Washing machine
WAG14060IN
en Operating and Installation Instructions

Advertisement

Table of Contents
loading

Related Manuals for Bosch WAG14060IN

Summary of Contents for Bosch WAG14060IN

  • Page 1 Washing machine WAG14060IN en Operating and Installation Instructions...

  • Page 2: Table Of Contents

    Table of Contents Operating instructions Information concerning waste disposal ..4 Protection of the environment / hints and tips ..5 General safety instructions ....6 Introducing your washing machine .
  • Page 3 Further information and a selection of our products can be found on our internet page: http://www.bosch-home.com Please read the operating and installation instruc- tion supplied and handle the appliance accordingly. These operating and installation instructions describe various models.

  • Page 4: Information Concerning Waste Disposal

    Operating instructions Information concerning waste disposal Disposing of the The shipping package has protected your new packaging appliance on its way to your home. All utilised materials are ecologically harmless and recyclable. Please contribute to a better environment by disposing of packaging materials in an environmentally conscious manner.

  • Page 5: Protection Of The Environment / Hints And Tips

    Protection of the environment / hints and tips Your washing machine uses water, energy and detergent efficiently, thereby protecting the environment and reducing your household costs. See page 32 for consumption values of your appliance. Using your washing machine in an efficient and Hints and tips environmentally friendly manner: Do not exceed maximum load.

  • Page 6: General Safety Instructions

    General safety instructions Your washing machine is intended for – use in the household only, – for washing machine-washable fabrics in washing lye, – operation with cold drinking water and commercially available detergents and cleaning products which are suitable for use in washing machines.

  • Page 7: Introducing Your Washing Machine

    Introducing your washing machine Adding detergent/cleaning product Dispenser I: Detergent for prewash or starch, Dispenser II: Detergent for main wash, soaking agent, water softener, bleach or stain remover, Dispenser M: Additives, e.g. fabric softener or former (do not fill above the lower edge of the insert 1).
  • Page 8 Control panel Start Soaking A button Programme selector For starting the washing cycle /soaking For switching the machine on and off and for the laundry. selecting the programme. (programme must have been selected). Can be rotated in either direction. The programme selector does not rotate while the programme is running, the programme sequence is electronically controlled.

  • Page 9: Before Using Your Washing Machine For The First Time

    Before using your washing machine for the first time Preparing your Attention washing machine The washing machine must have been installed and connected properly (refer to page 34). ² The washing machine was tested before leaving the factory. To remove any water left over from testing procedures, the first washing cycle should be carried out without laundry in the machine.

  • Page 10: Preparing, Sorting And Loading The Washing

    Preparing, sorting and loading the washing Preparing the washing Warning Loose debris (e.g. coins, paper clips, needles, nails) can damage items of clothing as well as parts of the washing machine (e.g. drum). Empty all pockets on items of clothing. ■...
  • Page 11 Degrees of dirt Lightly soiled No visible soiling or stains. Washing has probably absorbed body odour. – Light-weight summer clothing and sportswear worn for several hours. – T-shirts, shirts, blouses worn for up to one day. – Bed linen, guest towels used for one day. Normally soiled Visible soiling and/or a few light stains.
  • Page 12 Removing stains Remove/pretreat stains as soon as possible after they have occurred. First dab with a soapy solution. Do not rub. Then select the appropriate programme and wash the item. Stubborn/dried in stains can sometimes only be removed by washing several times. Sorting washing according Only wash laundry that is labelled with the following to the instructions on the...
  • Page 13 Loading the washing Risk of explosion! Items of clothing that have been pretreated with solvent-based cleaning agents, e.g. stain remover and dry cleaning spirit, represent an explosion hazard once loaded into the washing machine. Before loading the laundry, rinse thoroughly by hand. Warning Foreign objects in the drum may damage the laundry.

  • Page 14: Detergents And Cleaning Products

    Detergents and cleaning products Dosing detergent Risk of poisoning! Keep detergents and additives out of the reach of children. Dose detergent according to the water hardness. You can find out the water ■ hardness from your water utility company. the amount of laundry. ■...
  • Page 15 Adding detergent/ Dispenser I cleaning product Detergent for prewash or starch. Dispenser II Detergent for main wash, water softener, pre-soaking agent, bleach and stain removal product. Dispenser Cleaning product, e.g. fabric softener or fabric conditioner (do not fill above the lower edge of the insert 1: MAX).

  • Page 16: Programmes And Functions

    Programmes and functions Select the desired programme. For maximum spin speeds of the programmes see Page 18. Programme selector Basic programmes Cotton cold, 30, 40 Dark Load , 60°C For hard-wearing textiles, e.g. made of cotton or linen. Cotton 90°C T Prewash Energy-intensive programme for heat-resistant textiles, e.g.
  • Page 17 Programme options Rinse Rinse cycle with subsequent spin cycle for rinsing hand-washed items or for starching. Spin Í Spin cycle for spinning hand-wash items. Washing water or rinsing water is drained before the spin cycle. Additional options ­ buttons The washing time is extended so that highly soiled Intensive washing or 5.5 kg of cottons/coloureds are washed more intensively.
  • Page 18 , Silk n and Wool programmes the washing machine spins at a low speed- for gentle treatment of delicate laundry. Maximum spin speeds Revolutions per minute Type of laundry/Programme options WAG14060IN Cotton Easy Care Silk Wool Rinse Spin Unbalanced load detection system...

  • Page 19: Washing

    Washing Turn on water tap. ■ Start programme Turn the programme selector to the desired ■ programme. “ready/wash” indicator light flashes. If required, press the button(s) for additional ■ option(s). The indicator light of the selected button is on. Press the Start Soaking A button. ■...
  • Page 20 Changing the If you have accidentally selected the wrong programme programme : Turn the programme selector to Off. ■ Turn the programme selector to the desired ■ programme. “ready/wash” indicator light flashes. Press the Start Soaking A button. ■ “ready/wash” indicator light comes on. The new programme starts.

  • Page 21: When The Programme Has Ended

    When the programme has Ended “spin/end” indicator light flashes. Turn the programme selector to Off. ■ ² If required: Select an additional programme (Spin Íor Rinse ■ Press the Start Soaking A button. ■ At the end of the programme option, turn the ■...

  • Page 22: Special Applications

    Special applications Soaking Load laundry of the same colour. ■ Pour soaking agent into dispenser II according to ■ the manufacturer's instructions. Set the programme selector to Cotton 30°C . ■ Press the Start Soaking A button. ■ The programme starts. After approx.
  • Page 23 Dyeing Only use dyes that are environmentally compatible and suitable for use in washing machines. Caution Washing in subsequent wash cycles may become discoloured. Apply dyes according to the manufacturer's ■ instructions. After dyeing: ½ Pour approx. measuring beaker of detergent into ■...

  • Page 24: Cleaning And Care

    Cleaning and care Risk of electric shock! First, always disconnect the appliance from the power supply. Never clean the appliance with a water jet. Risk of explosion! Never clean the appliance with solvents. Clean the appliance As required: housing and control Use hot soapy water or a mild, non-abrasive ■...
  • Page 25 Cleaning the detergent In the event that residual detergents or additives have dispenser accumulated: Pull out the detergent drawer all the way, ■ press down the insert and ■ remove the detergent drawer. ■ Open the cover. ■ Clean the detergent drawer and cover under ■...
  • Page 26 Cleaning the drain This is necessary if the washing solution has not been pump completely drained. The pump is blocked by either loose debris or fluff which accumulates if fluff-giving fabrics are washed. (Up to 20 litres. Have a suitable container ready.) Drain the water Risk of scalding! Allow the hot water to cool down beforehand.
  • Page 27 Cleaning water inlet This is necessary if very little or no water flows into the strainers washing machine. First, reduce the water pressure in the inlet hose: Turn off the tap. ■ Turn the programme selector to any programme ■ (except Spin Í).
  • Page 28 Descaling the washing Attention machine Descaling agents contain acids which may corrode the components of the washing machine and discolour the laundry. Provided that you use the correct amount of detergent, it is not necessary to descale the washing machine. If descaling is nevertheless required, please follow the instructions supplied by the manufacturer of the descaling agent.

  • Page 29: Troubleshooting Minor Faults

    Troubleshooting Minor Faults Risk of electric shock! Repairs may be carried out by customer service or authorised technicians only. If repairs are needed, and assuming that you cannot eliminate the fault yourself with the aid the following table: Turn the programme selector to Off. ■...
  • Page 30 Fault Cause Remedial action Programme does not start. Loading door not closed properly. Check whether laundry is trapped in The “ready/wash” and “rinse” door. indicator lights flash. Close the loading door (a click should be heard). Start Soaking A button not Press the Start Soaking A pressed.
  • Page 31 Fault Cause Remedial action The washing has not been spun Large laundry items have become Always load large and small items correctly. entangled and are not evenly together into the drum.(see also distributed in the drum. imbalance compensation system). For safety reasons, the high-speed final spin cycle was automatically cancelled.

  • Page 32: Consumption Values

    Consumption values Normal programme Additional Load Consumption values** Programme duration option Power Water 5,2 kg 0.38 kWh 51 l 0:39 h Cotton 30°C 2,6 kg 0.40 kWh 40 l 1:10 h Cotton 40°C Dark Load 5,2 kg 1.10 kWh 53 l 1:34 h Cotton 60°C...

  • Page 33: Customer Service

    Customer service Before you call customer service, please check whether you can eliminate the fault yourself (see from page 29). A technician who is called out to give advice will charge you, even if the appliance is still under guarantee. You can find your nearest customer service in the enclosed address list.

  • Page 34: Installing, Connecting And Transporting

    Installation instructions Installing, connecting and transporting Safety instructions Risk of injury! The washing machine is heavy. Take care when lifting it. Caution Frozen hoses may tear/burst. Do not install the washing machine in an area where there is a risk of frost or outdoors.
  • Page 35 Standard accessories – Water-inlet hose. – Water drainage hose – Elbow for attaching the drain hose e.g. into a wash basin. – Power cord. – Covers for holes left by removing the transport bolts. Depending on the connection situation, the following part is also required: Ø...
  • Page 36 Installation surface Appliance stability is important so that the washing machine does not "wander" during the spin cycles. The installation surface must be solid and level. Soft floor coverings, e.g. carpets or floor coverings with a foam backing are not suitable. If the washing machine is to be installed on a wooden floor: If possible, install the washing machine in a corner.
  • Page 37 Removing the Caution transportation The transport bolts must always be removed before protection devices using the appliance for the first time and must be retained for any subsequent transport (e.g. when moving). Release all screws A using the A/F 13 wrench until ■...
  • Page 38 Hose and-cable lengths Connection on left side 100cm 140cm Connection on right side 150cm 110cm Available from specialist dealers: Other hoses – Extended supply hose (approx. 2.20 m).
  • Page 39 Connecting the water Risk of electric shock! To prevent leaks or water damage, it is essential to follow the instructions in this chapter! Water inlet hose Warning Operate the washing machine with cold drinking water only. Do not connect to the mixer tap of an unpressurised hot-water apparatus.
  • Page 40 Water drainage hose Warning Do not bend or pull the water drainage hose. Height difference between the placement area and drainage point: maximum 100 cm. Drainage into a siphon: Ø Secure connection point with 24-40 mm hose ■ clip (specialist outlet). Drainage into a wash basin: Warning The plug must not block the drain of the wash basin.
  • Page 41 Connecting the power Caution Connect the washing machine only to an alternating current via a correctly installed earthed socket. The mains voltage must correspond to the voltage specification on the washing machine (nameplate). Connection specifications as well as the required fuses are stipulated on the appliance nameplate.
  • Page 42 Transport, e. g. when Before transporting the washing machine: moving – Turn off the tap. – Reduce the water pressure in the water inlet hose (refer to page 27). – Drain any residual washing solution (refer to page 26). – Disconnect the washing machine from the mains. –...
  • Page 43 WAG14060IN 0711en 9000 659 499 ROBERT BOSCH HAUSGERATE GMBH...
