Summary of Contents for HYFIX MobileCM Base-Station
- Page 1 MobileCM Base-Station for G EODNET Manual Release Number Author Date Comments 0.2.0 Mike Horton Feb 4, First release: GNSS Antennae Installation 2022 and Basic Network Connection...
-
Page 2: Table Of Contents
SET UP YOUR MINING ACCOUNT ON THE CONSOLE ............. 9 LEARNING MORE ........................10 5.1. GNSS S & S ..................10 YSTEM PACE EATHER 5.2. GNSS C ............. 10 ORRECTION ETWORKS FOR RECISE OCATION DEBUG AND GETTING HELP ....................10 HYFIX MobileCM Base-station Manual Page 2 of 12... -
Page 3: Unpack & Power On
1. Unpack & Power On HYFIX's MobileCM Station Kit contains the following items: MobileCM GNSS (Space Weather) Receiver GNSS (Space Weather) Antenna Primary Antennae Cable WiFi Antennae USB-C Power Cable Brackets Bag Antennae Mounting Rod To configure and connect the MobileCM (Section 2), you will need a Windows 10 PC or MAC computer and be nearby the WiFi network you intend to use for data transmission. -
Page 4: Antennae Ports
Used for configuring Internet connection. (http://192.168.4.1) BLINKING (FAST): Attempting to Connect to Internet via Configured SSID and Password SOLID, Internet is connected. 1.5. Android Set-Up App Bluetooth-based Set-up App Coming in Q3 2022 time-frame. HYFIX MobileCM Base-station Manual Page 4 of 12... -
Page 5: Wifi Connection And Internet Setup
If the connection was not successful, the GREEN LED will eventually stop blink and begin blinking slowly … reverting to AP Mode. While slowly blinking, repeat step 2.1 double checking your SSID and Password for the WiFi network. HYFIX MobileCM Base-station Manual Page 5 of 12... -
Page 6: Open Mobilecm Webui (Station Mode)
MobileCM’s debug serial port (See section 6 Debug). Enter the assigned IP address to your web browser and the following configuration page will appear. In this example that is 10.0.0.233 and a screen appears below. HYFIX MobileCM Base-station Manual Page 6 of 12... -
Page 7: Set Miner Key And Transmit Data To Geodnet
MobileCM. Go to the Network Settings link from the main page. Again, be sure your PC or MAC is on same WiFi SSID as the newly configured SSID and repeat step 2.2. HYFIX MobileCM Base-station Manual Page 7 of 12... -
Page 8: Gnss Space Weather Antennae Installation
[7], and then connect the primary antennae cable [3]. Connect the other end of the antenna cable to the MobileCM GNSS port. Turn MobileCM back on and after a few HYFIX MobileCM Base-station Manual Page 8 of 12... -
Page 9: Rf Extension Cables
30m using a female-to-female TNC adapter, and additional low-loss RF cable with TNC male connectors. Alternatively, you can extend the cable, using a low-loss TNC female to TNC male cable. 4. Set Up Your Mining Account on the Console Coming Soon…. HYFIX MobileCM Base-station Manual Page 9 of 12... -
Page 10: Learning More
Step 2: Find the list of four virtual COM ports which will automatically appear. The debug port is the lowest numbered port number in the group of four ports created by the MobileCM. HYFIX MobileCM Base-station Manual Page 10 of 12... - Page 11 Step 4: Issue Commands Using a Terminal Program. Note the <CR><LF> at end of each string is required. Serial Command Action +HYFIX,DEVMODE,AP#<CR><LF> Erases the SSID and Password, so the device will be in AP Mode +HYFIX,WIFISTATUS?#<CR><LF> Returns connection status and MobileCM IP address if Connected +HYFIX,SN?#<CR><LF>...
- Page 12 STATION INSTALLATION RECORD It is recommended to record the following data from your installation. Station Serial Number SSID of Internet Connection MobileCM WebUI IP Address My Miner Key Installation Location HYFIX MobileCM Base-station Manual Page 12 of 12...
