  • Page 1 Car Camcorder User Manual...

  • Page 2: Table Of Contents

    Contents Regulatory notices ..............3 Prohibition of co-location ............3 WEEE Notice ................3 ..................4 CE Regulatory Notice ..............4 Notes on Installation ..............5 Caution ..................5 Introduction ................ 9 Features ................. 9 Package Contents ............9 Product Overview ............10 Getting Started ..............
  • Page 3 Automatic Record ............19 3.1.1 The Recording Screen ........20 3.1.2 Emergency Recording ........22 Add Speed Point ............22 Picture in Video ............. 23 Driving Safety ............... 23 3.4.1 Speed Cam Alert ..........24 3.4.2 Speed Limit Alert ..........25 3.4.3 Driver Fatigue Alert ..........

  • Page 4: Regulatory Notices

    About this Guide The content in this document is for information purpose and is subject to change without prior notice. We have made every effort to ensure that this User Guide is accurate and complete. However, no liability is assumed for any errors or omissions that may have occurred.

  • Page 5: Fcc

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Ce Regulatory Notice

    CE Regulatory Notice The product herewith complies with the requirements of the RED-Directive 2014/53/EU. EU Health Protection: This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Notes on Installation 1. Please measure the front windshield viewing area, make sure not to block driver's front view, install the camcorder below the rearview mirror (the central, higher right position of the front windshield).
  • Page 7  The firmware function in the camcorder is for reference only, drivers are advised to exercise discretion based on actual road conditions.  The results of GPS positioning are only for reference, and should not affect the actual driving situation. The camcorder also cannot ensure the positioning accuracy.
  • Page 8 “Switch Off 2-way Radios” sign by switching off camcorders that may interfere with the radio frequency.  HP Inc. is NOT responsible for the loss of any data/content during operation.  Disposal of a battery into fire or a hot oven, or mechanically...
  • Page 9  Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas...

  • Page 10: Introduction

    1 Introduction Thank you for purchasing this advanced Car Camcorder. This product is specifically designed for real time video recording when driving. It also supports a HP rear camera. You might ask distributor for further information. Features  Full HD 1920*1080 ...

  • Page 11: Product Overview

    Product Overview Note: Please press the button (3~7) according to the diagram notice shown on screen.

  • Page 12: Getting Started

    2 Getting Started Storage Media 2.1.1 Insert the Memory Card Insert memory card with the pins facing forward and the screen of the camcorder facing forward too, see the picture as below: 2.1.2 Remove the Memory Card If the camcorder is power on, please power off first and wait for the procedure of switching off the camcorder completed before removing the memory card.

  • Page 13: Installing In Vehicles

    Installing in Vehicles 2.2.1 Mount to Windshield Put the electrostatic sticker onto the suggested area on the windshield. Before putting the sticker, please wipe and clean the windshield. During the installation, please make sure the bubbles in between the sticker and the window are all gone. Peel off the protective plastic sheet from the adhesive pad.

  • Page 14: Adjust The Camcorder

    2.2.2 Adjust the Camcorder Loosen the knob to swivel the camcorder to adjust view angle. Then tighten the knob to make sure the camcorder is securely locked in place.

  • Page 15: Connecting To Power

    Connecting to Power Use only the supplied car charger to power up the camcorder. Connect one end of the car charger to the USB connector of the camcorder. USB port input: DC 5V / 1A. Plug the other end of the car charger to the cigarette lighter socket of your vehicle.

  • Page 17: Powering The Camcorder On / Off

    Powering the Camcorder On / Off 2.5.1 Auto Power On/Off Start the car engine, wait a few seconds to charge the camcorder, and then screen will light up and the camcorder will automatically power on and start recording. Once the vehicle engine shuts down, the camcorder automatically saves the recording and turns off the power.

  • Page 18: Initial Settings

    Initial Settings Before using the camcorder, we recommend you setup the correct Time zone, Date and Time. Note: Please note that if you press the button during recording, the system will stop recording and enter OSD menu. Make sure the recording is already stopped then continue operating the menu.

  • Page 19: Set The Date / Time

    2.6.2 Set the Date / Time To set the correct date and time, do the following: Press the button to enter the OSD menu. Press the button to select Date / Time, and then press the button for entering function menu.

  • Page 20: Using The Car Camcorder

    3 Using the Car Camcorder 3.1 Automatic Record Start the car engine, wait a few seconds to charge the camcorder, and then screen will light up and the camcorder will automatically power on and start recording. Recording will automatically stop when the engine is switched off. Note: 1.

  • Page 21: The Recording Screen

    3.1.1 The Recording Screen Icon Item Description Recording Indicates the video current Duration duration. During video recording, press the button to enter the OSD Menu Button menu；long press 3 seconds button to enter Function Chart. During video recording, press the button to add a speed cam Add Speed Point 錯誤...
  • Page 22 Resolution Indicates the video resolution. icon Indicates voice recording sets as off, the sound will not be recorded. Voice Record 錯誤 找不到參照 Please refer to icon 來源。 (6.2). Indicates the strength of satellite Satellite positioning. If the icon shows Positioning up on screen, it indicates that the icon camcorder cannot complete the...

  • Page 23: Emergency Recording

    3.1.2 Emergency Recording To Start the Emergency Recording, do the following: During Video Recording, press the button to enter emergency recording mode, the “Emergency” message will be shown immediately on the upper left corner of the screen, and the recorded file will be protected. The emergency video recording length is same as the recording interval setting.

  • Page 24: Picture In Video

    3.3 Picture in Video You can also use this camcorder to take snapshots of the current scene. In recording status, press to capture recording screen shots from the front (and rear) lens. When the icon shows in the central of screen, it means the screenshots is completed.

  • Page 25: Speed Cam Alert

    3.4.1 Speed Cam Alert If the Speed Cam Alert function is enabled, once your car’s location is determined by GPS and approaches a speed cam, this product produces audible alert and screen message. To enable the Speed Cam Alert, do the following: Press the button to enter the OSD menu.

  • Page 26: Speed Limit Alert

    3.4.2 Speed Limit Alert If the Speed Limit Alert function is enabled, this product produces audible alert and screen message once your car’s location is determined by GPS and its running speed exceeds the set limit. To set the Speed Limit Alert, do the following: Press the button to enter the OSD menu.

  • Page 27: Driver Fatigue Alert

    3.4.3 Driver Fatigue Alert If the Driver Fatigue Alert function is enabled, this product produces audible alert and screen message one hour after it has begun recording and repeats the alerts every half hour afterwards. To enable the Driver Fatigue Alert, do the following: Press the button to enter the OSD menu.
  • Page 28 Press the button to return to recording screen. After enabling LDWS, the screen will display traffic lane align icon , please adjust the camcorder so that the horizontal line and the eye level are overlapped and the slash lines are centered in the driving lane. This product produces audible alert and screen message when LDWS is activates.

  • Page 29: Fcws

    3.4.5 FCWS Once your car’s location is determined by GPS and the FCWS function is enabled, this camcorder produces audible alert and screen message when you drive at speeds over 60 km/h (37 mph) and are less than 20 m away from the car in front of you. If the camcorder not completes the satellite positioning, and the leading vehicle distance below 20 meters, it will also produce a warning screen and beep reminder.

  • Page 30: Headlight Warning

    3.4.6 Headlight Warning The Headlight Warning function produces audible alert and screen message when it detects poor lighting conditions through the recording displays of this camcorder, including driving in rainy or cloudy weather, at night, and in basements, parking lots, and tunnels.
  • Page 31 3.4.7 FCMD If FCMD function is enabled, when the front car moves and you don’t start to drive forward, the camcorder will issue audible alert and screen message. To set the FCMD (Front Car Move Detection), do the following: Press the button to enter the OSD menu.
  • Page 32 3.5 Parking Mode To monitor the vehicle when it is parked, you can activate Park Recording, or Motion and Collision Detection, or Timelapse. Before you activate Parking Mode, please install ACC cable through professional car service shop. Follow the steps below to change the settings for Parking Mode: Press the button to enter the OSD menu.
  • Page 33 3.5.2 Motion and Collision Detection - In normal loop recording mode, press and hold POWER key for 3 seconds, the screen will show message “Press OK to power off or enter Motion and Collision Detection after 10 sec.” Please wait for 10 seconds and the camcorder will enter Motion and Collision Detection automatically.
  • Page 34 3.6 Collision Detection If the Collision Detection function is enabled, this camcorder begins emergency recording once it detects any collision. Sensitivity of the Collision Detection function is set to Normal by default, if user wants to change the settings of Collision Detection, do the following: Press the button to enter the OSD menu.

  • Page 35: Playback Videos And Photos

    3.7 Playback Videos and Photos If recording is in progress, press the button to stop recording and enter Menu. Press the button to select Playback and press the button. Press the button to select Video, Emergency or Picture category and press the button.

  • Page 36: The Playback Screen

    3.8 The Playback Screen Video Playback Screen Picture Playback Screen Icon Item Description Press the button to return preview screen of video or picture. Return Press the button repetitively to return recording screen. Fast Forward Indicates video fast-forward and / Fast Rewind rewind status.

  • Page 37: Deleting Files

    Icon Item Description Total Duration Shows the current file serial number Serial Number and total file number. When viewing pictures, press the Previous File button will switch over to the previous file. When viewing pictures, press the Next File button will switch over to the next file.
  • Page 38 Use the to select the video or photo you want to delete, and press button to confirm your selection. Note: 1. Deleted files CANNOT be recovered. Ensure the files you wish to preserve are backup before deletion. 2. If the file is taken by front camera and rear camera at the same time, no matter you delete video or picture from Front camera folder or Rear camera folder, both front camera file and rear camera file will be deleted.

  • Page 39: Initial Set Up Go Dashcam Application

    4 Initial set up Go Dashcam application 4.1 Camcorder application installation The camcorder allows you to connect to the mobile devices via the App. When using for the first time, install the [Go Dashcam] App for your mobile device. Download Go Dashcam App from Google Play or App Store.
  • Page 40 APP layout and features may be changed subject to different software versions. Please refer to Google Play or APP Store for update. 4.2 Wi-Fi connecting Press the Power button to switch on the camcorder. Enter Menu and go to Wi-Fi option; choose “ON” to activate the wireless network.
  • Page 41 3. After connecting the mobile device with the camcorder, and activate app feature “Camera Preview”, all the button operation of the camcorder will be disable; all the operations shall be carried out via the Go Dashcam App. 4. The language of the Go Dashcam App will be consistent with your mobile device, beyond the language options, the App will be activated with default language.

  • Page 42: Using The Go Dashcam Application

    5 Using the Go Dashcam application Touch [Go Dashcam] icon to activate the application. The main screen will pop up. Follow the below instruction to operate this application.

  • Page 43: Camera Preview, Record, Snapshot

    5.1 Camera preview, record, snapshot You can use this feature to preview, record or take snapshot. 1. The mobile device will display camcorder’s preview screen. The camcorder will lose control and screen will show ”Network Streaming”. Please use Go Dashcam app to operate the camcorder.

  • Page 44: Playback, Delete, Download

    icon Description Start/stop recording Snapshot (no matter in front camcorder or rear camcorder preview, once you touch this icon, both of front and rear camcorder will take photo.) Switch front and rear camcorder preview 5.2 Playback, delete, download You can use this feature to playback or delete the file saved in camcorder, or to download the file from camcorder to your mobile device.
  • Page 45 Icon Description Switch front and rear camcorder Download the file from camcorder to your mobile device Delete Exit...
  • Page 46 Note: 1. If you find the video playback without audio, please check if you turn on Voice Record on the menu. If you do turn it on, it means the mobile device itself doesn’t support the video decoding. It’s not the problem of the file. We recommend you to install a free app software such as VLC to playback the file.

  • Page 47: Local Album

    5.3 Local album You can use this feature to playback or delete the file that you download to your mobile device. Touch icon [Local Album]。 Pick up the file that you want to playback. The downloaded videos or pictures will be saved in the album of your mobile device, at the mean time it will create a new folder “Go Dashcam”.

  • Page 48: Camera Setting

    5.4 Camera Setting You can use this feature to set up your car camcorder. Touch icon [Camera Setting]. Refer to the below table for details of menu items and available menu options. Menu option Description Available option 1080p 30fps HDR 1080p 27.5fps HDR Set the desired video Resolution...

  • Page 49: Adjusting The Settings

    6 Adjusting the Settings 6.1 Using the Menu You can customize the general settings via the on-screen display (OSD) menus. Press the button to enter the OSD menu. Press the button to select menu item, and then press the button for entering function menu. Press the button to select or adjust the value, and then press the...
  • Page 50 Menu option Description Available option If the Speed Cam Alert function is enabled, once your car’s location is determined by GPS and Speed Cam Alert On / Off approaches a speed cam, this product produces audible alert and screen message. Add Speed Point: The satellite positioning will manually add speed...
  • Page 51 Menu option Description Available option 1920x1080 30fps HDR 1920x1080 27.5fps HDR Resolution Setting of video resolution. 1280x720 30fps HDR 1280x720 27.5fps HDR Press the button to set the exposure value. Setting of exposure value. It can be set between -2 ~ Set LCD off time.
  • Page 52 Menu option Description Available option When Headlight Warning is activated, camcorder will issue an audible alert and Headlight screen message reminding On / Off Warning that insufficient brightness is sensed on the recording face. Once your car’s location is determined by GPS and the LDWS function is enabled, this camcorder produces LDWS...
  • Page 53 Menu option Description Available option Format the memory card inserted in the equipment. Format Yes / No All the files in the card will be erased. The system reverts to the Default Yes / No default setting. Indicates the current Firmware Version firmware version.

  • Page 54: Installing The Software

    7 Installing the Software Place the attached CD ROM into the CD player. If the CD does not execute automatically, please use Windows File Manager to execute the Install_CD.exe file in the CD. The following screen will be shown up. Press the [Menu] item to start the installation process according to the instructions on-screen.

  • Page 55: Supercar

    8 SuperCar Item Item Front Camera File Path Playback Play / Pause Browser File Previous File List Next Rear Camera Playback Stop Volume Playback Duration / Total Electronic Map Duration Compass G-Sensor Speed Meter Note: 1. To display the route on Electronic Map, please make sure the internet is connected before starting the video playback.

  • Page 56: Specifications

    Specifications Item Description Image sensor 1/2.8” CMOS sensor 1920 (H) x 1080 (V) Effective pixels Supports Micro SDHC, up to 32GB class 10 speed or Storage media greater 2.31” LCD color TFT LCD display Wide Angle Fixed Focus lens Lens Aperture: Up to F1.8 Focus range 1.5m~Infinity...
  • Page 57 Item Description Power Super Capacitor Operating 0° ~ 45° C Temperature Operating 20 ~ 70% RH Humidity Storage -20° ~ 70° C Temperature Dimensions 56.5 x 30 x 58 mm Weight Approx. 74g Built-in IEEE 802.11g/n(HT20) Wi-Fi chip: RTL8188FTV Frequency range 2412~2472MHz (for EU) Wi-Fi Channel Ch1~Ch13 (for EU)
