- Page 1 AquaView ™ Sand Filter with 7 Position Valve Model — 0-1709-014 14" Sand Filter Model — 0-1709-017 17" Sand Filter Model — 0-1709-020 20" Sand Filter Model — 0-1709-024 24" Sand Filter Owner's Guide 365-2078...
-
Page 2: Important Safety Instructions
“READ ALL INSTRUCTIONS.” Failure to follow these important safety instructions and other basic safety precautions may result in serious personal injury. IMPORTANT SAFETY INSTRUCTIONS DO NOT BURY CORD Before you begin installing your filter, PROPERLY SUPPORTED refer to your pump owners guide for An unexposed cord may accidentally Filter, pump and any other related very important installation and... -
Page 3: Installation
Did you read the IMPORTANT POSITIONING FILTER/PUMP SAFETY INSTRUCTIONS? If not, READ THEM NOW. They contain Position the filter and pump as shown very important safety information in Fig. 1. Make sure filter is positioned related to the installation of your filter. in base correctly, once sand is 5 FT. - Page 4 VALVE INSTALLATION - PLEASE READ STEP 1 STEP 3 Press down firmly until the large round o-ring is seated to tank flange. ROUND O-RING POSITION: SQUARE O-RING POSITION: PUSH ALL THE WAY UP IN GROOVE PAST GROOVE Position round o-ring all the way to the flange and position the square o-ring in the groove as shown.
- Page 5 INSTALL HOSES NEW FILTER START UP See Fig. 1 and Exploded Parts Illustration AFTER ADDING THE CORRECT SAND, #20 grade filter (.4/.5 IMPORTANT: Incorrect hose hookup could cause damage to your mm) sand AND CORRECT filter system. Follow the instructions AMOUNT.
-
Page 6: Valve Operation
BACKWASH: Backwashing reverses plugging the underdrain slots. WASTE LINE HOOKUP the flow of water through the filter to Because pool water is lost during The discharge waste water will flush out the dirt and debris, and this operation (150 to 200 contain pool water treatment chemi- waste water is discharged to waste gallons) keep a close check on... -
Page 7: Maintenance
CAUTION indicated on the pressure gauge. 5. Disconnect all hoses. BEFORE removing filter or pump Frequent backwashing will be 6. Place plastic bag over riser tube from pool for servicing, prevent the necessary during this process in tank and secure with a rubber backflow of water from your skimmer depending on the amount of sedi- band. - Page 8 Exploded View AquaView Model 014 & 017 Doughboy Sand Filter with 7 Position Valve TO WASTE TO POOL RETURN TO TOP PUMP PORT TO FRONT PUMP PORT TO SKIMMER...
- Page 9 Parts List AquaView Model 014 & 017 Doughboy Sand Filter with 7 Position Valve ITEM PART # DESCRIPTION 1121-1970 Tank w/Decals - 014 Model 1121-1971 Tank w/Decals - 017 Model 1107-1636 Underdrain Base Assembly 1107-1679 Underdrain Assembly - 014 Model...
- Page 10 Exploded View AquaView Model 020 and Model 024 Doughboy Sand Filter with 7 Position Valve TO POOL TO WASTE RETURN TO TOP PUMP PORT TO SKIMMER TO FRONT PUMP PORT WARRANTY CARD OWNER'S GUIDE ONLY INCLUDED WITH 24" FILTER...
- Page 11 Parts List AquaView Model 020 and Model 024 Doughboy Sand Filter with 7 Position Valve ITEM PART # DESCRIPTION 1121-1972 Tank w/Decals Model - 020 1121-1973 Tank w/Decals Model - 024 340-2224 Underdrain Spacer 1107-1649 Threaded Underdrain Assembly 330-1023 #8 x 5/8" Screw 1121-1543 Tank Internal Adaptor w/Insert &...
- Page 12 Change of Design: Doughboy Recreational expressly reserves the right to change or modify the design and construction of any product in due course of our manufacturing procedures, without incurring any obligation or liability to furnish or install such changes or modifications on products previously or subsequently sold.
