CM10V .................. 19 CM12V/CM15V ..............22 CW115V/CW118V ..............25 CW218V ................28 C112VA/C115VA(分解手順) ..........30 NEUTRIK NL4FC PLUG WIRING CW218V (スピコンNEUTRIK NL4FCプラグの配線)......32 PARTS LIST 011868 S112VA: 200706 オープンプライス HAMAMATSU, JAPAN S115VA: 200706 オープンプライス Copyright (c) Yamaha Corporation. All rights reserved. PDF ’07.07...
Page 2
IMPORTANT NOTICE This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically Yamaha Products, are already known and understood by the users, and have therefore not been restated.
CLUB Series SPEAKER SYSTEM/ SUBWOOFER NETWORK C112 /CM12 (WJ367900) REAR PLACE LABEL FRONT EYELET APPROXIMATELY (4 PLACES) WHERE SHOWN SPACER (4 PLACES) NBY0730 CABLE TIE NBY0731 (1 PLACE) NBY0732 NBY0734 NBY0735 20'' BLUE 20'' YELLOW 20'' RED 20'' BLACK EYELET (4 PLACES) 4'' WHITE 187 x .015...
Page 5
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C115 /CM15 (WJ367800) PLACE LABEL REAR FRONT EYELET APPROXIMATELY (4 PLACES) SPACER WHERE SHOWN (4 PLACES) NBY0730 NBY0731 CABLE TIE NBY0732 (1 PLACE) NBY0734 NBY0735 20'' BLUE 20'' YELLOW 20'' RED 20'' BLACK (0.80) 4'' WHITE 187 x .015 187 x .015 LABEL DETAIL...
Page 6
CLUB Series SPEAKER SYSTEM/ SUBWOOFER CM10 (WJ368000) PLACE LABEL REAR FRONT EYELET APPROXIMATELY (4 PLACES) SPACER WHERE SHOWN (4 PLACES) NBY0730 NBY0731 CABLE TIE NBY0732 (1 PLACE) NBY0734 NBY0735 15'' BLUE 15'' YELLOW 15'' RED 15'' BLACK (0.80) 4'' WHITE 187 x .015 LABEL DETAIL 187 x .015...
Page 7
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C215 (WJ368100) SPACER (6 PLACES) 6.25 5.857 EYELET (6 PLACES) 30'' BLUE 30'' YELLOW 28'' RED/BLACK 28'' BLACK 2.393 31'' BLACK - WL 31'' RED + WL 4'' WHITE 187 x 187 x 0.015 0.015 10'' WHITE 4'' ORANGE 187 x...
Page 8
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C112 A (WJ368200) PLACE LABEL REAR FRONT EYELET APPROXIMATELY (4 PLACES) SPACER WHERE SHOWN (4 PLACES) NBY0730 NBY0731 CABLE TIE NBY0732 (1 PLACE) NBY0734 NBY0735 20'' BLUE 20'' YELLOW 20'' RED 10'' WHITE 20'' BLACK 10'' ORANGE (0.80) LABEL DETAIL...
Page 9
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C115 A (WJ368300) REAR FRONT EYELET APPROXIMATELY (4 PLACES) SPACER WHERE SHOWN (4 PLACES) NBY0730 NBY0731 CABLE TIE NBY0732 (1 PLACE) NBY0734 NBY0735 20'' BLUE 20'' YELLOW 20'' RED 10'' WHITE 20'' BLACK 10'' ORANGE (0.80) LABEL DETAIL SCALE:NONE...
CLUB Series SPEAKER SYSTEM/ SUBWOOFER DISASSEMBLY PROCEDURE C112V/C115V Metal Handle Rubber Foot (Time required: About 1 minute) (Time required: About 1 minutes) Remove the six (6) screws marked [160]. The metal Remove the screw marked [10d]. The rubber foot handle can then be removed. (Photo 1) can then be removed.
Page 12
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Woofer (Time required: About 3 minutes) Remove the eight (8) screws marked [140A]. The Remove the eight (8) screws marked [150]. The Metal grille assembly can then be removed. (Photo 4) woofer can then be removed. (Photo 5) [140A] Horn assembly [130B]...
Page 13
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Diaphragm assembly Photo 8 Network Network (Time required: About 4 minutes) Remove the woofer. (See procedure 4) Remove the four (4) screws marked [170]. The network can then be removed. (Photo 9) [170] [170]: Pan Head SM Screw PHSMS #6 x 3/4 BLK (WJ911700) Photo 9 Input Assembly (Time required: About 2 minutes)
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C112VA/C115VA Woofer (Time required: About 3 minutes) Remove the eight (8) screws marked [140A]. The Remove the eight (8) screws marked [150]. The metal grille assembly can then be removed. (Photo 1) woofer can then be removed. (Photo 2) [140A] Horn assembly [130]...
Page 15
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Diaphragm assembly Photo 5 Network Network (Time required: About 4 minutes) Remove the woofer. (See procedure 1) Remove the four (4) screws marked [170]. The network can then be removed. (Photo 6) [170] [170]: Pan Head SM Screw PHSMS #6 x 3/4 BLK (WJ911700) Photo 6 Input Assembly (Time required: About 2 minutes)
CLUB Series SPEAKER SYSTEM/ SUBWOOFER C215V Metal Handle Rubber Foot (Time required: About 1 minute) (Time required: About 1 minutes) Remove the six (6) screws marked [150]. The metal Remove the screw marked [10d]. The rubber foot handle can then be removed. (Photo 1) can then be removed.
Page 17
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Horn Assembly (Time required: About 3 minutes) Remove the metal grille assembly. (See procedure 3-1) Diaphragm Assembly Remove the eight (8) screws marked [140]. The horn 4-4-1 Remove the three (3) screws marked [A]. The assembly can then be removed.
Page 18
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Network (Time required: About 4 minutes) Network Remove the upper woofer. (See procedure 3) Remove the six (6) screws marked [160]. The network can then be removed. (Photo 8) [160] [160]: Pan Head SM Screw PHSMS #6 x 3/4 BLK (WJ911700) Photo 8 Input Assembly (Time required: About 2 minutes)
CLUB Series SPEAKER SYSTEM/ SUBWOOFER CM10V Handle Assembly Rubber Foot (Time required: About 1 minutes) (Time required: About 1 minute) Remove the screw marked [10d]. The rubber foot Remove the two (2) screws marked [160]. The handle can then be removed. (Photo 3) assembly can then be removed.
Page 20
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Woofer (Time required: About 3 minutes) Remove the eight (8) screws marked [140A]. The Remove the four (4) screws marked [150A]. The metal grille assembly can then be removed. (Photo 4) woofer can then be removed. (Photo 5) [140A] [150B] [150A]...
Page 21
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Input Assembly (Time required: About 2 minutes) Remove the six (6) screws marked [140C]. The input Remove the hexagonal nut. The plain washer and assembly can then be removed. (Photo 7) phone jack can then be removed. (Photo 7, 8) Remove the two (2) screws marked [90f] and the two (2) hexagonal nuts marked [90e].
CLUB Series SPEAKER SYSTEM/ SUBWOOFER CM12V/CM15V Metal Handle Rubber Foot (Time required: About 1 minute) (Time required: About 1 minutes) Remove the six (6) screws marked [160]. The metal Remove the screw marked [10d]. The rubber foot handle can then removed. (Photo 1) can then be removed.
Page 23
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Woofer (Time required: About 3 minutes) Remove the eight (8) screws marked [150]. The Remove the eight (8) screws marked [140A]. The woofer can then be removed. (Photo 5) metal grille assembly can then be removed. (Photo 4) [130B] [150] [140A]...
Page 24
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Diaphragm assembly Photo 8 Network (Time required: About 4 minutes) Network Remove the horn assembly. (See procedure 5) Remove the four (4) screws marked [170]. The network can then be removed. (Photo 9) [170] [170]: Pan Head SM Screw PHSMS #6 x 3/4 BLK (WJ911700) Photo 9 Input Assembly (Time required: About 2 minutes)
CLUB Series SPEAKER SYSTEM/ SUBWOOFER CW115V/CW118V Metal Handle Rubber Foot (Time required: About 1 minute) (Time required: About 1 minutes) Remove the six (6) screws marked [150]. The metal Remove the screw marked [10d]. The rubber foot handle can then be removed. (Photo 1) can then be removed.
Page 26
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Woofer (Time required: About 3 minutes) Remove the eight (8) (The screws of CW118V model Remove the eight (8) screws marked [140]. The is twelve (12)) screws marked [130A]. The metal grille woofer can then be removed. (Photo 5) assembly can then be removed.
Page 27
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Wire Harness A (Time required: About 5 minutes) Remove the woofer. (See procedure 4) Remove the screw marked [130C]. The wire harness A can then be removed. (Photo 8, 9) Poly switch Poly switch Wire harness A [130C] [130]: TH Sheet Metal Screw #6 x 5/8 BLK (WJ493800) Wire harness A...
CLUB Series SPEAKER SYSTEM/ SUBWOOFER CW218V Metal Handle Rubber Foot (Time required: About 1 minute) (Time required: About 1 minutes) Remove the six (6) screws marked [150]. The metal Remove the screw marked [10d]. The rubber foot handle can then be removed. (Photo 1) can then be removed.
Page 29
CLUB Series SPEAKER SYSTEM/ SUBWOOFER Input Assembly (Time required: About 2 minutes) Remove the six (6) screws marked [130B]. The input Remove the hexagonal nut. The plain washer and assembly can then be removed. (Photo 5) phone jack can then be removed. (Photo 5, 6) Remove the two (2) screws marked [90f] and the two (2) hexagonal nuts marked [90e].
CLUB Series SPEAKER SYSTEM/ SUBWOOFER NEUTRIK NL4FC PLUG WIRING (スピコン NEUTRIK NL4FC プラグの配線) If you will be using the Neutrik connectors for speaker input, wire the plugs as shown below. (Neutrik NL4FCプラグは図のように配線してく ださい。 ) Be sure to use proper speaker cable — NOT shielded instrument or line cable — for all speaker connections. (ケーブルは、...
Page 33
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PARTS LIST CONTENTS(目次) OVERALL ASSEMBLY(総組立) ........2 C112 V ................2 • C112 V A ................4 • C115 V ................6 • C115 V A ................8 • C215 V ................10 • CM10 V ................. 12 •...
Page 34
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : C112 V 50 60 20 60 60 90 Input Assembly Horn Assembly Metal Grille Assembly 50b1...
Page 35
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 C112V Overall Assembly PA J 総 組 立 Y (WJ38650) Overall Assembly PA CHN 総 組 立 O (WK73590) Cabinet Assembly キ...
Page 36
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : C112 V A 10c 10e 50 60 60 90 10e 200 10c 10e Input Assembly Metal Grille Assembly Horn Assembly 10c 10e 50b1...
Page 37
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 C112VA Overall Assembly PA J 総 組 立 YJ (WJ38660) Overall Assembly PA CHN 総 組 立 O (WK73600) Cabinet Assembly キ...
Page 38
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : C115 V 50 60 20 60 60 90 Input Assembly Horn Assembly Metal Grille Assembly 50b1...
Page 39
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 C115V Overall Assembly PA J 総 組 立 Y (WJ38670) Overall Assembly PA CHN 総 組 立 O (WK73610) Cabinet Assembly キ...
Page 40
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : C115 V A 50 60 60 90 Input Assembly Metal Grille Assembly Horn Assembly 50b1...
Page 41
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 C115VA Overall Assembly PA J 総 組 立 YJ (WJ38680) Overall Assembly PA CHN 総 組 立 O (WK73620) Cabinet Assembly キ...
Page 42
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : C215 V 50 60 20 60 20 60 20 60 60 90 Input Assembly Metal Grille Assembly Horn Assembly 50b1...
Page 43
SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 C215V Overall Assembly PA J 総 組 立 Y (WJ38690) Overall Assembly PA CHN 総 組 立 O (WK73630) Cabinet Assembly キ...
Page 44
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CM10 V 50 60 60 90 140 200 20b 20c Input Assembly Metal Grille Assembly...
Page 45
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CM10V Overall Assembly PA J 総 組 立 Y (WJ38700) Overall Assembly PA CHN 総 組 立 O (WK73640) Cabinet Assembly キ...
Page 46
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CM12 V 50 60 140 200 60 90 20 60 Input Assembly Horn Assembly Metal Grille Assembly 50b1...
Page 47
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CM12V Overall Assembly PA J 総 組 立 Y (WJ38710) Overall Assembly PA CHN 総 組 立 O (WK73650) Cabinet Assembly キ...
Page 48
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CM15 V 50 60 60 90 20 60 Input Assembly Horn Assembly Metal Grille Assembly 50b1...
Page 49
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CM15V Overall Assembly PA J 総 組 立 Y (WJ38720) Overall Assembly PA CHN 総 組 立 O (WK73660) Cabinet Assembly キ...
Page 50
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CW115 V 40 50 30 50 Metal Grille Assembly Input Assembly • WIRING DIAGRAM FOR INPUT PANEL 50 90...
Page 51
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CW115V Overall Assembly PA J 総 組 立 Y (WJ38730) Overall Assembly PA CHN 総 組 立 O (WK73670) Cabinet Assembly キ...
Page 52
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CW118 V 40 50 30 50 Metal Grille Assembly Input Assembly • WIRING DIAGRAM FOR INPUT PANEL 50 90...
Page 53
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CW118V Overall Assembly PA J 総 組 立 Y (WJ38740) Overall Assembly PA CHN 総 組 立 O (WK73680) Cabinet Assembly キ...
Page 54
CLUB Series SPEAKER SYSTEM/ SUBWOOFER OVERALL ASSEMBLY (総組立) : CW218 V 40 50 40 50 20 50 Metal Grille Assembly 50 90 Input Assembly • WIRING DIAGRAM FOR INPUT PANEL...
Page 55
CLUB Series SPEAKER SYSTEM/ SUBWOOFER PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 CW218V Overall Assembly PA J 総 組 立 Y (WJ38750) Overall Assembly PA CHN 総 組 立 O (WK73690) Cabinet Assembly キ...
