SPECIFICATIONS
Product Weight
Material
Normal Operating Temperature
Operating / Storage Humidity
Certifications
Type Lithium-ion Battery
Voltage
Capacity
Cycle Life
DC Input Port
USB-C PD Port
Total
USB-A(1)
USB-A(2)
DC Output & Car port
USB-C(1) PD Port
USB-C(2) PD Port
AC Output
Total Continuous Output
4
General
3.2kg / 7lbs
PC + ABS
0-40 ℃ / 32-104 ℉
45-95%
FCC, CE, PSE, RoHS
Battery
Lithium-ion
14.8V
296Wh/80000mah
≥500
Input
10-25V/5A, 60W Max
60W Max
120W Max
Output
5V/2.4A, 12W Max
QC3.0 18W Max
12V/10A Shared 120W Max
65W Max
18W
110V/60Hz(Pure Sine Wave 300W Rated )
300W
RECHARGING YOUR PULEIDA PU-300
CAUTION
· To maximize battery life, be sure to fully recharge your Puleida PU-300
before operating or storing
NOTE
· To shorten the recharge time of Puleida PU-300, it is recommended to
disconnect all loads while recharging the unit
Recharge Time
・Recharge via Solar: 4 Hours
・Recharge via AC/DC Adapter: 5.5 Hours
・Recharge via USB-C PD 60W Wall Charger: 5.5 Hours
・Recharge via both AC/DC Adapter and USB-C PD Wall Charger: 2.5 Hours
NOTE
· The above recharge times are based on conditions when the Puleida
PU-300 is recharged at full speed with no loads connected to it.
Recharging via Solar
・For optimal recharging performance, it is strongly recommended to recharge your
Puleida PU-300 using a compatible solar panel (not included) on bright sunny days
free of scattered clouds.
・Place the solar panel under direct sunlight. Steer clear of trees or branches that can
shade the solar panel and slow down the recharging process
・Use the Solar Panle Connectors to DC Adapter Cable to connect the solar
panel to the DC Input Port of your Puleida PU-300 and place your Puleida PU-300 in
the shade to prevent it from overheating.
NOTE
· Electrical shock can occur if the Solar Panle Connectors to DC Adapter
Cable is damaged or frayed. DO NOT use a damaged or frayed cable to
recharge your Puleida PU-300.
CAUTION
· Make sure the open circuit voltage of the solar panel does not exceed
25V or fall short of 10V.
NOTE
· The solar recharge time is highly dependent on solar irradiance and
ambient temperature.
5
