ComfortNet™ CTK04 Communicating Thermostat
With wireless accessories
Modulating control for up to 4 Heat/2 Cool communicating heat pump systems or up to
3 Heat/2 Cool communicating gas heat, electric cooling systems for residential and
commercial applications.
Installation guide for:
•
ComfortNet CTK04
Communicating Thermostat
•
Portable Comfort Control
•
Wireless Outdoor Sensor
Quick start guide
Install thermostat ..........................................................page 4
1
2
Power optional accessories ................................................... 7
3
Setup thermostat ................................................................... 8
4
Link optional accessories ...................................................... 9
5
Mount optional accessories ................................................. 11
6
Installer options ................................................................... 12
ComfortNet™ User Menu .................................................... 13
Device replacement and specifications ..........................21-23
DISCONNECT POWER BEFORE INSTALLATION. Can cause electrical shock or equipment damage.
MERCURY NOTICE: If this product is replacing a control that contains mercury in a sealed tube, do not place the old control in
the trash. Contact the Thermostat Recycling Corporation at www.thermostat-recycle.org or 800-238-8192 for information on how and
where to properly and safely dispose of your old thermostat.
Must be installed by a trained, experienced technician. Read these instructions carefully. Failure to follow these
instructions can damage the product or cause a hazardous condition.
System
Installation
Guide
•
Wireless Indoor Sensor
•
RedLINK
Internet Gateway
™
•
Entry/Exit Remote
•
Vent Boost Remote
69-2688-11
I/O-CHTSTAT03
Advertisement
Related Manuals for Honeywell ComfortNET CTK04
Summary of Contents for Honeywell ComfortNET CTK04
-
Page 1: Table Of Contents
Modulating control for up to 4 Heat/2 Cool communicating heat pump systems or up to 3 Heat/2 Cool communicating gas heat, electric cooling systems for residential and commercial applications. Installation guide for: • ComfortNet CTK04 • Wireless Indoor Sensor Communicating Thermostat •... - Page 2 System Installation Guide The ComfortNet advantage The premium Honeywell ComfortNet™ control system is easy to use, energy-effi- cient, reliable and ensures the system is set up properly. Advanced operating algo- rithms built into the control delivers efficient equipment operation while providing eco- nomical comfort.
- Page 3 CTK04 ComfortNet™ Communicating Thermostat Installation This booklet contains installation instructions and information on the thermostat and wireless accessories. Separate installation instructions for the furnace or air handler and outdoor AC condensing unit or heat pump are provided with the appropriate equipment.
-
Page 4: Install Thermostat
System Installation Guide Install thermostat Thermostat Mounting Mount the thermostat approximately 5 feet from the floor on an interior wall using the included screws and anchors. Drill 3/16" holes for drywall and 7/32" holes for plaster. Do not install the thermostat where it can be affected by: •... - Page 5 CTK04 ComfortNet™ Communicating Thermostat Install thermostat Wiring Thermostat, Indoor Unit and Outdoor Unit Wire Thermostat to Indoor Unit Connect 1, 2, R and C from the thermostat to 1, 2, R and C at the Indoor Unit. Wire Outdoor Unit Connect wires 1 and 2 from the Indoor Unit to 1 and 2 at the Outdoor Unit.
- Page 6 RedLINK Internet Gateway ™ The Honeywell RedLINK Internet Gateway gives your customers remote access to home climate-control systems from any location with Internet access. Using a Web browser, users can review and adjust indoor temperature, system mode and other settings. The Gateway can also send alerts to as many as 6 email addresses if a problem occurs.
-
Page 7: Power Optional Accessories
CTK04 ComfortNet™ Communicating Thermostat Power optional accessories TrueSTEAM Connect the ABCD terminals between TrueSTEAM and the THM4000 Wireless Adapter. Adjust the DIP Switches on TrueSTEAM as follows when using the Wireless Adapter: DIP3: UP DIP4: UP TrueSTEAM DIP5: DOWN THM4000R1000 MCR31476 Entry/Exit Remote or Vent Boost Remote 1 Remove the cover. -
Page 8: Setup Thermostat
System Installation Guide Setup thermostat Initial Power Up 1 Turn on AC power to the system. 2 Select Language. Press Next. 3 Select Application (Residential or Commercial). Press Next. 4 Enter a Device Name. Press Next. The thermostat will iden tify the number of units connected and then prompt the installer to select the equipment (Furnace or Air Handler, Heat Pump or... -
Page 9: Link Optional Accessories
CTK04 ComfortNet™ Communicating Thermostat Link optional accessories to wireless network If you need to return to the "Add Device" screen to add devices later, press MENU and scroll down to press INSTALLER OPTIONS. Enter the date code (password) when prompted. The date code is printed on the back of the thermostat; or press MENU > EQUIPMENT STATUS to find the date code. - Page 10 System Installation Guide Link optional accessories to wireless network Portable Comfort Control Press CONNECT on the Portable Comfort Control display screen. Press DONE when the screen displays "Connected." Press NO at the next screen to save and exit. (Or press YES to link another thermostat.) CONNECT Error messages:...
-
Page 11: Mount Optional Accessories
CTK04 ComfortNet™ Communicating Thermostat Mount optional accessories [If no sensors are used, skip to Section 6.] To install outdoor air sensor 1 Mount the sensor on a vertical exterior wall, at least 6 inches below any overhang. Choose a location protected from direct sunlight. -
Page 12: Installer Options
After you enter the password, press CREATE SETUP to setup the thermostat. A brief summary of installer options follows. You can download a complete list of all options at http://customer.honeywell.com. Create Setup: Press CREATE SETUP to set all system settings one by one. -
Page 13: Comfortnet User Menu
CTK04 ComfortNet™ Communicating Thermostat Installer options (ISU) Function Function 4130 Entry/Exit Remote - 9100 High Humidity Comfort Reset Setting Away/Unoccupied Heat Setpoint 9180 Dehumidification Away Mode 4140 Entry/Exit Remote - 9190 Dehumidification Away Mode - Fan Control Vacation/Holiday Cool Setpoint 9200 Dehumidification Away Mode - 4140... - Page 14 System Installation Guide Wiring humidifier to the IFC To change installer setup (ISU) information, see pages 12-13. Wiring TrueSTEAM to IFC THERMOSTAT TRUESTEAM 24 V 24 V 1. WIRE THERMOSTAT AND TrueSTEAM AS SHOWN. 2. SET THERMOSTAT ISU 8000 TO “STEAM”. 3.
- Page 15 CTK04 ComfortNet™ Communicating Thermostat Heat pump with outdoor temperature lockouts Outdoor temperature lockouts are optional. See Installer Setup options (ISU 3120). Electric - Backup heat allowed to run with heat pump Heat pump only Backup heat lockout Heat pump with backup heat as needed * Compressor lockout Backup heat only No backup heat unless indoor temperature drops to selected Backup Heat Differential setting, or Backup Heat...
- Page 16 System Installation Guide Basic and Advanced Temperature Control Options (ISU 3010) Basic Options: The Installer Setup displays basic temperature control options which include Backup Heat Differential, Backup Heat Upstage Timer and Outdoor Temperature Lockouts. Note: Outdoor Temperature Lockouts only apply to Heat Pump applications.
- Page 17 CTK04 ComfortNet™ Communicating Thermostat Humidification The thermostat reads the indoor humidity level and allows the user to set a humidifi- cation setting with or without window protection. Window Protection Window Protection limits the amount of humidity to prevent frost or condensation on windows.
- Page 18 System Installation Guide Dehumidification - Commercial The thermostat reads the indoor humidity level and allows the user to set a dehumidification setting. Dehumidification using the cooling system has the following methods of dehumidification control (ISU 9080): Basic: This option uses the cooling system to reach the desired humidity level. Minimum On Time and High Humidity Comfort Reset are not used with this method.
- Page 19 CTK04 ComfortNet™ Communicating Thermostat Dehumidification Away Mode Dehumidification Away Mode protects the home when unoccupied for long periods of time during hot and humid weather by maintaining the desired humidity and temperature settings. To start Dehumidification Away Mode, press Menu, then press Dehumidification Away Mode. The thermostat automatically follows settings that are set by the dealer during installer setup.
- Page 20 System Installation Guide Indoor sensor operation Temperature control The thermostat can be set to respond to its internal temperature sensor, or to an optional remote indoor sensor. If multiple sensors are used, the thermostat will respond to an aver- age of temperatures detected at each sensor. Humidification control If optional remote indoor sensors are installed, you can choose which sensor you want to use...
-
Page 21: Device Replacement And Specifications
CTK04 ComfortNet™ Communicating Thermostat Alerts Log MENU > INSTALLER OPTIONS > DATA LOGS > ALERTS LOG The thermostat saves the most recent 25 alerts. It records the date, time, alert status (snoozed, dismissed, recovered), and diagnostic information to help you identify and correct problems. - Page 22 Portable Comfort Control: 6-1/4 x 3-1/8 x 1-5/8 inches (158 x 80 x 38 mm) RedLINK Internet Gateway: 6 x 4-7/8 x 2-1/2 inches (152 x 124 x 64 mm) Electrical Ratings 18 to 30 VAC Accessories & Replacement Parts Item Honeywell Part Number RedLINK Internet Gateway THM6000R1002 Entry/Exit Remote REM1000R1003 Vent Boost Remote...
- Page 23 CTK04 ComfortNet™ Communicating Thermostat Regulatory information FCC Compliance Statement (Part 15.19) (USA only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. FCC Warning (Part 15.21) (USA only) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 24 Honeywell International Inc. Goodman Manufacturing Co., LP 1985 Douglas Drive North Suite 500 Golden Valley, MN 55422 5151 San Felipe http://customer.honeywell.com Houston, TX 77056 ® U.S. Registered Trademark. © 2015 Honeywell International Inc. 69-2688—11 M.S. Rev. 10-15 I/O-CHTSTAT03 Printed in U.S.A.
