The contents of this document are protected by copyright laws and international treaties. Any reproduction or distribution of this document or any portion of this document, in any form by any means, without the prior written consent of ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations.
Chapter Safety Instructions Special Note • Remove the plastic covering before using the Set-Top Box to provide normal ventilation. • Use the power adapter provided with the Set-Top Box. Important Safety Instructions • Ensure that the electric voltage meets the device requirements. Check the cables periodically, replace any damaged cables immediately.
Page 5
• The power cable or power socket is damaged. • There is any liquid leaks into the device. • Fails to run normally even after following the instructions. • The device is physically damaged. RF exposure information: The Maximum Permissible Exposure (MPE) level is calculated based on a distance of d=20 cm between the device and the human body.
FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 7
Quantity Item Remarks HDMI cable MINI-AV cable Ethernet network cable Power adapter User Guide Qualification Certificate/ WARRANTY Notes: This packing list is for reference only. The items actually delivered depend on the companion packing list of the STB. Contact the provider immediately if parts are missing or damaged.
Chapter Panels 3.1 Front Panel Name Description Power indicator Red: STB is in standby state. Blue: STB is running normally. Not Lit: STB is not powered on. 3.2 Rear Panel Name Description Power Press it to turn on/turn off STB. switch DC +12 V Power input socket, +12 V DC power adapter...
Name Description Consult technical personnel before using other types of power adapter. Audio and composite video output interface. HDMI HDMI output interface. 10 M/100 M Base-T RJ45 self-adaptive Ethernet interface. SPDIF Digital audio interface, which can be connected to a power amplifier. 3.3 Side Panel Name Description...
Chapter Connecting Up 4.1 Connecting Network This section introduces the network connection methods for STB. Select one method to connect according to the on-site conditions. 4.2 Video and Audio Connections Steps Connecting Standard Definition Interface Connect the R and L interfaces on the TV to the corresponding interfaces with the AV cables.
Page 11
Connecting High Definition Interface Connect the HDMI interface on STB to the corresponding interface on TV with the HDMI cable, as shown in the follow figure. —END OF STEPS—...
4.3 Power ON Steps 1. Ensure that all cables are connected correctly. 2. Install the power cable to STB using the power adapter and to AC power source. 3. Ensure that all other devices are plugged in and receiving power. 4.
Notes: • The remote control provided depends on the IPTV service provider. The appearance of remote control shown is for reference only. • The remote control is powered by two AAA batteries. Insert two AAA batteries into the remote control according to the polarity instruction displayed on it.
Chapter Operation Guide Common Operations Switch between the standby and working state. Press the key on the remote control to enter the Launcher. Press direction keys (up, down, left, and right) on the remote control to select an EPG item (such as button, text box and column).
Press key to pause the program. Press key again to resume the program. Input Operation Change the input method. Pairing operation Press the button for 3 seconds, start the match. The remote control indicator light need continued rapid flashing 30 s,we can’t cancel the pairing mode or flash light mode in the pairing time .After 30S the indicator light goes out to exit the pairing mode.
Page 17
Problem Possible Cause Solution power adapter with a new one. The power outlet has Check and ensure the no power. power outlet has power. User cannot The network cable has Connect the network connect to the not been connected cable properly or replace properly.
Page 18
Problem Possible Cause Solution down. remote control, or increase the volume of the STB or TV. The remote The remote control is Change a new Bluetooth control fails. physically damaged. remote control. The Bluetooth pairing fails. Press at the same time for 3 seconds, start pairing.
Chapter Technical Specification Compliant GB4943.1-2011, GB9254-2008 Standard Power Adapter Input: 100 V ~ 240 V, 50 Hz ~ 60 Hz Output: +12.0 V DC Environment Working environment temperature: +32 ℉ ( 0 ℃ ) ~ Requirement +104 ℉ ( +40 ℃ ) Working environment humidity: 5% ~ 95% Protocol TCP/IP, HTML 4.0, HTTP 1.1/JavaScript 1.5, NTP,...
Page 20
Suround, Single/Dual/Multi Track, and Stereo Dimension 108 mm × 108mm × 23 mm (Length × Width × Height ) Weight 0.2 kg HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
