Removing/emptying grass
collection bag
WARNING! Always check
the safety flap close the
discharge outlet before using.
Never lift the safety flap when the
lawn mower is being used without
fitted grass collection bag.
Rear discharge
STORAGE
BATTERY STATUS (See Fig. F)
Before starting or after use, press the button
"POWERTEST" on the machine to check the battery
capacity. During operation, the battery capacity will be
indicated automatically by the battery power indicator.
The indicator constantly senses and displays the
battery condition as follows:
Battery power
indicator status
Five green lights
( ) are
illuminated.
Two, three or four
green lights are
illuminated.
Only one green
light ( )
16
is illuminated.
No light is
illuminated.
Only one light is
flashing twice per
cycle.
Only one light
is flashing three
times per cycle.
Only one light is
flashing four times
per cycle.
MOWING TIPS
NOTE: ALWAYS INSPECT AREA WHERE MOWER
IS TO BE USED AND REMOVE ALL STONES,
STICKS, WIRE, METAL AND OTHER DEBRIS
WHICH MIGHT BE THROWN BY THE ROTATING
BLADE.
1. Mow across the face of slopes, never up-and-
down. Exercise extreme caution when changing
direction on slopes. Do not mow excessively steep
See Fig. I2
See Fig. J
See Fig. K1, K2
Battery condition
The two batteries are in a
highly charged condition.
The two batteries have a
remaining charge. The more
lights are illuminated, the
more battery capacity.
At least one battery is almost
depleted and needs to be
charged.
At least one battery is not
fully installed or battery may
be defective.
At least one battery is over
discharged (please refer to
the battery charge condition),
please recharge the two
batteries at once before use
again or storage.
At least one battery is hot,
wait for them cool down
before start again.
The machine is over load.
Raise the cutting height or
push slowly.
Cordless Lawn Mower
WG779E WG779E.X
slopes. Always maintain good footing.
2. Release bail handle to turn mower "OFF" when
crossing any graveled area (stones can be thrown
by the blade).
3. Set mower at highest cutting height when mowing
in rough ground or in tall weeds. Removing too
much grass at one time can cause circuit breaker
to trip, which stops mower.
4. If a grass bag is used during the fast growing
season, the grass may tend to clog up at the
discharge opening. Release bail handle to turn
mower "OFF" and remove the safety key. Remove
the grass bag and shake the grass down to the
back end of the bag. Also clean out any grass or
debris which may be packed around the discharge
opening. Replace the grass collection bag.
5. If mower should start to vibrate abnormally,
release bail handle to turn mower "OFF" and
remove safety key. Check immediately for cause.
Vibration is a warning of trouble. Do not operate
mower until a service check has been made.
6. ALWAYS RELEASE BAIL HANDLE TO TURN
MOWER "OFF" AND REMOVE SAFETY KEY
WHEN LEAVING IT UNATTENDED EVEN FOR
A SHORT PERIOD OF TIME.
CUTTING AREA
The cutting area can be affected by several factors,
such as cutting height, lawn humidity, grass length
and density. Besides, starting and stopping the mower
too many times during operation will reduce the
cutting area.
The table below gives the relationship between cutting
conditions and cutting area.
Cutting conditions
Grass Cutting
conditions height
Very thin, dry cut 7cm to
grass 5cm
cut 7cm to
Thin, dry grass
3cm
* Used with two fully charged battery packs.
TIPS:
1) It is recommended to mow your lawn more
frequently, walk at normal pace, and not to start/
stop the mower too often during operation. Please
always use the same two batteries and charge the
two batteries at same time.
2) For best performance, please ensure use a fully
charged battery pack and always cut off 1/3 or less
of the grass height.
3) Walk slowly when cutting long grass, so as to have
more effective cutting and properly discharge the
clippings.
4) Avoid cutting wet grass, otherwise it will stick to
the underside of the deck and the clippings cannot
be collected or discharged properly.
5) A higher cutting height shall be applied to new or
thick grass and it will extend the battery duration.
Cutting area (maximum)
2.0 Ah 2.5 Ah 4.0 Ah
battery battery battery
230m 2 * 280m 2 * 460m 2
120m 2 * 140m 2 * 230m 2
*
*
