• Do not expose the drive to extreme temperatures. Mounting Recommendations There are no screw holes or guide rails in the Microdrive 3K8 hard disk drive. Hitachi recommends you secure the drive by placing it in a frame with snubbers as shown in the...
Page 2
• To permit airflow, a 0.5mm gap on top and bottom should exist after device holding drive is assembled. • Give FPC (Flexible Printed Circuit) cable enough length to avoid excessive tension under shock condition. • Snubbers are available from 3 not produce any outgassing such as siloxane found in organic silicone oil.
Page 3
Electrical Information • Power Supply to be 3.3V +5% - 15%, 70mV max ripple, 400mA capable • Interface Signal Levels Input High Voltage 2.0 min Input Low Voltage 0.8 max Output High Voltage 2.4 max Output Low Voltage 0.5 min...
Page 4
Storage Technologies products, programs or services do not imply that Hitachi Global Storage Technologies intends to make these available in all countries in which Hitachi Global Storage Technologies operates. Product information is provided for information purposes only and does not constitute a warranty.
