  • Page 1 Technical Reference Manual Hardware and BIOS HP Vectra VE series 3 PC...
  • Page 2 Notice The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Conventions

    Preface This manual is a technical reference and BIOS document for engineers and technicians providing system level support. It is assumed that the reader possesses a detailed understanding of AT-compatible microprocessor functions and digital addressing techniques. Technical information that is readily available from other sources, such as manufacturer’s proprietary publications, has not been reproduced.

  • Page 4: Bibliography

    Bibliography HP Vectra VE 5/xxx series 3 User’s Guide manual (D4050-90001). HP Vectra VE 5/xxx series 3 Familiarization Guide (D4050-90901). HP Vectra Accessories Service Handbook - 6th edition (5964-8495). HP Vectra PC Service Handbook (Volume 1) - 10th edition (5964-8494).

  • Page 5: Table Of Contents

    Contents Preface ..........Conventions .
  • Page 6 4 Summary of the HP/Phoenix BIOS HP/Phoenix BIOS Summary ....... . . 36 Setup Program .
  • Page 7 Product Identification ........HP I/O Port Map (I/O Addresses Used by the System)....
  • Page 8 Contents viii...

  • Page 9: System Overview

    System Overview This chapter introduces the external features, and lists the specifications and characteristic data of the computer. It also summarizes the documentation which is available.

  • Page 10: Package

    1 System Overview Package Package Front logo no longer carries processor speed and series information Mouse Keyboard Parallel Port Serial Port A Serial Port B Product information now appears on serial number label Display Empty shelf for a CD-ROM or 5.25-inch device Empty shelf for a 2nd hard disk...

  • Page 11: Plan View Of The Chassis Base

    1 System Overview Package Plan view of the Chassis Base The above illustrations shows a plan view of the PC, seen from above. All dimensions are in millimeters. The mounting holes for the second hard disk (95.20 44.45 mm), and those for mounting the computer to a solid surface (275.00 210.00 mm), are indicated.

  • Page 12: Specifications And Characteristic Data

    1 System Overview Specifications and Characteristic Data Specifications and Characteristic Data Physical Characteristics Weight 20 lbs Dimensions 15.3 inches (D) by 16.5 inches (W) by 4.9 inches (H) 39 cm (D) by 42 cm (W) by 12.5 cm (H) Footprint 1.8 sq ft Flat 18.3 inches (W) by 7 inches (D) by 1.3 inches (H)

  • Page 13: Electrical Specification

    Electrical Specification Limit for the Power Parameter Supply Input voltage 100-127, 200-240 Vac Input current (max) Input power (max) 150 W Input power (typical) < 44 W < 29 W < 24 W < 5 W Input frequency 47 Hz to 63 Hz Available power 100 W (continuous) Max current at +12 V...

  • Page 14: Documentation

    Documentation The table below summarizes the availability of documentation that is appropriate to the HP Vectra VE 5/xxx series 3. Only selected publications are available on paper. Most are available as printable files from the HP division support servers, and as viewable files (which can also be printed) on the HP Support Assistant CD-ROM.

  • Page 15: Where To Find The Information

    Where to Find the Information The following table summarizes the availability of information within the HP Vectra VE 5/xxx series 3 documentation set. User Guide Product features Key features Product model numbers Connecting cables and Keyboard, mouse, turning on display, printer, power Finding on-line Finding READ.MEs and...
  • Page 16 1 System Overview Documentation...

  • Page 17: System Board

    System Board The next chapter describes the graphics and disk devices which are sup- plied with the computer. This chapter describes the components of the system board, taking in turn the components of the Processor-Local Bus, the Peripheral Component Interconnect (PCI) bus and the Industry Standard Architecture (ISA) bus.

  • Page 18: System Board And Backplane

    2 System Board System Board and Backplane System Board and Backplane Display SW1 (security features) SiS 6205 Graphics Controller 27.5 cm (1 1.0 inches) SiS 5512 Data Buffer Cache Memory socket Pentium Processor Serial B Serial A VESA feature connector PCI/ISA bridge PL/PCI bridge Memory Cntlr...

  • Page 19: Backplane

    Backplane PCI slots (normal) PCI slots (network) PCI/ISA combination slots ISA slots (full length) ISA slots (restricted length) Backplane Architectural View The block diagram, on the following page, gives an architectural view of the computer’s structure. 2 System Board System Board and Backplane Total Occupied (J2)
  • Page 20 2 System Board System Board and Backplane Processor-Local Bus (64 bit, 60/66 MHz) SiS5512 Data Path Unit Pentium Processor Main Memory Controller Level-Two Cache PCI Bus (32 bit, 33 MHz, asynchronous) Graphics Controller SiS551 1 PL/PCI Bridge Main Master Memory Controller Slave Cache...

  • Page 21: Devices On The Processor-Local Bus

    VRE voltage regulator module (VRM), in which the voltage is derived from the 3.3 V, 5 V and 0 V outlets of the power supply. Since there is no VRM in the HP Vectra VE 5/xxx series 3, these types of processor cannot be installed.
  • Page 22 2 System Board Devices on the Processor-Local Bus Processor Jumper J7 PCI Bus Local Bus Frequency Frequency short pins 2-4 50 MHz 33 MHz short pins 1-3 60 MHz 33 MHz short pins 3-4 66 MHz 33 MHz short pins 2-4 50 MHz 33 MHz short pins 1-3...

  • Page 23: Chip-Set

    Chip-Set The chip-set comprises three chips, each encapsulated in a 208 pin plastic quad flat pack (PQFP) package. The PCMC chip (SiS 5511) is a combined PL/PCI bridge and cache controller and main memory controller and PCI arbiter. The PLDB chip (SiS 5512) provides the PCI local data buffer and PCI-to- Processor-Local bus data path.

  • Page 24: Cache Memory

    The L2 cache memory, when fitted, also has a 32-byte line width. It is controlled by the PL/PCI bridge chip in the system board chip-set. A single HP cache memory module consists of 256 KB of direct mapped, synchronous pipelined burst, static random access memory (SRAM). The synchronous cache memory module produces 10% better performance than the asynchronous module.

  • Page 25: Main Memory

    Main Memory There are six main memory module sockets, arranged in three banks (A to C), allowing installation up to 192 MB. One bank is already occupied by the pair of memory modules that contain the 8 or 16 MB of memory that is fitted as standard (depending on the model of the computer).

  • Page 26: Devices On The Pci Bus

    2 System Board Devices on the PCI Bus Devices on the PCI Bus PL/PCI bridge (SiS5511) PCI/ISA bridge (SiS5513) IDE controller (SiS5513) Graphics controller (SiS6205) PCI slot #1 PCI slot #2 Graphics Controller The SiS 6205 graphics controller, its shared frame buffer (SFB), and the unified memory architecture (UMA) are described in the next chapter.
  • Page 27 The three DMA modes allow the following transfer rates: Mode Cycle time (ns) Transfer rate (MBytes/s) Operated in slave mode, the IDE controller saturates the PCI bus with transfers, thus limiting the actual achieved transfer rate to 10 MBytes per second.

  • Page 28: Devices On The Isa Bus

    It can operate the four modes: Standard mode (PC/XT, PC/AT, and PS/2 compatible). Bidirectional mode (PC/XT, PC/AT, and PS/2 compatible). Enhanced mode (enhanced parallel port, EPP, compatible). High speed mode (MS/HP extended capabilities port, ECP, compatible). ISA Device Index Data...
  • Page 29 General Purpose I/O The NS87308 and NS87307 provide a number of general purpose I/O pins. Some of these are used on the HP Vectra VE 5/xxx series 3 to sense the current settings of system board switches and jumpers. Host bus frequency selection (S2), as indicated by jumper J7...
  • Page 30 2 System Board Devices on the ISA Bus Description Backplane identification (desktop=1, minitower=0) Serial EEPROM Data In Serial EEPROM clock Serial EEPROM Data Out Serial EEPROM clear (as per SW1) Ring signal (used for remote power-on, RPO) XD bus bit 2...

  • Page 31: System Rom

    Updating the System ROM The System ROM can be updated with the latest BIOS. This can be ordered from HP or downloaded from one of HP’s online services. (For more information on HP’s electronic services, refer to the Hewlett-Packard Support and Information Services chapter in the User’s Guide that was supplied with the computer.)
  • Page 32 1-2 = asynchronous Serial EEPROM flag jumper on = normal no jumper = clear (reserved for use by HP) By setting switch SW1-2 in the configuration data cleared (in the CMOS memory and the Serial EEPROM), but also all the Plug-and-Play data that had been saved in the Serial EEPROM.

  • Page 33: Little Ben

    General Purpose I/O Enable remote ON This signal is used to control a status panel light on HP Vectra 500 Jumper J15. (GPIO2=0 if the jumper is removed, to clear the product ID field) Screen blanking enabled (GPIO3=0) Not used.

  • Page 34: Other Pci And Isa Accessory Devices Under Plug And Play

    2 System Board Devices on the ISA Bus Other PCI and ISA Accessory Devices under Plug and Play All PCI accessory boards are Plug and Play, although not all ISA boards are. Check the accessory board’s documentation if you are unsure. The computer is PCI 2.1 compliant, and PnP 1.1 compliant.

  • Page 35: Interface Boards And Mass-Storage Drives

    Interface Boards and Mass-Storage Drives This chapter describes the video and mass storage devices which are supplied with the computer. It also summarizes the pin connections on internal and external connectors.

  • Page 36: Sis 6205 Graphics Controller Chip

    3 Interface Boards and Mass-Storage Drives SiS 6205 Graphics Controller Chip SiS 6205 Graphics Controller Chip There is no dedicated video memory. Instead, the computer is built around a unified memory architecture (UMA). The shared frame buffer (SFB) is located in a reserved portion of the main memory, with the remainder of the main memory available for conventional system memory.

  • Page 37: Connectors

    It is a purely subjective effect. However, in general, the use of this display with the HP Vectra VE 5/xxx series 3 is not recommended. If the user is determined to use this combination, though, then decreasing the refresh rate or the video resolution, or both, may diminish the effect.

  • Page 38: Available Video Resolutions

    DDC displays, or when Video Plug and Play is disabled, the refresh rates can be changed manually in the Setup program. DDC can be enabled by software (such as the HP UserTool in Windows for Workgroups 3.11 or Windows 95) even if Video Plug and Play is disabled in the Setup program.
  • Page 39 Resolution Windows for Workgroups 640 x 480 3.11 800 x 600 1024 x 768 1280 x 1023 640 x 480 800 x 600 1024 x 768 1280 x 1023 Windows 95 640 x 480 800 x 600 1024 x 768 640 x 480 800 x 600 1024 x 768...

  • Page 40: Mass-Storage Drives

    (5063-9036) for Windows for Workgroups 3.11. At the time of release, these bear the version number M1202. Hard Disk Drives A 3.5-inch hard disk drive is supplied on an internal shelf in some models. HP product number D2787A Manufacturer Western Digital...

  • Page 41: Connectors And Sockets

    Connectors and Sockets Hard Disk Drive Data Connector Signal Signal Reset# Ground HD10 HD11 HD12 HD13 HD14 HD15 Ground orientation key DMARQ Ground DIOW# Ground DIOR# Ground IORDY SPSYNC:CSEL DMACK# Ground INTRQ IOCS16# PDIAG# CS0# CS1# DASP# Ground Status Panel Connector Signal Signal Error_LED#...

  • Page 42: Vga Connector

    Connectors and Sockets Signal Ground Ground Ground EVideo ESync EDclk not connected Ground Ground Ground Ground not connected Socket Pin Layouts Keyboard and Mouse Connector Serial Port Connector VESA Connector Signal DClk BlankP# HSyncB VSyncB Ground Battery Pack Connector Signal Ground not connected orientation key...

  • Page 43: Summary Of The Hp/Phoenix Bios

    Summary of the HP/Phoenix BIOS This chapter and the following chapter give an overview of the features of the HP/Phoenix BIOS.

  • Page 44: Hp/Phoenix Bios Summary

    The Tattoo string can be set the very first time that the computer is started in Windows. It can be updated with the DMI the Windows control panel, or with the Windows 95 control panel, or the Windows for Workgroups 3.11 HP UserTool. to view the summary configuration once, it can be is pressed.
  • Page 45 IS A P n P : No t In stal led <F1> to continue, <F2> to run Setup, <F10> to power off, <F5> to retain 4 Summary of the HP/Phoenix BIOS HP/Phoenix BIOS Summary PC Se ria l N u mb e r...

  • Page 46: Setup Program

    4 Summary of the HP/Phoenix BIOS Setup Program Setup Program To run the Setup program, interrupt the POST by pressing when the message appears on the initial “Vectra” logo screen. F2=Setup Five menus are offered along the top of the screen: Main, Configuration, Security, Power, and Exit.
  • Page 47 ; the translation method can be set to , or both 4 Summary of the HP/Phoenix BIOS Setup Program I t e m - S p e c i f i c H e l p En ab le s o r d is ab les t he on - b oa r d p a r a l l e l p or t a t the s p ecif ic ad dre ss .

  • Page 48: Security Menu

    4 Summary of the HP/Phoenix BIOS Setup Program Security Menu Sub-menus are presented for changing the characteristics and values of the User Password, the System Administrator Password, the amount of protection against use of the system’s drives (using the Hardware Protection sub-menu), and the amount of protection against being able to boot from the system’s drives (using the Start-Up Center sub-menu).

  • Page 49: Vectra Ergonomic Power Solution (Veps)

    “Power” menu of the Setup program. HP Off HP Off protects the user from some types of unintentional data loss, providing a safe shutdown of running applications and unsaved files. It is available under the Windows 95 operating system provided that the appropriate driver is installed.

  • Page 50: Advanced Power Management (Apm)

    4 Summary of the HP/Phoenix BIOS Vectra Ergonomic Power Solution (VEPS) Advanced Power Management (APM) The BIOS is APM 1.1 compliant, providing it with facilities for advanced power management (APM). APM is incorporated in Windows for Workgroups 3.11, Windows 95 and OS/2. A file called is needed power.exe...

  • Page 51: Bios Addresses

    BIOS Addresses This section provides a summary of the main features of the HP system BIOS. This is software that provides an interface between the computer hardware and the operating system. System Memory Map Reserved memory used by accessory boards must be located in the area from C8000h to EFFFFh.
  • Page 52 Primary flexible disk drive controller 03F8h - 03FFh Serial port 1 0496h - 0497h HP reserved (Little Ben) 0678h - 067Bh Parallel port if ECP mode is selected 2 0778h - 077Bh Parallel port if ECP mode is selected 1...
  • Page 53 The following table shows how the master and slave controllers are connected. The Interrupt Requests (IRQ) are numbered sequentially, starting with the master controller, and followed by the slave. 4 Summary of the HP/Phoenix BIOS Function Function BIOS Addresses...
  • Page 54 BIOS Addresses IRQ (Interrupt Vector) IRQ0(08h) IRQ1(09h) IRQ2(0Ah) Slave IRQ IRQ8(70h) IRQ9(71h) IRQ10(72h) IRQ11(73h) IRQ12(74h) IRQ13(75h) IRQ14(76h) IRQ15(77h) IRQ3(0Bh) IRQ4(0Ch) IRQ5(0Dh) IRQ6(0Eh) IRQ7(0Fh) Using the Setup program: • IRQ3 can be made available by disabling serial ports 2 and 4. •...

  • Page 55: Power-On Self-Test And Error Messages

    Power-On Self-Test and Error Messages This chapter describes the Power-On Self-Test (POST) routines, which are contained in the computer’s ROM BIOS, the error messages which can result, and the suggestions for corrective action.

  • Page 56: Order In Which Tests Are Performed

    To see the tests performed during the POST, press when the initial HP “Vectra” logo appears, and the display will switch to text mode. In this mode, a summary configuration screen will be displayed at the end of the POST. Pressing the PAUSE/BREAK key at any time will allow you to inspect the screen contents.
  • Page 57 Test System BIOS Tests Tests the LEDs on the control panel. LED Test Calculates an 8-bit checksum. Test failure causes the boot process to System (BIOS) ROM Test abort. Tests the RAM refresh timer circuitry. Test failure causes the boot process RAM Refresh Timer Test to abort.
  • Page 58 Order in Which Tests are Performed Read/write test on real-mode RAM. (This test is not done during a reset Real-Mode Memory Test using (First 640KB) system RAM to determine how much is present. Test failure of a 64 KB block of memory causes an error code to display, and the test is aborted. Tests shadow RAM in 64 KB segments (except for segments beginning at Shadow RAM Test A000h, B000h, and F000h).

  • Page 59: Beep Codes

    Beep Codes If a terminal error occurs during POST, the system issues a beep code before attempting to display the error. Beep codes are useful for identifying the error when the system is unable to display the error message. Beep Numeric Beep Pattern Code...

  • Page 60: Error Message Summary

    Error Message Summary Error Message Summary The POST section of the HP BIOS no longer displays numeric error codes (such as 910B) but gives a self-explanatory, descriptive diagnosis, and a list of suggestions for corrective action. The following table summarizes the most significant of the problems that can be reported.
