Operating Instructions
LED TV
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0817-0
For more detailed instructions, please refer to
[eHELP] (Built-in Operating Instructions).
●
How to use [eHELP]
Model No.
TX-49EX580B
TX-55EX580B
(p. 16)
TQB0E2774U
English
Advertisement
Table of Contents
Related Manuals for Panasonic TX-49EX580B
Summary of Contents for Panasonic TX-49EX580B
- Page 1 ● How to use [eHELP] (p. 16) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
For information about the trademarks, refer to [eHELP] (Search by Purpose > Read first > Before use > Licence). The illustration for TX-49EX580B is used in this manual unless otherwise mentioned. Illustrations shown may be different depending on the model. -
Page 3: Important Notice
5 amp rating and that it is Panasonic has no authority to and does not grant approved by ASTA or BSI to BS1362. you that permission and explicitly disclaims any right,... - Page 4 Do not use an unapproved pedestal / mounting ● Disconnect the mains plug when cleaning the TV. equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved ● Do not touch the mains plug with wet wall-hanging brackets.
- Page 5 Do not use the pedestal if it becomes warped or order to help prevent excessive heat, which could lead physically damaged. If this occurs, contact your to early failure of some electronic components. nearest Panasonic dealer immediately. ● During setup, make sure that all screws are securely tightened.
-
Page 6: Accessories
LED TV Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and other relevant provisions of the Directive 2014/53/EU.” If you want to get a copy of the original DoC of this TV,... - Page 7 Preparations Assembling / Removing the pedestal Take out the pedestal and the TV from the packing case Assembly screw (4) and put the TV onto a work table with the screen panel down on the clean and soft cloth (blanket, etc.) M5 ×...
- Page 8 ■ <Style1> English...
- Page 9 ■ <Style2> Removing the pedestal from the TV Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the 1 Put the TV onto a work table with the screen panel down on the clean and soft cloth. 2 Remove the assembly screws from the TV.
-
Page 10: Connections
Connections Basic connections ■ Mains lead ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the AC 220-240 V mains socket before attaching or disconnecting any 50 / 60 Hz cables. - Page 11 ■ Satellite receiver Connections for 4K compatible equipment HDMI cable 4K compatible equipment HDMI cable ● To watch high-definition 4K more accurately or HDR RF cable content, connect the 4K compatible equipment to HDMI1 or 2 terminal. Satellite receiver ● Connect the 4K compatible equipment to HDMI Terrestrial aerial terminal using a 4K compatible cable and you can...
- Page 12 ■ ■ Common Interface Camcorder / Game equipment ● Turn the TV off with Mains Power On / Off switch (VIDEO equipment) whenever inserting or removing the CI module. ● If a smart card and a CI module come as a set, first insert the CI module, then insert the smart card into (Viewing) the CI module.
-
Page 13: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. 8 [Option Menu] Remote Control ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ● Used for the selection, navigation and operation of various functions. - Page 14 ■ Installing / Removing batteries Indicator / Control panel ● When pressing 4, 5, 6 buttons, the control panel guide appears on the right side of the screen for Pull open 3 seconds to highlight which button has been pressed. Hook Close Note the correct...
-
Page 15: First Time Auto Setup
First time Auto Setup If tuning has failed check the RF cable, and the network connection, and then follow the on-screen instructions. Note ● The TV goes into Standby mode when no operation When the TV is turned on for the first time, it will is performed for 4 hours if [Auto Standby] in the Timer automatically search for available TV channels and give Menu is set to [On]. -
Page 16: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... - Page 17 ● To scroll the description (if more than 1 page) While the description is highlighted ● To open the reference screen ( ● To display the menu related to the description (only for some descriptions) (red) ● To check the features of this TV Search by Purpose >...
-
Page 18: Faqs
(p. 14) to your local electrical retailer, contact your local ● Has the TV been switched on? Panasonic dealer or visit freeview.co.uk/retune ● The batteries may be running low. Replace them with Re-tuning only takes a few minutes, just follow the new ones. -
Page 19: Maintenance
Maintenance Specifications First, remove the mains plug from the ■ mains socket. Model No. : TX-49EX580B Display panel, Cabinet, Pedestal 49-inch model : TX-55EX580B 55-inch model Regular care: Gently wipe the surface of the display panel, cabinet, Dimensions (W × H × D) - Page 20 HDMI 1 / 2 / 3 input Operating conditions TYPE A Connectors Temperature HDMI1 / 3: 0 °C - 35 °C 4K, Content Type, Deep Colour, x.v.Colour™ Humidity HDMI2: 20 % - 80 % RH (non-condensing) 4K, Content Type, Audio Return Channel, Deep Colour, x.v.Colour™...
- Page 21 ■ When using the wall-hanging bracket Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ● Holes for wall-hanging bracket installation Rear of the TV 49-inch model a: 400 mm b: 200 mm 55-inch model a: 400 mm...
- Page 24 • Or go on line through our Internet Accessory ordering application at www.pas-europe.com. • Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are provided directly by Panasonic UK. • It couldn’t be simpler! • Also available through our Internet is direct shopping for a wide range of finished products. Take a browse on our website for further details.
