Operation; Starting The Engine (Electric / Key Start) - ALDI Ferrex Ninja User Manual

224cc 4 Stroke Petrol Lawn Mower

Operation

Starting the Engine (Electric / Key Start)

NOTE: Before starting the mower check the oil and
fuel levels. The engine MUST be filled with 500ml
of SAE 10W/30 engine oil BEFORE starting. Fresh
unleaded fuel must be used in this unit.
WARNING: DO NOT use Ethanol based
fuels. Do NOT mix oil with fuel.
Warranty will be void if the engine becomes faulty
due to insufficient oil and fuel levels.
For starting, ensure the mower is set to the highest
height setting so the blades are not resting deep
into the grass.
NOTE: The engine of this lawn mower has an
automatic choke start and operation feature,
and no priming bulb, hence no priming or choke
adjustment is required before starting the engine.
1. Ensure the 20V Xfinity Li-ion battery (46) is
charged. If not, refer to the "Battery Charging"
section of the manual.
2. Insert the 20V Xfinity Li-ion battery (46) into the battery compartment
(42) at the rear of the tool and refreshment holder (3). A click will be
heard when the battery has engaged. (Fig. K1)
3. Turn the key (26) to the right to the "START" position to start the lawn
mower engine. The engine should start. (Fig. K2) Release the key (26) as
soon as the engine starts. The key (26) will automatically move back to
the "ON" position.
WARNING: Do not wash your lawnmower with the battery
inserted. Please store your battery in a dry safe place. Always
store your battery in a safe location and never leave outside.
AFTER SALES SUPPORT
1300 889 028
(toll free)
K1
K2
e-mail: info.aldi@positecgroup.com
MODEL No.: SLM531 • 10/2020 • 10093
Operation
29
