- Page 1 5” CAR BABY MONITOR HD Wireless Baby Monitor For Your Car WP ITM. TT002 Care & Use Instructions for TT002B / TT002W Important, retain for future reference: Read carefully...
- Page 2 IF YOU ARE EXPERIENCING ANY ISSUES WITH THE PRODUCT DURING OPERATION, DO NOT RETURN THE PRODUCT TO THE STORE. CONTACT TINY TRAVELER™ DIRECTLY FOR INSTRUCTIONS ON HOW TO RETURN/EXCHANGE THE PRODUCT. PLEASE KEEP YOUR ORIGINAL RECEIPT AS PROOF OF PURCHASE MUST BE PROVIDED. FULL WARRANTY INFORMATION IS INCLUDED IN THIS USER MANUAL.
-
Page 3: Table Of Contents
3. Package Contents ........................6 4. Product Specifications ......................7 5. Product Overview ........................7 6. Tiny Traveler™ Monitor & Camera LED Indicators ..............8 7. Recording Time ........................9 8. Technical Specifications ......................9 9. Installation Guide ........................10 10. -
Page 4: Introduction
Thank you for purchasing the Tiny Traveler™ 5” Car Baby Monitor. Designed by our family with your family in mind. Tiny Traveler™ is set out to create simplified tech to keep your little ones safer. The 5” Car Baby Monitor is essential for any trips in the car or at home to safely monitor your baby. It’s packed with features such as a HD Touch Screen Monitor, night vision, and the ability to view rear or forward facing car seats. - Page 5 • The Tiny Traveler™ 5” Car Baby Monitor is not a toy. At no time should children be allowed to play with it. It should only be operated by adults who have read the safety and operating instructions listed in this manual.
-
Page 6: Package Contents
Car Camera (Class 10) with Built-in Battery 2 x 9.8’ / 3m Micro USB Power Cable 33” / 84cm Camera Tiny Traveler™ Micro USB Cable On Board Sticker Spring Loaded Clamp (With Data Pin) Camera Headrest Mount Monitor 2 x USB Adapter... -
Page 7: Product Specifications
4. PRODUCT SPECIFICATIONS Frequency: 2.4 GHz Camera Resolution: HD 720P Camera Viewing Angle: FOV(H) 79º Operating Temperature: 14ºF ~ 122ºF (-10ºC ~ 50ºC) Operating Voltage: DC 5V (Micro USB) Maximum Signal Range: 33 Feet / 10 Meters (without interference or obstruction) 5. -
Page 8: Tiny Traveler™ Monitor & Camera Led Indicators
Micro SD Slot 3.46” / 88 mm 5.86” / 149 mm 0.74” / 19 mm 6. TINY TRAVELER™ MONITOR & CAMERA LED INDICATORS Power / Mode Status 5” Touch Screen Monitor Camera Power On Blue LED light stays on. Monitor powers on when the engine is turned Blue LED light stays on. -
Page 9: Recording Time
7. RECORDING TIME Memory Card Maximum Recording Time Maximum Recording Time Maximum Recording time Capacity (1 Minute Loop Record) (3 Minutes Loop Record) (5 Minutes Loop Record) 16GB Up to 890 minutes Up to 890 minutes Up to 890 minutes 32GB Up to 1,000 minutes Up to 1,900 minutes... -
Page 10: Installation Guide
9. INSTALLATION GUIDE Camera Placement and Operation Before selecting which camera mount to use, it is best to determine where in the car the Camera will best be placed in order to capture the image of your baby’s car seat. Make sure the Camera is not located near the airbag. - Page 11 Option 2: Spring Loaded Clamp To mount the Camera using the Spring Loaded Clamp, place the clamp around the headrest pole that best suits the Camera placement that is needed. Attach the Camera on the bracket of the clamp. Adjust the angle of the Camera by loosening the nut and rotate to your desired angle.
-
Page 12: Connect To Power
10. CONNECT TO POWER Powering the Camera and Monitor The 5” Car Baby Monitor comes with two USB Power Adapters and two 9.8’ (3m) Micro USB Power Cables which can be plugged into any available sockets in your vehicle. Starting with the power cable at the base of the Camera, run and tuck the cable to the available socket you wish to plug into. -
Page 13: Initial Setup
Usage Precautions Many vehicles provide constant power to the 12/24V outlet. If your outlet provides constant power, please remember to unplug the LCD Touch Screen Monitor and Camera when not in use to avoid draining of the vehicle’s battery. 11. INITIAL SETUP MicroSD Card (Pre-installed) NOTE: If you use your own MicroSD card please insert it into the Monitor and use the... -
Page 14: Pairing The Camera
No camera pairing is needed as the Tiny Traveler™ Car Camera is already paired with the 5” LCD Monitor. However, if you purchase the Tiny Traveler™ Add- On Camera (TTCAMB / TTCAMW, sold separately), you need to pair the Add-On Camera by following these steps: System Setting. -
Page 15: Configuration & Menu Setting
Tap on Tips icon for on-screen instructions. Split Screen If you purchase the Tiny Traveler™ Add- On Camera (TTCAMB / TTCAMW, sold Split separately), you can tap the... - Page 16 Menu Tree: See below for the settings to be found under each submenu: System Settings Camera Settings Monitor Settings Pair Camera Contrast Loop Record Gallery Saturation Warning Image Date & Time Rotate Camera Screen Save Format Voice Activation Monitor Brightness Default Setting Night Vision Language...
- Page 17 Camera Settings NOTE: Camera settings are not available in Split 5. Night Vision - Swipe the slider to adjust night Screen Mode. You must switch to Camera 1 or vision exposure level or to disable night vision. Camera 2 by tapping the Split Screen Mode Icon before configuring any camera settings.
-
Page 18: Safety Information
This limited express warranty shall be the exclusive remedy of the purchaser and Tiny Traveler™ makes no other warranty of any kind aside from the limited express warranty stated above. - Page 19 Conditions of Warranty If during the 1 year warranty period your new product is found to be defective, Tiny Traveler™ will repair such defect, or replace the product, without charge for parts or labor subject to the following conditions: •...
-
Page 20: General Information
PARTICULAR PURPOSE. Tiny Traveler™ and/or its affiliates do not guarantee or promise that the user of the 5” Car Baby Monitor will not be in an accident or otherwise not collide with an object and/or person. Our 5” Car Baby Monitor is not intended in any way to be a substitute for careful and cautious driving or for the consistent adherence to all applicable traffic laws and motor vehicle safety regulations. - Page 21 FCC Compliance Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 22 The battery is self-contained and not consumer replaceable. The battery must be disposed of properly when it no longer holds a charge. Proper charging practices will increase the life of the product. For information on battery recycling, call toll-free 800-822-8837. Tiny Traveler™ 5” Car Baby Monitor HD Wireless Baby Monitor For Your Car TT002 Responsible Party: Tiny Traveler™...
- Page 24 A Horizon Brands Company 2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626 1.866.294.9244 info@mytinytraveler.com © 2021 ADC Solutions Auto, LLC. All rights reserved. www.mytinytraveler.com @mytinytraveler ML-532387_V1...
