5
EXPLODED VIEWS AND PARTS LIST
N
OTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List.
• The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
• Screw adjacent to mark on the product are used for disassembly.
• For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions,apply as you think it appropriate.)
PACKING
12
13
1
1
8
PACKING SECTION PARTS LIST
Mark No.
Description
1
Screw(M3 x 6)
2
Cord Assy
3
Accessory Assy
4
Attachment Assy
5
Packing
6
Double Faced Tape
7
Fastener Assy
8
Unit Box
9
Contain Box
5
6
10
11
2
6
7
4
5
9
Mark No.
Part No.
CZB5016
CZD5443
CZE5026
CEA4582
CZN7090
CZN7091
CZX5193
CZH7112
CZH7113
ND-BC2/E5
6
7
14
15
3
Description
10
Owner's Manual 1
(English, Spanish, German, French, Italian)
11
Owner's Manual 2
(Portuguese(B), Russian, Simplified Chinese, Arabic)
12
Camera Assy
13
Strap Assy
14
Battery Box Assy
15
Strap Assy 2
7
8
A
B
C
D
E
Part No.
CZR5068
CZR5069
CZX5373
CZX5374
F
CZX5375
CZX5379
5
8
