Summary of Contents for Philips GC551
- Page 1 GC551 EN User manual SC 用户手册...
- Page 4 a Steamer head h De-calc knob b Steamer head holder i Water tank c Hang&lock j Board cover d Pole lock clip k Board e Pole l Steam supply hose f Steam knob m Glove g Base n Brush & pleat maker a 蒸汽喷头...
- Page 7 EN The board provides backing support to enhance the steaming performance. Note: Do not wash the board cover as it may damage the foam material. 熨衣板可以提供背面支撑以增强熨烫效果。 注意：不要清洗熨衣板外罩，因为这可能会损坏 海绵材料。...
- Page 8 EN Your appliance has been designed to be used with tap water. In case you live in an area with hard water, fast scale build-up may occur. Therefore, it is recommended to use water without minerals such as distilled or purified water to prolong the lifetime of your appliance.
- Page 10 EN Multi steam settings are provided to save water and energy. You can increase the steam setting for more steam power at any point of time. This appliance is safe to use on all fabrics at any setting. Note: The steam supply hose becomes warm during steaming.
- Page 11 EN For garments which require a formal look and crisp result, such as shirts, jackets and pants, it is recommended to use the board. 对于衬衫、夹克和裤子等要求具有正式造型和挺括 效果的衣物，建议使用熨衣板。...
- Page 12 EN To make crisp pleats, start steaming from the bottom half of the pants and move onto the top half to prevent accidental wrinkles on parts which have already been steamed. 要打造笔挺的裤缝，可先从裤子的下半部开始蒸汽 熨烫，然后再移至上半部进行熨烫，以防止熨烫过 的部分偶尔出现褶皱。 EN For a more natural look and quick touch-up on garments such as dresses, pleated skirts and T-shirts, it is recommanded to use the board.
- Page 13 EN Put the glove on the hand you are using to hold a garment. The glove protects your hand against the steam from the steamer head. 将防烫手套戴在拿着衣物的手上。防烫手套可保护 您的手不被蒸汽喷头所喷出的蒸汽烫伤。...
- Page 14 EN The brush improves steam penetration into thick and heavy fabrics for faster results. Brush slowly with the bristles touching the garment. Caution: Do not attach or detach the brush and pleat maker while the steam is on or the steamer head is hot.
- Page 15 EN To maintain optimal steam performance and prolong the lifetime of the appliance, it is important to remove scale and impurities inside the appliance regularly. Therefore, it is recommended to perform the de-calc process at least once a month. Before you start de-calc process, make sure there is some water in the water tank.
- Page 16 EN Note: Clean the appliance and wipe any deposits off the steamer head with a damp cloth and non-abrasive liquid cleaning agent. Always empty the water tank after usage, to prevent calc build-up and maintain good steam performance. 注意：用湿布和非腐蚀性液体清洁剂清洁本产品， 并擦去蒸汽喷头中的沉积物。 使用后务必将水箱倒空，以防止水垢的形成并保持...
- Page 18 Possible cause Solution Problem The appliance The steamer has Let the appliance heat produces not heated up up for approximately no steam or sufficiently. 45 seconds. irregular steam. Steam has Lift the steamer head condensed in the to straighten the hose hose.
- Page 19 Possible cause Solution Problem An excessive The water in Perform de-calc process. amount of the appliance is Refer to section. water drips out dirty or has been of the steamer left inside the head when the appliance for a appliance is long time.
- Page 20 可能的原因 解决方法 问题 产品无法产 蒸汽挂烫机未充分 让产品加热约 45 秒钟。 生蒸汽或产 加热。 生的蒸汽不 连贯。 有蒸汽凝结在输送 提起蒸汽喷头以垂 管内。 直拉直蒸汽输送 管。这样做可使冷 凝水流回水箱中。 水箱中的水位低或 为水箱加水并正确 水箱未正确插入。 装入。 产品内积聚的水垢 执行除垢流程。 太多。 请参阅 部分。 水滴从蒸汽 蒸汽喷头和/或蒸 提起蒸汽喷头以垂 喷头上滴下 汽输送管水平摆放 直拉直蒸汽输送 或产品发出 了较长时间。 管。这样做可使冷 咕噜声。 凝水流回水箱中。 当蒸汽输送管处于 提起蒸汽喷头以垂 U 形状态时，输送...
- Page 21 可能的原因 解决方法 问题 产品加热时 产品中的水变脏 执行除垢流程。 有过多的水 或留在产品很长 请参阅 部分。 从蒸汽喷头 时间。 中滴出。 蒸汽挂烫机 水箱盖未盖好或除 盖好水箱盖或拧紧 底座漏水。 垢旋钮未拧紧。 除垢旋钮。 水箱没有正确地 请正确插入水箱。 插入。...
- Page 22 产品中有害物质的名称及含量 有害物质 铅及其 汞及其 镉及其 六价铬 多溴 多溴 部件名称 化合物 化合物 化合物 化合物 联苯 二苯醚 PBDE （ ） （ ） （ ） （ ） （ ） 主机 Main Body 电源线 Power cord 蒸汽喷头 Steamer Head 蒸汽输送管 Steam supply hose SJ/T 11364 本表格依据...
- Page 23 产品： 飞利浦蒸汽挂烫机 G C551 型号： 220 V～ 额定电压： 50 Hz 额定频率： 额定输入功率： 1800 W 生产日期： 请见产品本体 产地： 中国浙江慈溪 飞利浦（中国）投资有限公司 上海市天静安区灵石路718号A1幢 全国顾客服务热线: 4008 800 008 本产品根据国标 GB4706.1-2005, GB4706.84-2007 制造 保留备用 2018-03-02 发行日期：...
- Page 24 ©2018 Koninklijke Philips N.V. All rights reserved. 4239 001 10882...
