable the "Battery Monitor” function: Press and hold down the “SET” button for more than 5 seconds (but within 10 seconds); 3) Exit the "Battery Monitor"...
-
Page 10: Instructions For Food Storage
V. Instructions for food storage Precautions for use The appliance might not operate consistently (there is possibility of defrosting or temperature becoming too warm in the frozen food compartment) when sited for an extended period of time below the cold limit of the temperature range for which the refrigerating appliance is designed The information of climate type of the appliance is provided on the rating plate. -
Page 11: Tips For Special Needs
Use quality food and handle it as little as possible. When foods are frozen in small quantities, it will take less than for them to freeze up and thaw. Estimate the amount of foods to be frozen up. When freezing large amounts of fresh food, adjust the temperature control knob to the low mode, with the freezer temperature lowered. -
Page 12: Maintenance And Cleaning
VII. Maintenance and cleaning When cleaning, Do not stretch your hands into the bottom of the refrigerator, since you might be scratched by sharp metal corners. Internal cleaning and external cleaning The food residuals in the refrigerator are liable to produce bad odor, so the refrigerator must be cleaned regularly. The fresh food compartment is usually cleaned once a month. -
Page 13: Simple Fault Analysis And Elimination
VIII. Simple fault analysis and elimination You can solve many common refrigerator problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling for service. Case Inspection Solutions ·Completely non-...
Need help?
Do you have a question about the SRD-360WTG-E and is the answer not in the manual?
Questions and answers
My refrigerator is not working but the freezer is
The Everchill SRD-360WTG-E refrigerator may not be working while the freezer is functioning due to a fridge sensor fault. According to the self-checking function, if the indicator light "1" keeps flashing, it indicates a fridge sensor failure. This issue can prevent the refrigerator compartment from operating properly while the freezer continues to function. It is recommended to check the indicator lights and contact maintenance if this fault is detected.
This answer is automatically generated
2022 Ever Chill SRD-360WTG-E Which way do you slide the Freezer adjustment for the coldest setting
