INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
Fits for most 26-50 inches Plasma, LCD and LED TVs .
Weight capacity: 27kg (60 LBS) .
Thank you for purchase!We strive to provide products and services of exceptional quality.
We sincerely invite you to write an unbiased review. For parts missed or installation problems,
please contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email
us by customerservice@mountingdream.com , so that we may solve the issue for you.
Max VESA:400X400mm/16X16"
MODEL : MD2501
(A0)

Advertisement

loading
Need help?

Need help?

Do you have a question about the MD2501 and is the answer not in the manual?

Questions and answers

Related Manuals for Mounting Dream MD2501

Summary of Contents for Mounting Dream MD2501

  • Page 1 INSTALLATION INSTRUCTION Max VESA:400X400mm/16X16" MODEL : MD2501 Please read this instruction carefully before installation . Fits for most 26-50 inches Plasma, LCD and LED TVs . Weight capacity: 27kg (60 LBS) . Thank you for purchase!We strive to provide products and services of exceptional quality.
  • Page 2 Avertissement de sécurité: bienvenue à choisir le support suspendu de téléviseur de la Vue Aérienne, pour garantir un usage sécurité du produit MD2501, préserver le risque contre vous-même et des tiers et éviter ledommage des biens, veuillez lire soigneusement ce manuel avant l'usage. Si vous ne pouvez pas comprendre cette notice ou en cas de doute sur la sécurité...
  • Page 3 Before getting started, let's make sure this mount is perfect for you! Is your TV VESA equal to/greater than 75x75mm/3x3in and equal to/less than 400x400mm/16x16in? Max:400mm/16" Yes --- Perfect! Max: 400mm/16" No --- This mount is NOT compatible. Does your TV (including accessories) weigh more than 60 lbs (27kg)? NO --- Perfect! 60 lbs...
  • Page 4 For parts shortage or damage, please contact us directly by customerservice@mountingdream.com. Attention: New delivery will be timely arranged to replace missed or defective parts. Installation tools: 2M 2M Socket wrench Band tape 2m Stud finder Pencil Screwdriver 1/2"(13mm) 3/8" 7/32" Hammer Electrodrill Masonry Drill Bit...

  • Page 5: Wall Mounting Hardware

    Wall mounting hardware ： --Lag bolt --4mm Allen key --M8 Washer 4pcs 4pcs TV mounting hardware ： a--M4X12 bolt b--M5X12 bolt c--M6X12 bolt d--M8X25 bolt 4 pcs 4 pcs 4 pcs 4 pcs e--M4X30 bolt f--M5X30 bolt g--M6X35 bolt h--M8X50 bolt 4 pcs 4 pcs 4 pcs...
  • Page 6 Step 1 Wall plate installation : Wall plate installation in wood stud To avoid potential body injury or property damage: 1. Wall mount must be installed into wood stud's center, not drywall alone. 2. Drywall covering the wood stud must not exceed 16 mm (5/8 in.). 3.
  • Page 7 ⑤ Put 4 lag bolts through the washers into the drilled holes, and tighten each bolt by using a socket wrench to mount the wall plate securely. Before totally tightening the lag bolt please attach the bubble level on the wall plate to check whether it is level.
  • Page 8 Step 2 Select TV hardware (diameter / length / combination) Bolt diameter: hand thread bolts into threaded inserts on the back of TV to determine correct bolt diameter (M4, M5, M6, M8). Bolt length: verify adequate thread engagement with bolts or bolts/spacers combination.
  • Page 9 Step 3 Attach brackets to the back of TV ① For the TV with flat back, mount the brackets with bolt/washer/spacer combination. Tips: Make sure the ends of TV brackets with round holes are facing upward. Round hole is for upper VESA hole, and long slot hole for lower VESA hole.
  • Page 10 ② For TV with inset mounting holes, mount the brackets with bolt/washer/spacer combination. (Spacers are highly recommended to be added, thus enlarge the space between TV and brackets for better functionality.) Tips: Make sure the ends of TV brackets with round holes are facing upward.
  • Page 11 Step 4 Hang the pre-assembled TV unit on the wall plate unit,then fasten the safety bolt ① with screwdriver. Attention: Cables are highly recommended to plug in before hanging the TV on the wall plate. figure 1 Two people are recommended to hold and position the TV.
  • Page 12 Step 5 Level the mount (±3°): Loosen 4 leveling bolts by MAXIMUM 2 turns to adjust the TV plate, and fasten leveling bolts with Allen key after adjustment.(figure 2) WARNING: Don't over loose the bolts to prevent the TV falling off. 4 Leveling bolts ±3°...

  • Page 13: Product Dimensions

    Product dimensions: 435mm MAX:400mm 420mm +5° MAX: 400mm -15° 420mm 86mm +45°/-45° If you have any questions about the installation,please feel free to contact us at telephone (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific time) or email us by customerservice@mountingdream.com . For more information, please visit our website:www.mountingdream.com...
