- Page 1 Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi- do, 18103, Republic of Korea TEL : +82-31-8077-5000 / FAX : +82-31-624-5310 http://www.miniprinter.com T32EB ENG Rev. I 01/2021...
- Page 2 MODEL : SLK-T32EB SERIES Receipt Printer User’s Manual All specifi cations are subject to change without notice...
- Page 3 This device co mplies with part 15 of the FCC Rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Vic Barczyk 19700 S Vermont Ave Ste 200 Torrance, CA 90502 | USA sales@miniprinter.com...
- Page 4 Disposal of Old Electrical&Electronic Equipment(Applicable in the European Union and other European countries with separate collection systems) This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronics equipment.
-
Page 5: Table Of Contents
Table of Contents 1. Parts Identifications 2. Setting up the printer 2.1 Unpacking 2.2 Connecting the cables 2.3 Loading the roll paper 2.4 Adjustment of paper width 3. Control panel and other functions 3.1 Control panel 3.2 Error Indicating 4. Self Test 5. -
Page 6: Parts Identifications
1. Parts Identifications PRINTER COVER Open this cover to load or replace paper. POWER SWITCH Used to turn on/off power to the printer. CONTROL PANEL Features LED indica- tors to indicate printer status and switches to operate the printer. COVER OPEN LEVER Pull down this lever to open the printer cover. -
Page 7: Setting Up The Printer
2. Setting Up the Printer 2-1. Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. The Printer Roll Paper Adaptor(Optional) Interface Cable(optional) -
Page 8: Connecting The Cables
2-2. Connecting the Cables You can connect up the cables required for printing to the printer. They all connect to the connector panel on the back of the printer, which is shown below : CASH DRAWER CONNECTOR POWER CONNEC- INTERFACE INTERFACE CON- CONNECTOR(USB) NECTOR (SERIAL) - Page 9 2-2-1. Interface Connector 9 Pin Serial USB “B” Type 1 2 3 4 5 3 6 7 8 Status LED Link END Ethernet 9Pin Serial Interface SIGNAL Description Input Printer receive data line Output Printer transmit data line 4, 7 Output Data Terminal Ready System Ground...
- Page 10 USB Interface SIGNAL Data Out + Output Data + Data Out - Output Data - Data IN + Input Data + Data IN - Input Data - This equipment is indoor use and all the communication wirings are limited to inside of the building.
-
Page 11: Loading The Roll Paper
2-3. Loading the Roll Paper NOTE Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly. Turn off power switch. 1 Make sure that the printer is not receiving data;... - Page 12 5 Be sure to note the correct direction that the paper comes off the roll. 6 Pull out a small amount of paper, as shown. Then, close the cover. 7 Tear off the paper as shown.
- Page 13 CAUTION When the paper is jammed with cutter, the top cover might be stuck. In this case, repeat power on and off several times. If the top cover is still stuck, please follow the steps to release the papers from jamming. 1 Make sure the printer is turned off.
-
Page 14: Adjustment Of Paper Width
2-4. Adjustment of paper width 1 Please adjust the Paper Guide to fit to the paper width as the direction of arrow. 2 Tight the screw after adjusting the Paper Guide. 3 Pull the edge of paper once the paper roll is installed correctly and close the Paper Cover. -
Page 15: Control Panel And Other Functions
3. Control panel and other functions 3-1. Control panel You can control the basic paper feeding operations of the printer with the button on the control panel. The indicator lights help you to monitor the printer’s status Control Panel Button The button can be disabled by the ESC c 5 command. -
Page 16: Self Test
4. Self Test The self-test result indicated whether the printer is operating properly. Also with this, user can check following options or status of the printer. Control circuit Printer mechanism Printing quality ROM version Interface setting This test is independent of any other equipment or software. Running the self test 1 Make sure the printer is turned off and the printer cover is closed properly before performing the self test. -
Page 17: Ascii Print
5. ASCII Print ASCII PRINT is printing a test page constructed ASCII code. You can able to check the printer works properly with this The ASCII PRINT test automatically ends and cuts the paper after printing the following: *** Completed *** The printer is ready to receive data as soon as it completes the ASCII PRINT. -
Page 18: Paper Reduce
6-2. Paper Reduce Reduce menu (Line space, Line feed, barcode[1D] height) was developed for paper saving. - Line space “Line space” means the amount of feed when you intentionally generate newlines. - Line feed “Line feed” means the amount of feed when there is an automatic line break. - Barcode Height “Barcode Height”... -
Page 19: Printer Setting
7. Printer Setting Change the printer settings. The options below can also be changed via the Memory Saver. PRINTER SETTING 01 SELECT BAUDRATE 02 SELECT CUTTING MODE 03 SELECT ERROR BEEP OPTION 04 SELECT MELODY OPTION 7-1. Baudrate After entering the BAUDRATE MODE, the list which can select the BPS will be printed. Similar like Self Test, you can press the FEED button to select a BAUDRATE. -
Page 20: Melody
7-4. Melody To DK Port (Cash), Melody box or external buzzer can be connected. You can activate it from the Melody Setting menu, and the melody will operate after the cutting operation. - Melody Box : Melody is fixed and volume can be adjusted. - External Buzzer : 3 types of melody are output according to the Melody Type setting and volume control is not included. -
Page 21: Hexadecimal Dump
8. Hexadecimal Dump This feature allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you go into the hex dump function, the printer prints all commands and other data in hexadecimal format along with a guide section to help you find specific commands. -
Page 22: Printer Cleaning
9. Printer Cleaning If the interior of the printer is dusty, printing quality can be lowered. In this case, follow the instructions below to clean the printer. NOTE 1 Make sure to turn the printer power off prior to cleaning 2 Regarding print head cleaning, as the print head is very hot during printing, turn off the printer power and wait approximately 10 minute before start. -
Page 23: Specifications
10. Specifications Printing Method Direct Thermal T32EB - Max. 200 mm/sec Printing Speed T32EBⅡ- Max. 220 mm/sec Resolution 180 DPI / 203 DPI (Optional) Dot Pitch 0.141mm x 0.141mm Printing Width Max. 72mm Number of print columns Font A - 42 columns / Font B - 56 columns EAN-8, EAN-13, Code 39, Code 93, Code 128, ITF, UPC-A, UPC-E, Codabar Barcode... - Page 24 Guillotine Type T32EB - 1,500,000 cuts Cutter Life T32EBⅡ- 1,800,000 cuts 0.06 ~ 0.09mm Paper Thickness 100 ~ 240Vac 50/60 Hz Power 24Vdc / 1.75A 156 × 206 × 155 [W x D x H (mm)] Size (W x D x H) 1.7kg Weight 0 ~ 45℃...
-
Page 25: Command List
11. Command List Command Function REMARKS Horizontal tab Print and line feed Print and carriage return Print and return to standard mode(in page mode) Cancel print data in page mode DLE EOT Real-time status transmission DLE ENQ Real-time request to printer DLE DC4 Generate pulse at real-time ESC FF... - Page 26 Command Function REMARKS ESC t Select character code table ESC { Turn upside-down printing mode on/off FS p Print NV bit image FS q Define NV bit image GS ! Select character size GS $ Set absolute vertical print position in page mode GS * Define downloaded bit image GS /...
-
Page 27: Utilities
Printer F/W and Font Download are available, and Download Tool BT, Wi-Fi module F/W Download is supported as an (F/W) option. It is a utility app that prints text, barcodes, images, Android Utility etc. through Bluetooth and Wi-Fi communication, and (Sewoo M_Utility) able to printer settings. -
Page 28: S/W
Mac Driver in the Mac OS environment. Android Plugin This is a print service plug-in that allows you to print (Sewoo Print documents, images, and web pages without installing Service Plugin) additional apps. This is library for communication and data output with Thermal printer in Windows OS. - Page 29 Name Description This is library for communication and data output iOS SDK with Thermal printers in iOS. This is library for communication and data output Linux SDK with Thermal printers in Linux. P A T E N T...
