Page 1 Hoshizaki Hoshizaki America, Inc. Modular Crescent Cuber Models KM-650MAH KM-650MWH KM-650MRH INSTRUCTION MANUAL “A Superior Degree of Reliability” www.hoshizaki.com ™ Issued: 8-14-2006...
Page 2 HOSHIZAKI provides this manual primarily to assist qualiﬁed service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write or send an e-mail message to the HOSHIZAKI Technical Support Department. HOSHIZAKI AMERICA, INC.
Page 3: Table Of Contents
• Keep this manual with the icemaker for later reference. I. Speciﬁcations... 4 A. Nameplate Rating ... 4 1. KM-650MAH (air-cooled)... 4 2. KM-650MWH (water-cooled) ... 5 3. KM-650MRH (remote air-cooled) ... 6 B. Dimensions / Connections ... 7 1.
Page 4: Speciﬁcations
I. Speciﬁcations A. Nameplate Rating 1. KM-650MAH (air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE COMPRESSOR PUMP OTHER MAXIMUM FUSE SIZE MAX. HACR BREAKER(USA ONLY) MAX. CIRC BREAKER (CANADA ONLY) MINIMUM CIRCUIT AMPACITY DESIGN PRESSURE REFRIGERANT MOTOR-COMPRESSOR THERMALLY PROTECTED, See the nameplate for electrical and refrigeration speciﬁcations.
Page 5: Km-650Mwh (Water-Cooled)
Therefore, the necessary electrical and refrigeration information is also on the rating label, which can be easily seen by removing only the front panel of the icemaker. We reserve the right to make changes in speciﬁcations and design without prior notice. HOSHIZAKI ICE MAKER MOTOR-COMPRESSOR THERMALLY PROTECTED, NOT INTENDED FOR OUTDOOR USE! Hoshizaki America, Inc.
Page 6: Km-650Mrh (Remote Air-Cooled)
3. KM-650MRH (remote air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE COMPRESSOR PUMP FAN REMOTE OTHER MAXIMUM FUSE SIZE MAX. HACR BREAKER(USA ONLY) MAX. CIRC BREAKER (CANADA ONLY) MINIMUM CIRCUIT AMPACITY DESIGN PRESSURE REFRIGERANT MOTOR-COMPRESSOR THERMALLY PROTECTED, See the nameplate for electrical and refrigeration speciﬁcations.
Page 7: Dimensions / Connections
B. Dimensions / Connections Unit: mm (inches) 1. KM-650MAH...
Page 8: Km-650Mwh
Unit: mm (inches) 2. KM-650MWH...
Page 9: Km-650Mrh
Unit: mm (inches) 3. KM-650MRH...
Page 10: Installation And Operating Instructions
6) See the nameplate on the rear panel, and check that your voltage supplied corresponds with the voltage speciﬁed on the nameplate. 7) This icemaker needs a storage bin. The recommended storage bin is HOSHIZAKI ICE STORAGE BIN, Model B-300 series.
Page 11: Location
C. Location This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F(7°C) to +100°F(38°C); Normal operating water temperature should be within +45°F (7°C) to +90°F (32°C). Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity.
Page 12: Electrical Connection
E. Electrical Connection 1. Electrical connection must be made in accordance with the instructions on a "WARNING" tag, provided with the pig tail leads in the junction box. 2. This icemaker requires a ground that meets the national and local electrical code requirements.
Page 13: Installation Of Remote Condenser Unit
F. Installation of Remote Condenser Unit 1. Checks Before Installation 1) Unpack and remove shipping carton, tape(s) and packing. 2) Check that the refrigerant lines do not rub or touch lines or other surfaces, and that the fan blade moves freely. 2.
Page 14: Setup
The two copper tubings should be insulated separately. See Fig. 6. • Precharged tubing kits, available as optional equipment from HOSHIZAKI AMERICA, are recommended. 4) Line sets fabricated in the ﬁeld should be evacuated through the charging ports on the Parker quick connect couplings and charged with R-404A refrigerant vapor to a pressure of 15 to 30 PSIG.
Page 15: Electrical Connection
3) Connect the fan motor leads in the junction box of the remote condenser unit to the fan motor leads in the junction box of the HOSHIZAKI remote air-cooled icemaker. 4) Install a ground wire to the remote condenser unit.
Page 16: Stacking Condenser Units
5. Stacking Condenser Units 1) Secure the lower condenser unit to the legs with eight bolts (not included). 2) Attach the upper condenser unit on the top of the lower. 3) Secure the upper condenser unit with the four screws provided. 4) Install refrigerant lines, and make an electrical connection for each fan motor as shown in "3.
Page 17: Water Supply And Drain Connections
G. Water Supply and Drain Connections See Fig. 9 Do not operate the icemaker when the water supply is OFF, or if the pressure is below 10 PSIG (0.7 bar). Do not run the icemaker until the proper water pressure is reached. •...
Page 18 KM-650MAH KM-650MRH KM-650MWH Fig. 9...
Page 19: Final Checklist
H. Final Checklist 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F (7°C) to +100°F (38°C) all year around? 3) Is there at least 6" (152 mm) clearance around the icemaker for maintenance or service? 4) Have all shipping cartons, tapes and packing been removed from the icemaker? Is the cube guide in its correct position?
Page 20: Startup
I. Startup 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. 3. Do not operate the unit in the "WASH" position without water in the water tank.
Page 21: Cleaning And Maintenance Instructions
Ensure all components, fasteners and thumbscrews are securely in place after any maintenance or cleaning is done to the equipment. A. Cleaning Instructions 1. HOSHIZAKI recommends cleaning this unit at least once a year. More frequent cleaning, however, may be required in some existing water conditions.
Page 22: Cleaning Procedure
1) Dilute approximately 16 ﬂ. oz. (0.47 l) of recommended cleaner Hoshizaki "Scale Away" or "LIME-A-WAY," (Economics Laboratory, Inc.) with 3 gal. (11.36 l) of water. 2) Remove all ice from the evaporator and the storage bin. Note: To remove cubes on the evaporator, turn off the power supply and turn it on after 3 minutes.
Page 23: Sanitizing Procedure - Following Cleaning Procedure
21) Move the control switch to the "WASH" position. 22) Replace the front panel in its correct position. 23) Turn on the power supply to rinse off the cleaning solution. 24) Turn off the power supply after 5 minutes. 25) Remove the front panel. 26) Remove one end of the pump tubing.
Page 24: Maintenance
B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. 1. Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth. Use a damp cloth containing a neutral cleaner to wipe off oil or dirt build up. 2.
Page 25 5) Allow 5 minutes for the icemaker to ﬁll with water and the water pump to start operating. 6) Close the water-cooled condenser water supply line shut-off valve. See Fig. 9. 7) Open the drain valve for the water-cooled condenser water supply line. 8) Allow the line to drain by gravity.
Page 26 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com 91A1KN10A...
