Panasonic TX-P46GW30 Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Plasma TV
  5. TX-P46GW30
  6. Service manual

Panasonic TX-P46GW30 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TX-P46GW30
Model No.
TX-P46GW30J
GPF14D-E Chassis
© Panasonic Corporation 2011.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.PCZ1104067CE
Plasma Television

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TX-P46GW30

Summary of Contents for Panasonic TX-P46GW30

  • Page 1 ORDER NO.PCZ1104067CE Plasma Television TX-P46GW30 Model No. TX-P46GW30J GPF14D-E Chassis © Panasonic Corporation 2011. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 11.2. Block (1/4) Diagram ------------------------------------- 38 1.1. General Guidelines ----------------------------------------3 11.3. Block (2/4) Diagram ------------------------------------- 39 1.2. Touch-Current Check--------------------------------------3 11.4. Block (3/4) Diagram ------------------------------------- 40 11.5. Block (4/4) Diagram ------------------------------------- 41 2 Warning --------------------------------------------------------------4 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.

  • Page 4: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.

  • Page 5: About Lead Free Solder (Pbf)

    2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

  • Page 6: Service Navigation

    3 Service Navigation 3.1. PCB Layout Board Name Function Board Name Function Power Supply Data Driver (Lower Right) Non serviceable. Data Driver (Lower Left) P-Board should be exchange for service. Scan Drive Main AV input, processing Sustain Drive Remote receiver, Power LED, C.A.T.S sensor Scan out (Upper) Non serviceable.

  • Page 7: Applicable Signals

    3.2. Applicable signals COMPONENT (Y, P ), HDMI * Mark: Applicable input signal Signal name COMPONENT HDMI 525 (480) / 60i, 60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i 1,125 (1,080) / 60p, 50p, 24p PC (from HDMI terminal) Applicable input signal for PC is basically compatible to HDMI standard timing.

  • Page 8: Specifications

    - 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 Demodulation - QPSK, 8PSK DiSEqC - Version 1.0 • Check the latest information on the available services at the following website. (English only) http://panasonic.jp/support/global/cs/tv/ Female F-type 75 Ω Satellite dish input Aerial input VHF / UHF Operating Conditions 0 °C- 35 °C...
  • Page 9 Dimensions (W × H × D) 1,118 mm × 730 mm × 335 mm (With Pedestal) 1,118 mm × 695 mm × 70 mm (TV only) Mass 27.5 kg Net (With Pedestal) 23.5 kg Net (TV only) Note • Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate. •...

  • Page 10: Technical Descriptions

    Model No. Keys One-to-One CI Plus DTCP-IP WIDEVINE (For USB Rec.) TX-P46GW30 TX-P46GW30J 5.2. USB HDD Recording 5.2.1. General information: Digital TV programmes can be recorded in USB HDD. A One-to-One key generated in A-board by SELF CHECK binds TV and USB-HDD for communication.

  • Page 11: Service Mode

    6 Service Mode 6.1. How to enter into Service Mode 6.1.1. Purpose After exchange parts, check and adjust the contents of adjustment mode. While pressing [VOLUME ( - )] button of the main unit, press [0] button of the remote control three times within 2 seconds. 6.1.2.
  • Page 12 6.1.4. Contents of adjustment mode • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. Main item Sub item Sample Data Remark ADJUST...

  • Page 13: Option - Mirror

    6.2. Option - Mirror Picture can be reversed left and right or up and down. 00 : Default (Normal picture is displayed) 01 : Picture is reversed left and right. 02 : Picture is reversed up and down. Hint : If the defective symptom (e.g. Vertical bar or Horizontal bar) is moved by selection of this mirror, the possible cause is in A-board.

  • Page 14: Hotel Mode

    6.4. Hotel mode 1. Purpose Restrict a function for hotels. Item Function 2. Access command to the Hotel mode setup menu Hotel Mode Select hotel mode On/Off In order to display the Hotel mode setup menu: Initial INPUT Select input signal modes. While pressing [VOLUME (-)] button of the main unit, Set the input, when each time power is switched press [AV] button of the remote control three times within...

  • Page 15: Data Copy By Sd Card

    6.5. Data Copy by SD Card 6.5.1. Purpose (a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board. (b) Hotel (Copy the data when installing a number of units in hotel or any facility): When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.
  • Page 16 6.5.3. Data copy from TV set to SD Card 1. Turn on the TV set. 2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2770 (b) For Hotel : 4850 Data will be copied from TV set to SD card.
  • Page 17 6.5.4. Data copy from SD Card to TV set 1. Turn on the TV set. 2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2771 (b) For Hotel : 4851 Data will be copied from SD card to TV set.

  • Page 18: Troubleshooting Guide

    7 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 7.1. Check of the IIC bus lines 7.1.1. How to access 7.1.1.1. Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.

  • Page 19: Power Led Blinking Timing Chart

    7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit. Blinking Times Contents Check point...

  • Page 20: No Picture

    7.4. No Picture...

  • Page 21: Local Screen Failure

    7.5. Local screen failure Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area. Fig-1...

  • Page 22: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. SC jig Purpose: To find the failure board (SC or SU/SD) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.

  • Page 23: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions 9.1. Remove the Rear cover 9.4. Remove Side terminal cover 1. See PCB Layout (Section 3) 9.2. Remove the AC inlet 1. Remove the screws (×2 2. Remove the Side terminal cover. Caution: To remove P.C.B. wait 1 minute after power was off for dis- charge from electrolysis capacitors.

  • Page 24: Remove The A-Board

    9.6. Remove the A-Board 3. Remove the screws (×2 4. Disconnect the connector. 1. Remove the Tuner unit. (See section 9.5.) 5. Remove the Side unit assy from the Side unit metal. 2. Remove the screws (×2 ) and remove the A-Board. 9.8.

  • Page 25: Remove The Sd-Board

    9.10. Remove the SD-Board 9.12. Remove the SS-Board 1. Disconnect the flexible cables (SD1, SD2, SD3 and SD4) 1. Remove the Tuner unit. (See section 9.5.) connected to the SD-Board. 2. Disconnect the connector (SS11). 2. Disconnect the flexible cable (SU11-SD11) and the bridge 3.

  • Page 26: Remove The Stand Bracket

    9.14. Remove the Stand bracket 9.17. Remove the Chassis support metals and the M8 nut metals 1. Remove the Plasma panel section from the servicing stand and lay on a flat surface such as a table (covered 1. Remove the Stand bracket. (See section 9.14.) by a soft cloth) with the Plasma panel surface facing 2.

  • Page 27: Remove The Plasma Panel Section From The Cabinet Assy

    9.19. Remove the Plasma panel sec- 9.20. Remove the Contact metals tion from the Cabinet assy 1. Remove the Cabinet assy. (See section 9.19.) 2. Remove the Tape from the Contact metals. 1. Place the Cabinet assy on a flat surface of a table (cov- 3.

  • Page 28: Replace The Plasma Panel

    9.22. Replace the Plasma panel Caution: Place the Plasma panel on a flat surface of a table (cov- ered by a soft cloth) and a cushion. A new plasma panel itself without Contact metals is fragile. To avoid the damage to new plasma panel, carry a new plasma panel taking hold of the Contact metals.

  • Page 29: Measurements And Adjustments

    10 Measurements and Adjustments 10.1. Adjustment 10.1.1. Vsus selection Caution: When Plasma panel or A-board is replaced, Vsus should be set to LOW. Procedure 1. Go into main item [VSUS] in Service Mode. LOW will be displayed. 2. Press [OK] button to go to TEST stage. White pattern without On-Screen Display will be displayed during TEST and CONF stage.
  • Page 30 10.1.2. Sub-Contrast adjustment Name of measuring instrument Connection Remarks RF generator Base Band signal generator HD signal generator Steps Remarks Connect IIC cable (bus controller-cable) after banner OSD appear. Note: And after SRQ-L, begin an adjustment 2 seconds later. Sub-contrast adjustment is unadjusted for AV/ HD input.
  • Page 31 Steps Remarks Another procedure Connect IIC cable (bus controller-cable) after banner OSD appear. And after SRQ-L, begin an adjustment 2 seconds later. Adjustment of HD system 1. At 1080i 100% Full White or Split colour bar receive component signal, as shown below. 2.
  • Page 32 10.1.3. THX white balance adjustment The adjusting method is different according to the PEAKS EEPROM version. [copy adjustment] : Peaks EEPROM ver.1.00- [Differential (Normal) + copy + WARM adjustment] : Peaks EEPROM ver.1.**- Name of measuring instrument Connection Remarks W/ B pattern Panel surface Color analyzer (Minolta CA-100 or equivalent)
  • Page 33 Steps Remarks 1. Enter the Service mode. METHOD=01 Please receive the Analog-RF. copy adjustments Or, please select CVBS/YUV/HDMI. (No inputting is possible.). (Forbid Analog-RF with no signal.) 2. A number key [1] or [2] are operated and [WB-ADJ] is displayed. Check that the color temp is [COOL].
  • Page 34 Steps Remarks [Differential (Normal) + copy + WARM adjustment] Adjustment of [COOL], [WARM] by data shift from [NORMAL] adjust. And only [WARM] is readjusted. Execute adjustment for color temp. [NORMAL], and set data for color temp. [COOL], [WARM] by data shift WB of HD (or PAL) copies the adjustment data from an adjusted format side.

  • Page 37: Block Diagram

    11 Block Diagram 11.1. Main Block Diagram MAIN AV INPUT,PROCESSING HDMI1-4 CI SLOT ETHERNET DATA (HDMI2) TMDS DATA HDMI I/F LAN CON I/F ETHERPHY ETHERNET Parallel_ TS(SAT) RECEIVER SD CARD I/F TUNER USB I/F SD CARD DATA SD CARD SIF I/F DDR3 DDR3 I/F TUNER I/F...

  • Page 38: Block (1/4) Diagram

    11.2. Block (1/4) Diagram SPEAKER_L SPEAKER_R JK4703 JK8601 JK8602 CN8600 JK4702 JK4701 JK4700 JK8600 TU4801 TU6775 HDMI IN 4 USB1,2 USB3 SD CARD MAIN AV INPUT,PROCESSING ANT IN ANT IN (SIDE) HDMI IN 3 HDMI IN 2 HDMI IN 1 ETHERNET TUNER SAT TUNER...

  • Page 39: Block (2/4) Diagram

    11.3. Block (2/4) Diagram MAIN AV INPUT,PROCESSING IC9300 PLASMA AI LVDS DATA VIDEO DATA VIDEO DATA H/V Sync Control IC9304 Sub Filed Processor IIC0 P+3.3V P+3.3V SI/SO FLASH I/F FLASH P+3.3V P_S0 KEY1 P_S0 KEYSCAN KEY3 P_S1 IC8707 KEY_POWER P+3.3V P_S1 F15V SOS8_SS...

  • Page 40: Block (3/4) Diagram

    11.4. Block (3/4) Diagram POWER SUPPLY COLD COLD L601 D607 Q202,Q203 RC231 F201 T201 L602 D608 RC233 Vsus RESONANCE Vsus Q602-Q605 250V 4A CONTROL L251 RC251 SS11 Vsus Q252 Z201 P+15V RC232 CONTROL Z601 RESONANCE Vsus CONTROL Z251 VR251 VR261 Z231 PC201 Q231,Q232...

  • Page 41: Block (4/4) Diagram

    11.5. Block (4/4) Diagram SUSTAIN DRIVE SCAN DRIVE TPVSUS TPVSUS Vsus SCAN OUT (UPPER) Vsus P+15V D16618 IC14601-03 MAIN H Q16607 Q16001 IC16131 Q16002 CERS VF5V PDP SCAN IC16684 Q16003 DRIVER VSCN-F BUFFER CPH1 CPH1 BUFFER Q16600 TPSS1 PDP SCAN IC16784,85 Q16041 IC16151...

  • Page 43: Wiring Connection Diagram

    12 Wiring Connection Diagram 12.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 12.2. Wiring (1)

  • Page 44: Wiring (2)

    12.3. Wiring (2)

  • Page 45: Wiring (3)

    12.4. Wiring (3)
  • Page 46 Model No. : TX-P46GW30/J Schematic Diagram Note...
  • Page 47 Model No. : TX-P46GW30/J Replacement Parts List Note...
  • Page 48 Model No. : TX-P46GW30/J A-Board (1/16)
  • Page 49 Model No. : TX-P46GW30/J A-Board (2/16)
  • Page 50 Model No. : TX-P46GW30/J A-Board (3/16)
  • Page 51 Model No. : TX-P46GW30/J A-Board (4/16)
  • Page 52 Model No. : TX-P46GW30/J A-Board (5/16)
  • Page 53 Model No. : TX-P46GW30/J A-Board (6/16)
  • Page 54 Model No. : TX-P46GW30/J A-Board (7/16)
  • Page 55 Model No. : TX-P46GW30/J A-Board (8/16) S-10...
  • Page 56 Model No. : TX-P46GW30/J A-Board (9/16) S-11...
  • Page 57 Model No. : TX-P46GW30/J A-Board (10/16) S-12...
  • Page 58 Model No. : TX-P46GW30/J A-Board (11/16) S-13...
  • Page 59 Model No. : TX-P46GW30/J A-Board (12/16) and K-Board S-14...
  • Page 60 Model No. : TX-P46GW30/J A-Board (13/16) S-15...
  • Page 61 Model No. : TX-P46GW30/J A-Board (14/16) S-16...
  • Page 62 Model No. : TX-P46GW30/J A-Board (15/16) S-17...
  • Page 63 Model No. : TX-P46GW30/J A-Board (16/16) S-18...
  • Page 64 Model No. : TX-P46GW30/J C1-Board (1/2) S-19...
  • Page 65 Model No. : TX-P46GW30/J C1-Board (2/2) S-20...
  • Page 66 Model No. : TX-P46GW30/J C2-Board (1/2) S-21...
  • Page 67 Model No. : TX-P46GW30/J C2-Board (2/2) S-22...
  • Page 68 Model No. : TX-P46GW30/J SC-Board (1/4) S-23...
  • Page 69 Model No. : TX-P46GW30/J SC-Board (2/4) S-24...
  • Page 70 Model No. : TX-P46GW30/J SC-Board (3/4) S-25...
  • Page 71 Model No. : TX-P46GW30/J SC-Board (4/4) S-26...
  • Page 72 Model No. : TX-P46GW30/J SS-Board (1/2) S-27...
  • Page 73 Model No. : TX-P46GW30/J SS-Board (2/2) S-28...
  • Page 74 Model No. : TX-P46GW30/J A-Board (Foil side) S-29...
  • Page 75 Model No. : TX-P46GW30/J A-Board (Component side) S-30...
  • Page 76 Model No. : TX-P46GW30/J K-Board S-31...
  • Page 77 Model No. : TX-P46GW30/J C1-Board S-32...
  • Page 78 Model No. : TX-P46GW30/J C2-Board S-33...
  • Page 79 Model No. : TX-P46GW30/J SN-Board (Foil side) S-34...
  • Page 80 Model No. : TX-P46GW30/J SN-Board (Component side) S-35...
  • Page 81 Model No. : TX-P46GW30/J SS-Board S-36...
  • Page 82 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks A-P46GW30 CIRCUIT BOARD A 1 (RTL)PAVCCZ P46GW30 A-P46GW30J CIRCUIT BOARD A 1 (RTL)PAVCCZ P46GW30J TXN/P1QRUE CIRCUIT BOARD P 1 (RTL)PAVCCZ TXN/K1RLUE CIRCUIT BOARD K...
  • Page 83 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C3140 F1G1H5610004 C 560 pF 50 V 1 PAVCCZ C3145 F1J1A106A087 C 10UF, 10V C3146 F1J1A106A087 C 10UF, 10V C3147 F1J1A106A087 C 10UF, 10V...
  • Page 84 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C4912 F1J1E105A231 C 1 UF 25V C4913 F1H1H104A970 C 0.1UF, , 50V C4914 F1J1E105A231 C 1 UF 25V C4915 F1H1H104A970 C 0.1UF, , 50V...
  • Page 85 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C6788 F1J1A106A087 C 10UF, 10V C6789 F1G1C1030008 C 0.01UF 16V C6790 F1K1E106A136 C 10UF, 25V C6791 F1G1C1030008 C 0.01UF 16V C6792 F1G1E392A123 C 3900pF 25V...
  • Page 86 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8056 F1G1C104A077 C 0.1UF 16V C8057 F1G1C104A077 C 0.1UF 16V C8100 F1G1E682A123 C 6800 pF 25 V C8102 F1J1A475A087 C 4.7UF, 10V C8104 F1H1C105A145...
  • Page 87 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8615 F1J1A106A087 C 10UF, 10V C8616 F1J1A106A087 C 10UF, 10V C8617 F1G1C104A077 C 0.1UF 16V C8619 F1G1C104A077 C 0.1UF 16V C8620 F1G1C104A077 C 0.1UF 16V...
  • Page 88 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8789 F1K1E106A136 C 10UF, 25V C8790 F1K1E106A136 C 10UF, 25V C8791 F1G1C223A081 C 0.022UF, 16V C8792 F1G1C1030008 C 0.01UF 16V C8793 F1G1C1030008 C 0.01UF 16V...
  • Page 89 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks D2820 B3AGB0000065 1 PAVCCZ D3015 K7AAAY000011 PHOTO LINK 1 PAVCCZ D3130 B0ACCJ000048 DIODE D4703 DZ2J056M0L ZENER DIODE D4704 B0JCCD000020 DIODE 1 PAVCCZ D4720 DZ2J056M0L...
  • Page 90 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks IC8404 C0DBZYY00382 1 PAVCCZ IC8601 C1CB00003491 IC8602 C0DBZYY00368 IC8603 C0DBZYY00450 1 PAVCCZ IC8606 C0DBZYY00368 IC8700 C0DBAYY00737 IC8701 C0DBAYY00931 1 PAVCCZ IC8702 C0DBAFG00029 1 PAVCCZ...
  • Page 91 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks L4902 G1C150MA0426 INDUCTION COIL 1 PAVCCZ L4903 G1C150MA0426 INDUCTION COIL 1 PAVCCZ L5200 G1C100MA0496 INDUCTION COIL 1 PAVCCZ L5441 G1C4R7MA0445 INDUCTION COIL 1 PAVCCZ...
  • Page 92 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks Q8100 B1CFRD000077 1 PAVCCZ Q8101 B1CFRD000077 1 PAVCCZ Q8102 B1MBEDA00027 Q8701 B1MBEDA00027 Q8709 DSA200100L TRANSISTOR Q8710 DSA200100L TRANSISTOR Q8711 DSC2001S0L TRANSISTOR R001 D0GBR00J0004 M 0 OHM J 1/10W...
  • Page 93 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R3153 D0GA221JA023 M220 OHM, J.1/16 W R3157 EXB28V221J M220 OHM 1/32 W R3163 D0GA104JA023 M100KOHM, J.1/16 W R3164 D0GA104JA023 M100KOHM, J.1/16 W R3167 D0GA333JA023...
  • Page 94 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R4772 D0GA152JA023 M 1.5KOHM, J,0.063W R4774 D0GA473JA015 M 47KOHM, J,1/16W R4775 D0GA473JA015 M 47KOHM, J,1/16W R4780 D0GA121JA023 M 120 OHM, J,1/16W R4781 D0GA680JA023 M 68 OHM, J,1/16W...
  • Page 95 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R5083 D0GA223JA023 M 22K OHM J 1/16W R5084 D1BA1002A014 M 10KOHM,J. 1/16 W R5085 D0GA223JA023 M 22K OHM J 1/16W R5086 D0GA102JA023 M1KOHM, J.1/16 W...
  • Page 96 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8211 D1BA2400A014 M 240 OHM,J.1/16 W R8212 D1BA2400A014 M 240 OHM,J.1/16 W R8213 D0GA103JA015 M 10KOHM,J,1/16W R8214 D0GA103JA015 M 10KOHM,J,1/16W R8215 D1BA2400A014 M 240 OHM,J.1/16 W...
  • Page 97 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8617 D0GA103JA015 M 10KOHM,J,1/16W R8618 D0GA103JA015 M 10KOHM,J,1/16W R8620 D0GA103JA015 M 10KOHM,J,1/16W R8621 D0GA103JA015 M 10KOHM,J,1/16W R8624 D0GA560JA023 M 56 OHM, J,1/16W R8625 D0GA560JA023...
  • Page 98 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8754 D0GA103JA015 M 10KOHM,J,1/16W R8755 D0GB221JA065 M 220 OHM J 1/10W R8756 D0GD104JA052 M 100KOHM,J,1/8W 1 PAVCCZ R8757 D0GD102JA052 M 1.0KOHM,J,1/8W 1 PAVCCZ R8758 D0GD472JA052 M 4.7KOHM,J,1/8W...
  • Page 99 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R9400 EXB2HV103JV M 10 kOHM 1/16 W R9401 EXB2HV103JV M 10 kOHM 1/16 W R9402 EXB28V103JX M 10KOHM 1/32 W R9608 EXB2HV470JV M 47 OHM 1/16 W...
  • Page 100 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16286 F1H1H104A970 C 0.1UF, , 50V C16287 F1H1H104A970 C 0.1UF, , 50V C16314 F2A2E141A217 E 140UF, 250V C16315 ECJ1VB1A105K C 1UF, 10V C16316 ECJ1XB1C104K C 0.1UF, Z, 16V...
  • Page 101 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16813 F2A2T121A019 E 120UF, 220V 1 PAVCCZ C16833 F1K2J222A014 C 2200PF ,630V C16834 F1K2J222A014 C 2200PF ,630V C16842 F2A2C101A169 E 100UF, 160V C16843 ECJ1VB1A105K...
  • Page 102 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks K1MY55B00002 55P CONNECTOR CB10 K1MY55B00002 55P CONNECTOR CB11 K1MY55B00002 55P CONNECTOR CB12 K1MY55B00002 55P CONNECTOR CB13 K1MY55B00002 55P CONNECTOR CB14 K1MY55B00002 55P CONNECTOR CB15...
  • Page 103 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks D16641 B0FCCN000004 DIODE 1 PAVCCZ D16642 B0FCCN000004 DIODE 1 PAVCCZ D16643 B0FCCN000004 DIODE 1 PAVCCZ D16645 DZ2J150M0L ZENER DIODE D16646 DZ2J150M0L ZENER DIODE D16647 DZ2J150M0L...
  • Page 104 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks IC16724 C0CBADE00049 IC16784 MIP3910MSSCF IC16785 C0DBZYY00352 IC16786 MIP3910MSSCF IC16787 C0DBZYY00352 IC16792 C0BBAA000008 LINEAR IC IC16793 C0DBZMC00006 IC16795 C0CBALC00012 IC16921 C1ZBZ0004292 1 PAVCCZ IC17102 C0JBAU000088...
  • Page 105 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks Q16601 B1CFRQ000021 1 PAVCCZ Q16602 DSA2001S0L TRANSISTOR Q16606 DSC2001S0L TRANSISTOR Q16607 B1CBGD000001 Q16621 B1JBDN000004 TRANSISTOR 1 PAVCCZ Q16622 B1JBDN000004 TRANSISTOR 1 PAVCCZ Q16623 B1JBDN000004...
  • Page 106 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16193 D0GD750JA052 M 75 OHM,J,1/8W 1 PAVCCZ R16195 D0GF1R0JA047 M 1 OHM,J,1/3W R16196 D0GF102JA048 M 1.0 KOHM,J,1/3W 1 PAVCCZ R16197 D0GB220JA065 M 22 OHM J 1/10W...
  • Page 107 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16494 D1BB2001A055 M 2KOHM,J.1/10W R16497 D0GB473JA065 M 47KOHM J. 1/10W 1 PAVCCZ R16498 D0GB103JA065 M 10K OHM J 1/10W R16501 D0GB220JA065 M 22 OHM J 1/10W...
  • Page 108 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16634 D0GD222JA052 M 2.2KOHM,J,1/8W 1 PAVCCZ R16645 D0GB562JA065 M 5.6KOHM,J,1/10W 1 PAVCCZ R16646 D1BD8660A044 M 866 OHM,F.1/8W 1 PAVCCZ R16648 D0GF202JA047 M 2KOHM,J,1/3W R16649 D0GD330JA059...
  • Page 109 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16851 D0GB474JA065 M 470KOHM,J,1/10W R16852 D0GB474JA065 M 470KOHM,J,1/10W R16856 D0GB102JA065 M 1KOHM,J,1/10W R16873 ERA6YEB242 M 2.4KOHM, B 1/10W R16891 D1BF6982A058 M 69.8KOHM, 1/4W R16892 D1BF8252A058 M82.50KOHM, 1/4W...
  • Page 110 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R17144 D0GB102JA065 M 1KOHM,J,1/10W R17145 D0GBR00J0004 M 0 OHM J 1/10W R17146 D0GBR00J0004 M 0 OHM J 1/10W R17196 D0GB102JA065 M 1KOHM,J,1/10W R17201 D0GB101JA065...
  • Page 111 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ZA17101 K4CD01000013 AV TERMINAL ZA17102 K4CD01000013 AV TERMINAL ZA17103 K4CD01000013 AV TERMINAL ZA17104 K4CD01000013 AV TERMINAL ZA17201 K4CD01000013 AV TERMINAL ZA17202 K4CD01000013 AV TERMINAL...
  • Page 112 Model No. : TX-P46GW30/J Exploded View 1 S-67...
  • Page 113 Model No. : TX-P46GW30/J Exploded View 2 S-68...
  • Page 114 Model No. : TX-P46GW30/J Packing 1 S-69...
  • Page 115 Model No. : TX-P46GW30/J Packing 2 S-70...
  • Page 116 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks BAT-C-0672 Battery Cover of RC 1 PAVCCZ J0KG00000146 FERRITE CORE PACK K0RB00600019 SIDE UNIT ASSY 1 PAVCCZ K2AHYH000044 AC-INLET WITH CABLE 1 PAVCCZ K2CN3YY00006...
  • Page 117 Model No. : TX-P46GW30/J Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TXFEA02RAUE SPEAKER R ASSY 1 PAVCCZ TXFKP01QTUE SIDE TERMINAL COVER ASSY 1 PAVCCZ TXFKY5Z0121A CABINET ASSY 1 PAVCCZ TXJA11QRUE SPEAKER LEAD(A11-SPL/SPR) 1 PAVCCZ XSB4+8FNK...

This manual is also suitable for:

Tx-p46gw30j

Table of Contents
