SPARE TIRE STORAGE:

The spare tire is located in the storage area found under the
passenger side rear bed, (see Picture B-P36A).
Unless equipped with optional Continental Spare Tire Kit,
(see Picture B-P37).
Brace yourself for the weight of the tire, (40 kg / 80 lbs).
The jack is located in the storage area found under the
passenger side rear bed mounted on the outside wall,
(see Picture B-P36).
Interior storage light switch, (see Picture B-P36).
CONTINENTAL SPARE TIRE KIT (Optional):
To access full size spare tire:
1. Unlock and remove chrome ring and fiberglass disc, (see picture B-P38).
2. While holding the spare tire, in the upright position, remove catch pin on the elbow of the receiver.
3. Slowly lower the spare tire to the flat position, (see Picture B-P39). Brace yourself for the weight of the
tire, (40 kg / 80 lbs).
4. Remove lug nuts on spare tire to remove from carrier.
To store tire, repeat these steps in reverse.
Note: To open driver side rear door, the spare tire kit must be lowered.
Picture B-P37: Spare tire kit.
Mineraling:
Due to the properties of natural Maple wood, Home & Park
makes no warranty against the mineraling of wood
components, (see Picture B-P40).
D D o o c c N N o o : : 21906532-210C05 R R e e v v : : 02
Picture B-P38: Remove chrome ring
and fibreglass disc.
C C o o p p y y r r i i g g h h t t © © H H a a n n m m a a r r M M o o t t o o r r C C o o r r p p o o r r a a t t i i o o n n 2 2 0 0 0 0 5 5
Light Switch
Picture B-P36: Location of jack, handle
and light switch.
Picture B-P36A: Storage area for spare tire.
Picture B-P39: Remove catch pin and
lower carrier to remove tire.
Picture B-P40: Maple cabinet showing mineraling.
DAILY LIVING
