1. Assembly Instructions:

1. Unpack all items carefully and check parts.
2. Folding instructions:
3. Attach wheels to axles by pushing the easy release
knobs on the outside of the wheels and inserting the
wheels into the axle. Make sure to continue pushing
the easy release knobs on the outside of the wheels
while sliding the wheels into the axles. Test that the
wheels are locked in by giving each wheel a firm pull
to ensure it does not slide out of the wheel's pin.
4. Attach accessories starting with the accessory
station. For further instructions click on the "support"
tab on our website www.caddydriver.com and scroll
down to the instructional videos section.

2. Handle Controls:

1. Distance (remote), 10/20/30(handle)
Auto Function
When pressed, the 10, 20, and 30 buttons will display
on the screen either an A, B, or C and your
Caddydriver will run for 10m, 20M, or 30M
respectively, and then stop automatically.
*Tip Always turn your remote control "OFF" when
you put it in your pocket to ensure if any buttons are
pressed while in your pocket the cart will not go
anywhere!
2. Power Button:
1. ON/OFF Button: Hold for 2 seconds until the lights
come on to turn your Caddydriver On and Off.
3. Speed Controller
Scrolling of the speed dial lets you choose your
preferred speed to suit your pace perfectly, and the
display will show the preferred speed. The speed level
is from 1 to 9.
4. GO/stop Button(handle):
Press to start your cart with the handle at the same
speed that it stopped. Or press to stop your cart.
5. LED Display:
The green, yellow, and red LEDs on the handle
indicate the level of charge of the battery. All on
indicates a high charge, just yellow and red indicates
medium charge and just red indicates a low charge.
*note – the cart should be in motion for the most
accurate reading.
