HT994SJ-A0_BUSAJJK DVD DIGITAL THEATER SYSTEM TH-G31 Consists of XV-THG31 SP-THG51F, SP-THG61C and SP-THG50W TUNING TUNING For Customer Use: Enter below the Model No. and Serial No. which are located on INSTRUCTIONS the rear of cabinet. Retain this information for future reference. Model No.
Page 2
CAUTION: The apparatus shall not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such as vases, shall be placed on the apparatus. RISK OF ELECTRIC SHOCK DO NOT OPEN FCC WARNING: This equipment may generate or use CAUTION: TO REDUCE THE RISK radio frequency energy.
Page 3
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL. AND THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard.
Introduction To ensure proper use of this product, please read this Notes on Discs owner’s manual carefully and retain it for future reference. Handling Discs This manual provides information on the operation Do not touch the playback side of the disc. Hold the and maintenance of your DVD player.
Types of Playable Discs Regional Code This unit has a regional code printed on the rear of the (8 cm / 12 cm disc) unit. This unit can play only DVD discs labelled as the same as the rear of the unit or “ALL”. Audio CD (8 cm / 12 cm disc) Notes on Regional Codes...
Front Panel d e f g h i a 1 1 / / ' ' (STANDBY/ON) g X X (PAUSE) Switches the unit ON and OFF. Pause playback. FM MODE b Disc Tray This will change the tuner from stereo to mono Insert a disc here.
Remote Control 0-9 numerical buttons: Selects AUDIO (1 1 / / ' ' ) numbered options in a menu. Switches the unit ON and OFF. FUNCTION SURROUND Selects the surround mode. Selects the function (DVD/CD, FM) INPUT SCAN MODE Sets the output resolution for HDMI Changes the input source ( AUX, and COMPONENT VIDEO OUT AUX OPT, AUDIO IN)
Installation and Setup TV Connection Video connection Connect the MONITOR OUT jack from the DVD/CD Make one of the following connections, depending on Receiver to the VIDEO IN jack on the TV using the the capabilities of your existing equipment. video cable (V).
Optional Equipment Connection Rear of DVD/CD Receiver (not supplied) (not supplied) VIDEO AUDIO (L) AUDIO (R) OPTICAL Auxiliary device DVD Player (or Digital Device, etc) AUX IN connection (A) Connect a Output of auxiliary device to the AUX AUDIO Input (L/R) Connector. OPTICAL IN connection (O) Connect an optical output of DVD Player (or Digital Device etc) to the OPTICAL IN connector.
HDMI Connection HDMI compatible TV About HDMI HDMI HDMI (High Definition Multimedia Interface) supports both video and audio on a single digital connection for an easy all- digital output to an HDMI or DI-equipped TV. Connection to an HDMI TV requires an HDMI cable while connection to a DVI-equipped TV requires a DVI adapter besides a HDMI cable.
Speaker System Connection Connect the speakers using the supplied speaker cables. To obtain the best possible surround sound, adjust the speaker parameters (volume, distance, etc.). Center speaker Notes: Front speaker Front speaker (Left) (Right) • Be sure to match the speaker cable to the appropriate terminal on the components: + to + and –...
Displaying Disc Information Initial Settings on-screen By using the Setup menu, you can make various adjustments to items such as picture and sound. You can display various information about the disc You can also set a language for the subtitles and the loaded on-screen.
DISPLAY General Operation 1. Press SETUP. The Setup menu appears. TV Aspect 4:3 – Select when a standard 4:3 TV is connected. 16:9 – Select when a 16:9 wide TV is connected. 2. Use v / V to select the desired option then press Display Mode B to move to the second level.
AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the player’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears.
5.1 Speaker Setup Rating Blocks playback of rated DVDs based on their Test contents. Not all discs are rated. Press b / B to test the signals of each speaker. Adjust 1. Select “Rating” on the LOCK menu then press B. the volume to match the volume of test signals 2.
Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. . / > During playback, press . or > to go to the next chapter/track or to return to the beginning of the current chapter/track.
Additional features Time Search To start playing at any chosen time on the disc: 1. Press DISPLAY during playback. 2. Press v / V to select the time clock icon and “--:--:--” appears. 3. Input the required start time in hours, minutes, and seconds from left to right.
Playing an Audio CD or ID3 TAG When playing a file containing information such as MP3/WMA file track titles, you can see the information by pressing DISPLAY. (Song, Artist, Album, Genre, Comment) This unit can play Audio CDs or MP3/WMA files. MP3/ WMA/ Audio CD Once you insert an MP3/WMA files recording media or Audio CD a menu appears on the TV screen.
Programmed Playback Repeat Programmed Tracks 1. Press REPEAT when playing a disc. The repeat The program function enables you to store your icon appears. Favourite tracks from any disc in the receiver memory. 2. Press REPEAT to select a desired repeat mode. A program can contain 30 tracks.
Viewing a JPEG file Still Picture 1. Press PAUSE (X X ) during the slide show. This unit can play discs with JPEG files. The DVD/CD Receiver will now go into the PAUSE Before playing JPEG recordings, read the notes on (X X ) mode.
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM. Before tuning, Preset radio stations in the DVD/CD Receiver’s make sure that you have turned down the volume. memory first (see “Presetting radio stations” on the left).
Sleep Timer Setting Enjoying audio form an external source Press SLEEP/DIMMER one or more times to select delay time between 10 and 180 minutes, after the You can enjoy audio form an external source through player will turn off. your unit. To check the remaining time, press SLEEP/DIMMER Press INPUT repeatedly to select the desired input To cancel the sleep function, press SLEEP/DIMMER...
Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian 7684...
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the No power. • The power cord is disconnected. wall outlet. • Insert a disc. (Check that the DVD or, The power is on, but •...
Page 26
Symptom Cause Correction • The antenna is positioned or connected • Connect the antenna securely. Radio stations cannot poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...
Specifications Power supply 120 V ~ 60 Hz Power consumption 130 W Net Weight 3.6 kg External dimensions (W x H x D) 430 x 76 x 317 mm Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal Operating humidity 5% to 85% Laser Semiconductor laser, wavelength 650 nm...
Page 28
ARRANTY (Only in U.S.A.) ARRANTY (Only in U.S.A.)
