- Page 1 Electric Bike Model: Cybertrack 200...
- Page 2 Before you ride your Cybertrack 200 for the first time, please be absolutely sure that it has been correctly assembled. You will find step by step instruction in this manual.
-
Page 3: Table Of Contents
Contents ............................1. PRODUCT OVERVIEW ............................2. PACKAGE CONTENTS .......................... 3. HOW TO ASSEMBLE THE EBIKE ......................... 4. HOW TO CHARGE THE BATTERY ..............................5. RIDING MODES ............................6. DISPLAY AND BUTTONS ........................... 7. BEFORE YOU RIDE CHECKLIST ............................... 8. MAINTENANCE ................................ -
Page 4: Product Overview
1. PRODUCT OVERVIEW LCD Display Handlebar Throttle Brake Lever Saddle Hidden Battery Front Fork Motor Quick Release Disc Brake On/Off Switch Pedal Charging Port - 03 -... -
Page 5: Package Contents
2. PACKAGE CONTENTS 1 × Bike Frame + Rear Wheel 1 × F 1 × Saddle 2 × Pedal 5 × Allen Key ront Wheel 1 × Wrench 1 × Screwdriver 1 × Charger 1 × User Manual 4 × Battery Key - 04 -... -
Page 6: How To Assemble The Ebike
After verifying that all components are present and in good condition, you can assemble your new fat tires eBike. Please retain the box and packaging materials in case you need to ship your Cybertrack 200 in the future. Step 1. How to assemble the stem and handlebar 1. - Page 7 2. Loosen the stem bolts, you may raise and lower the handlebar as you wish until you find a height comfortable for riding.This means that you can easily reach the brakes for safe control of the Cybertrack 200. When this is complete, simply pull the handlebar rotation quick release backward to secure the handlebars in place.
- Page 8 If something appears to be wrongly assembled - even if you have followed the instructions, please contact us before riding your Cybertrack 200, or take to your local shop to have it thoroughly checked. IMPORTANT: Attach the wheel securely. A loose or detached wheel can cause you to lose control of your Cybertrack 200 and fall, and could cause you serious injury.
- Page 9 Failure to tightly attach the pedals could result in the pedals becoming loose while riding. A loose or detached pedal can cause you to lose control of your Cybertrack 200 and fall, and could cause you serious injury.
- Page 10 IMPORTANT: Do not raise the seat post above the “minimum insert” line clearly printed on the backside of the seat post. Raising the seat post above the minimum insert line can cause the seat post to fail, which could in turn result in loss of control of your Cybertrack 200 and could cause you serious injury.
-
Page 11: How To Charge The Battery
Simply remove the battery from the frame and plug the charger first into the battery, then directly into the electrical socket. On/Off Switch IMPORTANT: When parking a Cybertrack 200, we recommend you lock your battery by setting it on “OFF” position, then remove the key. - 10 -... - Page 12 Once home, charge it as soon as possible. IMPORTANT: If your Cybertrack 200 will be kept for a long period in extreme temperatures (below 0 /32 or above 35 /95 ), remove the battery and keep it in a place where the temperature is between 4 /40 and 32 /90 .
-
Page 13: Riding Modes
5. RIDING MODES Speed Modes All Electric Pedal Assisted All Electric - Power on the LCD display and switch the speed modes × × from 1~5 by rotating the throttle. Pedal Assisted - Power on the LCD display and switch the speed modes from 1~5 by pedaling. -
Page 14: Display And Buttons
6. DISPLAY AND BUTTONS Motor power Button information Battery level Motor power : Quick-press to switch from speed modes 5 to 1. Speed mode : Press and hold for ~2 seconds to turn the E-Bike on/off. Addition Speed Display Area Speed display Power switch : Quick-press to switch from speed modes 1 to 5. -
Page 15: Before You Ride Checklist
7. BEFORE YOU RIDE CHECKLIST WEAR THE BIKE HELMET CAUTION - 14 -... -
Page 16: Maintenance
Lastly, place pads back into holder and re-insert into caliper. After re-insertion, pull the cable back into its original place and firmly re-tighten the pinch bolt. Pads worn out. Ask your dealer for more information about your bike specific model. If you are not comfortable with doing this work yourself, please take your Cybertrack 200 to your local bike mechanic. - 15 -... -
Page 17: Cleaning
9. CLEANING While our Cybertrack 200 fat tires eBike are rain and splash-proof, their electrical components should not be submerged in water. bottom bracket and bubs. IMPORTANT ! Do not attempt to open the casings of the battery, motor, or controller. This can be dangerous and will void any warranties by doing so. -
Page 18: Storage
10. STORAGE Fully charge the bike before storing to prevent the battery from over-discharge due to long-term storage. If your bike needs to be stored for more than one month, discharge and recharge the battery at least once a month. NOTE: process of plastic parts and may reduce battery life. -
Page 19: Disposal At End-Of-Life
11. DISPOSAL AT END-OF-LIFE product may result in the battery heating up, rupturing, or igniting which may cause serious injury. end-of-life is to dispose of the entire unit at or through an e-waste recycling center, program, or facility. state, and local governments. You must check laws and regulations corresponding to where you live in order to properly dispose of the battery and/or unit. household waste disposal service. -
Page 20: Specifications
12. SPECIFICATIONS Brand name AVANTREK Model No. CYBERTRACK 200 Net weight 56.9 lbs/25.8 kg Bike dimensions 67.3x27.6x(45.7-48.8) in / 171x70x(116-124)cm Bike dimensions when folded 37.8x20.5x27.2 in / 96x52x69cm Max. incline 15° (rider weighs 220.4 lb. / 100kg) Max. capacity 264.6 lbs / 120 kg Max. -
Page 21: Warranty
These items are warrantied to be free from manufacturer defects in materials and/or workmanship for a period of one year from the date you receive your Cybertrack 200 bike. This warranty does not cover normal wear and tear. support@iavantrek.com or bring your bike to your nearest electric bike shop for assistance. - Page 22 www.iavantrek.com support@iavantrek.com...
