- Page 1 OPERATION GUIDE TORNADO 4-Gallon 18V Battery Powered Backpack Sprayer Model #: SMSAAH-2...
- Page 2 If there is pressure in the pump, do not try to remove it with tools. Do not try to make modifications to the sprayer. Always use SprayMate™ branded replacement parts from the manufacturer. Never spray flammable, caustic, acidic, chlorine, or other corrosive solutions or heat, pressure, or gas producing chemicals.
- Page 3 The sprayer is susceptible to water damage if left in wet conditions. Always store it in a cool, dry place. Always use SprayMate™ original replacement parts. Do not leave the sprayer in reach of children or persons not qualified to handle it in a proper fashion.
- Page 4 REGISTER YOUR SPRAYER! To take advantage of the 1-year Limited Warranty from WESSOL, LLC. Register your sprayer at the website below: www.buyspraymate.com/register LET’S Please read and follow this manual carefully to ensure that you get the most out of your new sprayer. If you need assistance with the assembly or operation of your sprayer, please don’t hesitate to contact WESSOL, LLC via the support methods below: www.buyspraymate.com...
- Page 5 TABLE OF CONTENTS page 6-7 ABOUT specifications....................page 6 what’s in the box..................page 7 page 8-10 SET UP backpack sprayer assembly................page 8 spraying.......................page 9 aftercare.....................page 10 page 11-15 TROUBLESHOOT common solutions..................page 11 replacement parts..................page 12 warranty.....................page 14 Copyright © WESSOL, LLC...
- Page 6 2-3x more efficiency than a manual sprayer. This sprayer can be operated continuously for up to 2 hours and spray at a distance of 25 feet. SprayMate™ Tornado Specifications Model Number SMSAAH-2 Pump Type...
- Page 7 Tank Intake Filter 4-Gallon Tank 4. Top & Bottom Holsters 5. Backpack Straps 6. 5-Foot Hose WHAT’S IN Carbon Fiber Spray Wand Lithium-Ion Battery THE BOX? In-line Spray Handle Battery Charger 11. Nozzle Thread Adapter 12. Adjustable Cone Nozzle 13. 110º Fan Nozzle Copyright ©...
- Page 8 STEP 1. ASSEMBLING YOUR SPRAYER Required tools: Phillips head screwdriver Before you begin, open the tank lid (1) and remove Place the top wand holster (4) on the proper location any nuts and bolts that may be placed inside the on tank.
- Page 9 STEP 2. PREPARING TO SPRAY Fully charge the battery (8) prior to first Turn the pump on by flipping the power switch on operation. In a separate container, prepare the side of the unit. Position “I” will activate the the solution you want to spray according to the pump at 45 psi while postion “II”...
- Page 10 STEP 3. AFTER YOU FINISH SPRAYING Dispose of extra product based on manufacturer’s Dry the sprayer tank and clear the nozzle or wand instructions. Rinse out any residual solution in the attachment of any buildup. spray tank with warm, soapy water. Then spray fresh water through the sprayer for 3 to 5 minutes to completely clear the tank of chemicals.
- Page 11 TROUBLESHOOTING YOUR SPRAYER To contact Technical Support, message support@wessol.com or call 1 (803) 339-2500 PROBLEM POSSIBLE REASON(S) SOLUTION Charge the battery. If the battery will not charge, test the charger or call Support at (803) Dead battery 339-2500 for a replacement if applicable. Sprayer is not turning on Loose/worn connections on power Remove back plate.
- Page 12 REPLACEMENT PARTS & ACCESSORIES Visit buyspraymate.com to view and purchase parts. 2. FZAAEP 1. FZAAEN 21V/1Ah Charger 18V/2.6Ah Battery 6. FZRAED 5. FZRADK 3. FZRABW 4. FZRADE Carbon Fiber Backpack Straps In-line Spray Handle Intake Filter Spray Wand 9. SMRAEP 10.
- Page 13 14. FZAABB 13. FZAABD 11. FZRACM 12. FZRAFC 110º Fan Nozzle Adjustable Cone Standard/Dual- Inlet Filter Nozzle Pressure Pump Copyright © WESSOL, LLC...
- Page 14 WESSOL,LLC LIMITED WARRANTY WARRANTY COVERAGE WESSOL, LLC warrants to the original purchaser that the SprayMate product will function as intended under ™ normal use and consistent maintenance, subject to certain limitations and exclusions. At the discretion of WESSOL, LLC, we will repair or replace any parts found to be defective in material or workmanship without charge, apart from shipping and handling costs, during the covered warranty period.
- Page 15 EXCLUSIONS AND LIMITATIONS WESSOL, LLC only warrants products purchased from authorized distributors. Products purchased from unauthorized resellers or distributors are not subject to warranty services. The limited warranty does not cover damages, loss, or injury resulting from transportation, storage, accident, improper use, neglect, modifications, normal wear, or operation not in accordance with the instruction manual.
- Page 16 buyspraymate.com +1 (803) 339-2500 support@wessol.com...
